Motorola V101 Personal Communicator

Quick Reference Card

Control Buttons

,Press and hold to turn the communicator on and off.

(Accept and end a call, setting, or option.

ªReject or cancel a call, setting, or option. Press and release

to return to previous screen. Press for 2 seconds to go to

Standby screen. When entering text, press to delete

previous characters.

¢Press to enter Quick Access menu.

!Scroll through messages and text, increase and decrease

volume.

#Press to read a message.

.Press to write a message.

£Used to enter numbers and ALT symbols. Press once for

single number/symbol, press twice for multiple numbers/

symbols. Press twice to stop entering numbers/symbols.

ƒPress once to capitalize a letter. Press twice for continuous

capitalization, press twice again to stop capitalization.

]Smart Button. Use to answer, make, and end calls. Press to

go to Contacts and recall a phone number using Voice Tags.

}Press to answer and end a call when communicator is

closed or in the holster.

&Press to record Voice Notes, press again to stop recording.

Sending a Text Message

1. Press ., type your message, press (.

2. Follow the prompts to enter or select the phone number.

3. When the phone number is displayed, press (.

1039b80o.book Page 3 Monday, December 17, 2001 2:00 PM

Making a Call

Use the headset. Use !on keypad to adjust the volume.

Press ]to go to Contacts (or say Voice Tag name), select the

number, press (.

Note: Press and release ªto erase the last character, press

and hold ªto erase multiple characters.

Ending a Call

Press (or ª.

Receiving a Call

Use the headset. Use !on keypad to adjust the volume.

Press (to answer the call.

When the communicator is closed or in the holster, press }to

answer or end a call.

SIM Card and Battery Installation

1. Remove the battery cover.

2. With the gold contacts facing down, insert the SIM card into

the card recess area. Align the SIM card so the notch in the

card lines up with the notch in the recess area.

3. Align the battery contacts with the contacts in the battery

compartment. Press down on the battery until it clicks into

place.

4. Replace the battery cover.

Note: If the SIM card is inserted incorrectly, Check Card is

displayed. Remove the SIM card and re-insert it. If the card does

not work, contact your service provider.

Charging your Battery

Insert the adapter plug into the charging port on the

communicator and plug the adapter into a wall outlet.

1039b80o.book Page 4 Monday, December 17, 2001 2:00 PM

Introduction

Congratulations! You are now the proud owner of a Motorola V101 Personal

Communicator. Your Personal Communicator combines advanced calling and

messaging capabilities in a small compact unit that is easy to use and convenient to

carry with the holster accessory.

Your Personal Communicator provides cool and exciting ways to keep in contact with

your family and friends. Just review this user’s guide carefully and you will be ready

to start using your new Personal Communicator.

A detachable Quick Reference Card is included with this guide.

Personalized Control

You can set up your Personal Communicator to access important messages, phone

numbers, and features quickly. You can even answer calls with just one push of a

button, even when your Personal Communicator is closed. When you are performing

routine tasks, your Personal Communicator provides prompts and messages that

assist you with the next task or confirms your selection.

• You can add 9 of the features you use the most to your Quick Access menu so

you can get to them with just a couple of button presses.

• Voice Tags let you use voice-activated commands to call phone numbers stored

in your Personal Communicator. You can also add voice commands to Quick

Access options.

1039b80o.book Page 1 Monday, December 17, 2001 2:00 PM

Introduction

•With voice notes, you can record notes to yourself or record parts of a call.

Note: Recording of phone calls is subject to varying State and Federal laws

regarding privacy and recording of phone conversations.

•The Smart button ]lets you quickly display the entries stored in your

Contacts list.

•When your Personal Communicator is closed or in the holster, you can answer

a call quickly and easily by pressing }.

•With VibraCall®alert, your Personal Communicator vibrates when you get new

messages or calls to avoid disturbing others or when in a noisy environment.

•You can personalize the menus by choosing the features you want readily

available and storing the ones you use less frequently out of sight.

MOTOROLA, the Stylized M Logo, and all other trademarks indicated as such herein are trademarks of

Motorola, Inc. ®Reg. U.S. Pat. & Tm. Off.

All other product or service names are the property of their respective owners.

