i50sx Faceplates and Keypads

Your i50sx phone comes with a standard faceplate and keypad. You can order

additional face plates and keypads to change the look of your phone.

The following steps and accompanying illustration detail the procedure for

removing and replacing the changeable faceplate and keypad.

NOTE:Before replacing the faceplate, ensure that the audio seal and

keypad are present and undamaged. For security and

operational reasons, power to the i50sx phone should be off

prior to performing the removal and replacement procedure.

There is a protective plastic liner over the lens. Peel off prior to

operation.

Removal and Replacement Procedure

1

While holding the back of the phone, press the faceplate release button

located at the bottom of the phone to release the faceplate.

2

In an upward motion, grasp the bottom part of the faceplate and detach

it from the phone, while also detaching the upper part of the faceplate

from the phone.

3

Remove the keypad from the phone (or from the faceplate).

4

To replace the faceplate and keypad, lay the keypad on the phone body.

5

As shown in the illustration, attach the faceplate to the phone body, first

at the top and then atthe bottom. Rotate faceplate towardsbottom of the

phone until the lower snap is engaged. Snap engagement will be

verified by a click sound. After the lower snap is engaged, verify that

the upper snap is engaged by pressing the earpiece area.

6

Re-apply power to the phone by pressing the power button located on

the top of the phone.

Phone Body

Faceplate Release Button

Keypad

Faceplate
