Motorola I30sx Guida

135

i30sx Faceplates and Keypads

Your i30sx phone comes with a standard faceplate and keypad. You can order

additional face plates and keypads to change the look of your phone.

The following steps and accompanying illustration detail the procedure for

removing and replacing the changeable faceplate and keypad.

NOTE:Before replacing the faceplate, ensure that the keypad is

present and undamaged. For security and operational reasons,

power to the i30sx phone should be off prior to performing the

removal and replacement procedure. There is a protective

plastic liner over the lens. Peel off prior to operation.

Removal and Replacement Procedure

1

While holding the back of the phone, press the

faceplate release button located at the bottom of

the phone to release the faceplate. When you

press the release button, ensure that both sides

are disengaged from the faceplate prior to

removal.

2

In an upward motion, grasp the bottom part of the faceplate and detach

it from the phone.

3

Remove the keypad from the phone (or from the faceplate).

Release Button

4

To replace the faceplate and keypad, lay the keypad on the phone body.

5

As shown in the illustration, attach the faceplate to the phone body, first

at the top and then at the bottom. The top of the faceplate needs to be

securely seated into the top of the phone. Rotate faceplate towards

bottom of the phone until the lower snaps are engaged. Snap

engagement will be verified by a clicking sound. After the lower snaps

are engaged, verify that the middle of the faceplate is engaged by

pressing the faceplate near the sand rkeys. This will be verified by

a clicking sound.

6

Re-apply power to the phone by pressing and holding pnear the

bottom of the phone until the status light glows red and a tone briefly

sounds.