Personal Communications Sector

1500 Gateway Blvd., Boynton Beach, FL 33426-8292

6881039B80-O

Printed in the United States 12/01

1039b80o.book Page 2 Monday, December 17, 2001 2:00 PM

Contents

Introduction........................................ 1

Personalized Control ....................... 1

Safety and General Information ....... 7

European Union Directives

Conformance Statement............ 17

Getting Started................................. 18

Optional Features .......................... 18

Installing the SIM Card and

Battery ........................................19

Charging the Battery......................20

Turning Your V101 Personal

Communicator On and Off..........20

Entering Your SIM Card Personal

Identification Number (PIN) ........21

Entering Your Unlock Code ...........21

Setting Your Service Center

Numbers ..................................... 21

Additional Message Settings .........22

Testing Your V101 Personal

Communicator ............................23

Using the Control Buttons..............24

The Display....................................28

Using the Menus ..............................29

The Main Menu ..............................29

Getting Around in the Menus .........29

Exiting the Menus to the Standby

Screen.........................................30

Using the Quick Access Menu .......30

Short and Extended Menus............31

Menu Map .........................................32

Text Messaging................................37

Sending Text Messages.................37

How to Create and Edit Text

Messages....................................41

Inserting Messaging Emoticons .....42

Canned Message Text ...................45

Receiving and Reading Text

Messages....................................47

Making a Call....................................48

Ending a Call..................................48

International Phone Calls...............49

911 Emergency Calls.....................50

Redialing the Last Number

Called from Standby Mode .........50

1039b80o.book Page 3 Monday, December 17, 2001 2:00 PM

Answering a Call..............................50

In-call Menu ......................................51

Put Calls on Hold ...........................51

Turn Mute On or Off.......................52

Restrict My Phone Number ............52

End Active Call...............................52

Reconnect......................................53

Reconnect Held Call ......................53

End Held Call .................................53

End Current Call and Held Call......53

Conference Calls............................53

Transfer Calls.................................54

Split Call.........................................55

Reject Incoming Call ......................56

Voice Activation...............................56

Create a Voice Tag for a Phone

Number .......................................57

Add or Edit a Voice Tag .................57

Delete a Voice Tag.........................58

Using Voice Activation to Make

Phone Calls.................................58

Using Voice Activation to Access

Quick Access Features...............59

Messages Menu............................... 60

Call Voicemail................................ 60

Received Messages ...................... 61

Outgoing Messages....................... 64

Message Editor.............................. 67

Voice Notes ................................... 68

Cell Broadcast ............................... 72

Message Settings............................ 73

Auto Signature............................... 74

Voicemail Number ......................... 74

Service Center............................... 74

E-mail Service Center.................... 74

E-mail @ Symbol........................... 75

Expiry Period ................................. 75

Icon Messaging ............................. 75

Outgoing Message Type ............... 75

Contacts........................................... 76

Personal Numbers......................... 76

Voice Dialing.................................. 82

Last Ten Calls................................ 83

My Phone Numbers....................... 83

Fixed Dialing.................................. 84

Set Up One-Touch Dialing............. 85

1039b80o.book Page 4 Monday, December 17, 2001 2:00 PM

One-Touch Dialing from Phone

Memory ...................................... 86

One-Touch Dialing Using the

Smart Button .............................. 86

Chat .................................................. 87

Starting a Chat Session................. 87

Add Chat Members........................ 88

View Member List .......................... 89

Start Chat ...................................... 90

Chat View ...................................... 90

Send Chat Message ...................... 90

Switch View ................................... 91

View Member List .......................... 91

Disable Chat Message Tone ......... 94

Received Messages ...................... 94

Exit Chat ........................................ 94

Alarm Clock ..................................... 95

Set an Alarm.................................. 95

Show Alarm Status ........................ 96

Call Related Features...................... 97

