Motorola XT605 Manuale utente

APPLICANT:MOTOROLA MOBILITY, INC. FCC ID: IHDT56NA1

INSTRUCTION MANUAL

A representative version of the user's manual follows:

Exhibit 8

MOTOROLA XT605

January 10, 2012

1Congratulations

Congratulations

MOTOROLA XT605

Stay connected, organize your life, and absolutely own

the web with MOTOROLA XT605.

• Direct Connect calls. Keep in touch with your family,

friends, and colleagues with the simple touch of a

button.

• Organization. Check your email, calendar, and

contacts wherever you are.

•Browsing.Get more from the web with a huge

screen. Search, browse, everything you want to do,

all made easier.

• Maps, entertainment, and more. The latest

technology and apps. Google Maps™ to find your

way. YouTube™ to stay entertained. Easy access to

Google™ and thousands of Android™ apps to expand

your world.

Note: Certain apps and features may not be available in

all countries.

Caution: Before assembling, charging, or using your

phone for the first time, please read the important

legal and safety information packaged with your

product.

This product meets the applicable SAR limits of

1.6 W/kg (FCC & IC) and 2.0 W/kg (ICNIRP). The

limits and guidelines include a substantial safety

margin designed to assure the safety of all persons,

regardless of age and health. The highest SAR values

measured for this device are listed in the regulatory

information packaged with your product.

Note: When using the product while worn on your body,

either use an approved accessory such as a holster or

maintain a distance of 2.5 cm (1 inch) from the body to

ensure compliance with SAR requirements. Note that

the product may be transmitting even if you are not

making a phone call.

•Answers:Touch >

Help Center

• Updates: Smartphone updates, computer software,

user guides, online help, and more at

www.motorola.com/myXT605.

• Accessories: Find accessories for your smartphone at

www.motorola.com/products.

January 10, 2012

2Your phone

Your phone

the important keys & connectors

Note: Your phone might look a little different.

11:58

Add a social network

Add a social

network

HAPPENINGS

UNIVERSAL

INBOX

No recent unseen

messages

64˚

WOODSTOCK

64˚

WOODSTOCK

Press=Sleep/

Wake up.

Hold=Turn on/off.

Speaker

Key

Home Key

Back Key

Menu Key

Micro USB

Connector

Charge or

connect to PC.

Volume

Keys

Search Key

DC Button

Programmable

Key

Touchscreen

Power/Screen

Lock Key

3.5mm Headset Jack

Contents

Let’s go . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Touchscreen & keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Home screen & apps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Calls. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Direct Connect. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Contacts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Messaging. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Text entry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Tips & tricks. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Photos & videos . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Music . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Social networking. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Web . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

Personalize. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

Location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

Apps for all. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

Bluetooth™ wireless. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

Wi-Fi . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

Memory card & file management . . . . . . . . . . . . . . . . . . . . . . . . 49

Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53

Management . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61

Safety, Regulatory & Legal. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62

January 10, 2012

3Contents

Let’s go

let’s get you up and running

Assemble & charge

Caution: Please read “Battery Use & Safety” on page 62.

Tip: To save battery life, see “Battery tips” on page 26.

1Cover off

microSD in

3SIM in

5Cover on

6Charge

Battery in

SIM microSIM microSIM

+ Adapter

Set up & go

Note: This phone supports apps and services that use a

lot of data, so make sure your data plan meets your

needs. Contact your service provider for details.

Note: If you have an existing Gmail™ account, your

contacts from that account are synced to your phone.

11:58

Add a social network

Add a social

network

HAPPENINGS

UNIVERSAL

INBOX

No recent unseen

messages

64˚

WOODSTOCK

64˚

WOODSTOCK

d a soci

1Turn on.

2Select a language.

3Create account,

or log in.

Kim Vonesh

Welcome

Touch the android to begin.

Emergency dial Change language

Set up your Google Account 4Add accounts.

Don’t have a Google Account?

Already have a Google Account?

Want to set up an account later?

Create

Skip

If you use any of the services below, tap

the icon to set it up.

Google LastFMFlickr

Corporate Sync Facebook

Setup accounts

last.fm

January 10, 2012

4Touchscreen & keys

Wi-Fi connect

If you want to use a Wi-Fi network for even faster

Internet access, touch >

Settings

Wireless &

networks

Wi-Fi settings

. Touch

Wi-Fi

to search for and

connect to wireless networks. There’s more in “Wi-Fi”

on page 47.

Cool content & more

Browse and download thousands of the coolest apps on

the planet from Android Market™. See “Browse &

install apps” on page 44.

Your phone can use a microSD memory card (sold

separately)—you can load it up with photos, videos, and

music from your computer (see “Memory card” on

page 49).

Touchscreen & keys

a few essentials

Touch tips

Here are some tips on how to navigate around your

phone.

Touch

To ch oos e an ic on or

option, touch it.

Touch & hold

To open special options,

touch and hold an icon or

other item. Try it: In the

home screen, touch

Contacts

, then touch

and hold a contact to open

options.

SCREEN NOT YET AVAILABLE

January 10, 2012

5Touchscreen & keys

Drag

To scroll through a list or move

slowly, drag across the

touchscreen. Try it: Touch >

Contacts

, then drag your

Contacts

list up or down.

Flick

To scroll through a list or move

quickly, flick across the

touchscreen (drag quickly and

release).

Tip: When you flick a long list,

touch the screen to stop it from

scrolling.

Zoom

Get a closer look at Google Maps™ or web pages. To

zoom in, double-touch (tap twice quickly) the screen. To

zoom out, double-touch the screen again.

You can also zoom in or out by pinching your fingers

together or moving them apart on the screen.

