1English
FOREWORD
RF Energy Exposure and Product
Safety Guide for Portable Two-Way
Radios
ATTENTION!
Before using this product, read the RF Energy
Exposure and Product Safety Guide that ships
with the radio which contains instructions for
safe usage and RF energy awareness and
control for compliance with applicable
standards and regulation.
ACOUSTIC SAFETY
Exposure to loud noises from any source for
extended periods of time may temporarily or
permanently affect your hearing. The louder
the radio’s volume, the less time is required
before your hearing can be affected. Hearing
damage from loud noises is sometimes
undetectable at first and can have a
cumulative effect.
To protect your hearing:
• Use the lowest volume necessary to do
your job.
68012009043_a.book Page 1 Thursday, May 16, 2013 10:14 AM
2English
• Increase the volume only if you are in noisy
surroundings.
• Reduce the volume before connecting
headset or earpiece.
• Limit the amount of time you use headsets
or earpieces at high volume.
• When using the radio without a headset or
earpiece, do not place the radio’s speaker
directly against your ear.
DESCRIPTION
The PMLN6541 Retail Temple Transducer
Headset features high performance bone
vibration speakers for clear audio reception in
noisy environments. It uses a discrete,
lightweight and streamlined “ear loop” that
provides users with bone conduction
technology. Unlike conventional headsets, the
Temple Transducer allows the user’s ears to
be uncovered and completely free to hear
surrounding environmental sounds, while still
using the two-way portable radio. An in-line
push-to-talk (PTT) button and microphone
frees the user from holding the radio while
communicating.
68012009043_a.book Page 2 Thursday, May 16, 2013 10:14 AM
3English
OPERATION
1. Wear the Temple Transducer Headset as
shown in Figure 1.
2. Be sure to position the bone vibration
speakers on your temples.
3. Clip the in-line PTT switch in a convenient
operating location.
4. Turn the radio off before connecting the
headset.
68012009043_a.book Page 3 Thursday, May 16, 2013 10:14 AM
4English
5. Connect the plug to the accessory audio
port on the radio.
6. Turn the radio on, adjusting the audio
volume to an appropriate level.
7. Press and hold down the in-line PTT button
and begin speaking in order to transmit.
8. Your radio will return to receiving mode
when you release the in-line PTT button
after you finish speaking.
Figure 1: Wearing your Accessory
68012009043_a.book Page 4 Thursday, May 16, 2013 10:14 AM
5English
NOTE: You may actually feel the Temple
Transducer Speakers shake or vibrate
when the receive volume is too high.
For more comfortable use, set the
receive volume to an appropriate level.
Radios with this “Digital Symbol” are digital
capable radios and require the use of
accessories with the same “Digital Symbol”.
These accessories with the “Digital Symbol”
have been optimized for digital audio Transmit
and Receive. Use of non-approved
accessories may result in degradation of audio
quality.
Digital Symbol
Figure 2: Digital Symbol Marking
68012009043_a.book Page 5 Thursday, May 16, 2013 10:14 AM
6English
SERVICE
The PMLN6541 Retail Temple Transducer
Headset is not repairable. It is covered under
the Motorola six months limited warranty.
Order a replacement headset as necessary.
MOTOROLA, MOTO, MOTOROLA SOLUTIONS and
the Stylized M logo are trademarks or registered
trademarks of Motorola Trademark Holdings, LLC and
are used under license. All other trademarks are the
property of their respective owners.
© 2013 by Motorola Solutions, Inc. All rights reserved.
68012009043_a.book Page 6 Thursday, May 16, 2013 10:14 AM
7Español
(Latinoamérica)
PRÓLOGO
Guía de exposición a energía de
radiofrecuencia y seguridad del
producto para radios bidireccionales
portátiles.
¡ATENCIÓN!
Antes de utilizar este producto, lea la Guía de
exposición a energía de radiofrecuencia y
seguridad del producto que se incluye con el
radio, la que contiene instrucciones para uso
seguro e información para tomar conciencia y
controlar la energía de radiofrecuencia, para
que cumpla con los estándares y reglamentos
correspondientes.
SEGURIDAD ACÚSTICA
La exposición a ruidos fuertes de cualquier
fuente durante períodos prolongados podría
afectar la audición de manera temporal o
permanente. Cuanto más alto sea el volumen
del radio, más rápido se verá afectada la
audición. En ocasiones, el daño a la audición
provocado por ruidos fuertes es indetectable
en un principio y puede tener efecto
acumulativo.
68012009043_a.book Page 7 Thursday, May 16, 2013 10:14 AM
8Español
(Latinoamérica)
Para proteger la audición:
• Use el volumen más bajo necesario para
hacer su trabajo.
• Aumente el volumen solo si se encuentra
en un entorno ruidoso.
• Disminuya el volumen antes de conectar
los auriculares o los audífonos.
• Limite el tiempo durante el cual usa los
auriculares o audífonos a volumen alto.
• Cuando use el radio sin el auricular o los
audífonos, no ponga el altavoz del radio
directamente en la oreja
DESCRIPCIÓN
El Auricular transductor para hueso temporal
PMLN6541 cuenta con parlantes de alto
desempeño que hacen vibrar el hueso
temporal. Esto permite una recepción clara del
audio en entornos con mucho ruido. El auricular
utiliza un "aro" para colocar sobre la oreja que
es discreto, liviano y ergonómico. Este aro le
brinda a los usuarios la tecnología de
conducción para el hueso. A diferencia de los
auriculares convencionales, el Transductor para
el hueso temporal permite que, mientras el
usuario utiliza la radio portátil, sus oídos queden
totalmente descubiertos y libres para escuchar
los ruidos del entorno. Gracias al micrófono y al
68012009043_a.book Page 8 Thursday, May 16, 2013 10:14 AM