Show Battery Meter ....................... 97

Restrict My Phone Number ........... 97

Call Forwarding ............................. 97

Call Waiting..................................100

Call Barring ..................................100

Phone Setup...................................103

Adjust Ring Volume......................103

Ring or Vibrate .............................103

Downloadable Ring Tone.............103

Set Ringer Tone...........................104

Set Alarm Ringer Tone.................104

Set Message Alert Tone...............104

Message Popup Alert...................105

Quick Access Setup.....................106

Phone Lock ..................................106

Adjust Contrast ............................107

Require SIM Card PIN .................107

Change SIM PIN Code.................107

Change SIM PIN2 Code...............108

Unblocking Your V101 Personal

Communicator ..........................108

New Security Code ......................108

Extended Menus ..........................109

Show Time and Date....................109

Set Time and Date .......................109

Set Time Format ..........................109

1039b80o.book Page 5 Monday, December 17, 2001 2:00 PM

Backlight.......................................109

Language Selection .....................110

Battery Saving Mode....................110

Select Keypad Tones...................110

Phone Status................................110

Network Selection..........................112

Change Band ...............................112

Available Networks.......................113

Network Search............................113

Preferred Networks ......................114

Find New Network........................115

Call Meters Menu ...........................115

Show Call Charges ......................115

Show Call Timers .........................116

Set Audible Call Timers................116

Set In-Call Display........................116

Call Charge Settings ....................117

Lifetime Timer ..............................118

Calculator .......................................118

Perform Basic Mathematical

Calculations ..............................119

Convert Currency .........................119

Quick Access Menu ......................120

Add Features to the Quick

Access Menu............................ 121

Add or Edit a Quick Access

Voice Tag ................................. 121

Delete a Quick Access Voice

Tag ........................................... 122

Games ............................................ 123

Closing and Saving a Game........ 123

Towers of Hanoi .......................... 123

Baccarat ...................................... 124

Bricks........................................... 126

Special Symbols............................ 128

Troubleshooting............................ 130

Use and Care ................................ 134

Motorola Limited Warranty........... 149

Product Registration..................... 159

Wireless Phone Safety Tips ......... 161

Index............................................... 165

1039b80o.book Page 6 Monday, December 17, 2001 2:00 PM

Indice

Altri manuali Motorola PDA

Motorola

Motorola FR6074 Manuale utente

Motorola

Motorola Organizer Manuale utente

Motorola

Motorola MC319Z-GL4H24E0W Istruzioni di montaggio

Motorola

Motorola MC70 - Enterprise Digital Assistant Manuale utente

Motorola

Motorola MC55A0 Manuale utente

Motorola

Motorola MC75A Manuale utente

Motorola

Motorola MC67 Istruzioni di montaggio

Motorola

Motorola Talkabout T900 Manuale utente

Motorola

Motorola MC55 - Enterprise Digital Assistant Manuale utente

Motorola

Motorola Talkabout T900 Manuale utente

Motorola

Motorola MC55 - Enterprise Digital Assistant Manuale utente

Motorola

Motorola MC55A0 Manuale utente

Motorola

Motorola MC35 EDA Manuale utente

Motorola

Motorola MC75A Istruzioni di montaggio

Motorola

Motorola MC92N0 Manuale utente

Motorola

Motorola Timeport P935 Manuale utente

Motorola

Motorola MC55 - Enterprise Digital Assistant Manuale utente

Motorola

Motorola MC55 - Enterprise Digital Assistant Istruzioni di montaggio

Motorola

Motorola MC70 - Enterprise Digital Assistant Manuale utente

Motorola

Motorola MC70 - Enterprise Digital Assistant Guida di riferimento

Motorola

Motorola Personal Communicator Manuale utente

Motorola

Motorola MC45 Istruzioni di montaggio

Motorola

Motorola MC55 - Enterprise Digital Assistant Manuale utente

Motorola

Motorola MC70 - Enterprise Digital Assistant Guida rapida alla configurazione

Manuali PDA popolari di altre marche

SPOT

SPOT SPOT Manuale utente

Palm

Palm handheld Manuale utente

Winmate

Winmate E500QK Manuale utente

Getac

Getac PS236 Manuale utente

Sharp

Sharp CE-1600P Manuale utente

HTC

HTC PHAR100 Manuale utente

Mindeo

Mindeo M40 Manuale utente

Acer

Acer n30 Manuale utente

ASCOM

ASCOM 9D24 EX Manuale utente

Unitech

Unitech PA520BTNF Manuale utente

HandHeld

HandHeld Nautiz X3 Manuale utente

Casio

Casio PALM Manuale utente

Sharp

Sharp TM-20 Guida rapida

Atid

Atid AT870 Manuale utente

AML

AML M7225 Manuale utente

Audiovox

Audiovox Maestro Manuale tecnico

Casio

Casio PV-750 Plus Manuale di istruzioni e di sicurezza

Unitech

Unitech PT630 Manuale utente