Touchscreen on/off

Your touchscreen is on when you need it and off when

you don’t.

•To make your touchscreen sleep or wake up, just

press Power/Lock .

•When you hold the phone to your ear during calls,

your touchscreen sleeps to prevent accidental

touches.

Messaging

cker Dr

rborn St

N Micigan Ave

W Lake St W Lak

E Wacker Pl

State/Lake

Lake Randolph/

Wabash

ashington-Blue

E S

andolph St

Messaging

N Clark St

Wacker Dr

E Ohio St

N Rush St

N Wabash Ave

N Dearborn St

E Grand Av

N Micigan Ave

W Lake St W Lake St

E Wacker Pl

State/Lake

Grand Red

Lake

Randolph

St Metra

Randolph/

Wabash

Washington-Blue

E S WaterSt

E Randolph St

Ontario St E Ontario St

Pinch to zoomout.

January 10, 2012

6Touchscreen & keys

•To change how long your phone waits before the

screen goes to sleep, touch >

Settings

Display

Screen timeout

•To make the screen lock when it goes to sleep, use

“Screen lock” on page 59. To unlock the screen,

press Power/Lock or open the phone. Then, drag

to the right.

Note: Your touchscreen might

stay dark if the sensor just

above it is covered. Don't use

covers or screen protectors

(even clear ones) that cover

this sensor.

Key tips

Menu, home, back, & search

Touch Home to close any menu or app and return to

the home screen. In the home screen, touch and hold

Home to show the last eight apps you used, then

touch an app to open it.

11:58

Add a social network

HAPPENINGS

UNIVERSAL

INBOX

Key

Back

Key

Home

Key

Touch Search for text search, or touch and hold for

voice search.

Touch Menu to open menu options, or touch

Back to go back.

Power key menu

Press and hold Power/Lock to open the power key

menu, where you can turn off your phone (

Power off

), or

turn

Airplane mode

Silent mode

on or off.

Adjust volume

Press the volume keys to change the

ring volume (in the home screen) or

the earpiece volume (during a call).

When playing music or video files,

press the volume keys to adjust media

volume.

Rotate the screen

In many apps, the touchscreen can rotate to stay

right-side up when you turn your phone sideways:

Find it: >

Settings

Display

Auto-rotate

screen

January 10, 2012

7Home screen & apps

Home screen & apps

quick access to the things you need most

Quick start: Home screen

The home screen gives you all your latest information in

one place. It’s what you see when you turn on the phone

or touch Home from a menu. It’s basically like this:

Note: Your home screen might look a little different.

SCREEN NOT YET AVAILABLE

The home screen extends to give you room for adding

shortcuts, widgets, and more. Flick the home screen left

and right to see more panels or to add widgets or

shortcuts.

Use & change your home screen

On your home screen, shortcuts are icons that open

your favorite apps, Web bookmarks, contacts, mail

labels, or music playlists. Widgets show you news,

weather, messages, and other updates right on your

homescreen without having to open a separate app or

web page.

•To open something, touch it. Touch Home to

return to the home screen.

SCREEN NOT YET AVAILABLE

January 10, 2012

Indice

Altri manuali Motorola Telefono cellulare

Motorola

Motorola MOTOSLVR L7 Manuale utente

Motorola

Motorola RAZR V3x Manuale utente

Motorola

Motorola Sprint MOTORAZR2 V9m Manuale utente

Motorola

Motorola 6700 Manuale utente

Motorola

Motorola moto g20 Foglio di istruzioni

Motorola

Motorola DROID RAZR M Manuale utente

Motorola

Motorola Motorokr U9 Manuale utente

Motorola

Motorola E815 Manuale

Motorola

Motorola XT319 Manuale utente

Motorola

Motorola V505 Manuale utente

Motorola

Motorola I886 Manuale utente

Motorola

Motorola moto e3 Manuale utente

Motorola

Motorola IDEN LM 3000E Manuale utente

Motorola

Motorola M900 Manuale utente

Motorola

Motorola XT535 Manuale utente

Motorola

Motorola MOTOKRZR maxx K3 Manuale utente

Motorola

Motorola T250 Manuale utente

Motorola

Motorola V3 Manuale utente

Motorola

Motorola MOTO VE465 Manuale utente

Motorola

Motorola i876 Manuale utente

Motorola

Motorola EX431G Manuale utente

Motorola

Motorola BRUTE i686 Manuale utente

Motorola

Motorola DEXT Manuale utente

Motorola

Motorola Moto G5 Plus Foglio di istruzioni

Manuali Telefono cellulare popolari di altre marche

Zte

Zte BLADE A520 Manuale utente

Nokia

Nokia Lumia 620 Manuale utente

Blackbe;rry

Blackbe;rry KEYone Manuale utente

Bea-fon

Bea-fon X5 Premium Manuale utente

Blackbe;rry

Blackbe;rry 8707 Series Manuale utente

Blackbe;rry

Blackbe;rry Storm Istruzioni operative

LG LM-X420QN Manuale utente

LifeWatch

LifeWatch V Manuale utente

Bea-fon

Bea-fon SILVER LINE SL860 Manuale utente

IKI Mobile

IKI Mobile KF4.5i Manuale utente

Hitech

Hitech HT-850 Manuale utente

Yezz

Yezz Fashion F10 Manuale utente

Point Mobile

Point Mobile PM60 Manuale utente

Blackbe;rry

Blackbe;rry Q10 Manuale utente

Blackbe;rry

Blackbe;rry Bold 9900 Manuale utente

Blackbe;rry

Blackbe;rry STORM 9500 - VERSION 5.0 Manuale utente

LG LM-K420EMW Manuale utente

ISAFE MOBILE

ISAFE MOBILE IS655.2 Manuale utente
