MP-Man TS 302 Manuale utente

EN MP3 & Video Player with Touchscreen Control

Instruction Manual

Please read this instruction carefully before the operation

For Model No.

TS302

Page 2 Table Of Contents

English

ÂTable of Contents

THANK YOU.....................................................................................................................................5

Package Contents ..........................................................................................................................5

Features............................................................................................................................................5

CONTROLS AT A GLANCE..............................................................................................................6

GETTING STARTED...........................................................................................................................8

Charging the Battery......................................................................................................................8

Charging with a Computer ...........................................................................................................8

Turning the Player On/Off ..............................................................................................................8

Resetting the Player ........................................................................................................................9

Using the Touchscreen Controls ....................................................................................................9

Installing a microSD Memory Card...............................................................................................9

MAIN MENU.................................................................................................................................. 10

Main Menu Controls .....................................................................................................................10

MUSIC MODE................................................................................................................................ 11

Music Browser Controls................................................................................................................. 11

Now Playing Controls (Music Playback).....................................................................................12

Quick Option Menu ...........................................................................................................13

Page 3 Table Of Contents

English

VIDEO MODE ................................................................................................................................ 15

Movie Browser Controls ................................................................................................................15

Movie Playback Controls .............................................................................................................16

PHOTO MODE ............................................................................................................................... 17

Photo Browser Controls.................................................................................................................17

Photo Viewer Controls .................................................................................................................. 17

Quick Option Menu ...........................................................................................................18

RADIO MODE................................................................................................................................ 19

Radio Tuning Controls...................................................................................................................19

Quick Option Menu ...........................................................................................................20

TEXT MODE ...................................................................................................................................22

Text Browser Controls ....................................................................................................................22

Text Reader Controls.....................................................................................................................22

Quick Option Menu ...........................................................................................................23

EXPLORER MODE ..........................................................................................................................25

Explorer Controls ...........................................................................................................................25

Quick Option Menu ...........................................................................................................25

SETTING MODE ............................................................................................................................. 27

Page 4 Table Of Contents

English

DV MODE ...................................................................................................................................... 29

CAMERA MODE ...........................................................................................................................30

CALENDAR MODE ........................................................................................................................ 31

CLOCK MODE...............................................................................................................................32

MPMANAGER ...............................................................................................................................33

SPECIFICATIONS...........................................................................................................................34

TROUBLESHOOTING & SUPPORT...................................................................................................35

Page 5 Thank You

English

ÂThank You

Congratulations on your purchase of the Video & MP player. This manual is designed to help you easily

set up and begin using your new player right away. Please read this manual carefully and retain it for

future reference.

Package Contents

Please make sure that the items shown below are

included in the package. Should an item be miss-

ing, please contact the local retailer from which you

purchased this product.

Video & MP player

USB Cable

Instruction Manual & Documentation

Professional Stereo Earphones

Protective Pouch

Thispackagemaycontainplasticbagsorothermate-

rials that pose a hazard to children. Be sure to safely

disposeofallpackingmaterialsafteropening.

Features

Integrated ﬂash memory

Intuitive touchscreen control

.” TFT Display

Plays music, video, photos and text

ID and LRC support for song and synchronized

lyric information display

microSD card slot for easy memory capacity

upgrades (microSD card not included)

Integrated FM Radio

Integrated . Mega Pixel Camera

USB . Hi-speed for fast ﬁle transfers

Page 6 Controls At A Glance

English

ÂControls at a Glance

Left View

1. Volume Up button <UP>

2. Volume Down button <DOWN>

3. microSD Card slot

Load a microSD memory card here to upgrade

the memory capacity of the player.

Front View

4. Speaker

5. LCD touchscreen

Tap the display with your nger to activate the

on-screen control.

6. Power/Enter button

Press and hold the button to

power the palyer on or off.

<ENTER>

7. LED indicator

8. Menu button <MENU>

Rear View

9. Camera LENS

10. Reset button <RESET>

Bottom View

11. USB Port/Charge

Connect to a computer to transfer media les to

the player.

12. 3.5mm Headphone Jack

Page 7 Controls At A Glance

English

Page 8 Getting Started

English

ÂGetting Started

Charging the Battery

Your player has an integrated rechargeable battery.

Upon initial use, the battery should be charged fully

to ensure optimal performance and battery life.

If the player has not been used in a while, the

battery may need to be recharged overnight (about

 hours).

The battery used in this device may present

a ﬁre or chemical burn if mistreated. Do not

disassemble, incinerate, or heat the battery.

Do not leave the battery in a place subject

to direct sunlight, or in a car with its win-

dows closed.

Do not connect the player to a power source

other than that which is indicated here or on

the label as this may result in the risk of ﬁre

or electric shock.

Charging with a Computer

Your player can be charged through a USB com-

puter connection. Use the supplied USB cable to

connect the player to a high-power USB port of a

computer. The computer must be powered on and

not in sleep mode.

When the player is connected and charg-

ing, a USB symbol will be displayed on the

player’s screen.

Turning the Player On/Oﬀ

To turn the player on, press and hold the

<ENTER> button until the screen turns on.

To turn the player oﬀ, press and hold the

<ENTER> button until the screen turns oﬀ.

Page 9 Getting Started

English

Resetting the Player

Reset the player if it should freeze and not respond

or otherwise malfunction.

1. Disconnect your player if it is connected to a

computer.

2. Use a paper clip to gently press the <RESET>

button located on the rear of the player.

Using the Touchscreen Controls

Your video MP player comes equipped with an

easy-to-use touchscreen which allows access to the

player’s functions. Use your ﬁnger tip or the stylus

to tap the area of the screen where a control icon is

displayed. If you tap and hold an icon, it will register

as a continuous button press.

To avoid damaging the screen, do not

touch it with excessive force or with

any object other than your nger or the

stylus. For best response, make sure

your hands are clean before using the

touchscreen controls.

Installing a microSD Memory

Card (optional)

You can upgrade the memory capacity of your

player by adding microSD memory card.

Insert microSD card into the slot as shown in the

illustration below.

This player supports memory cards up

to 2GB in size.

Page 10 Main Menu

English

ÂMain Menu

When you turn on the player, you will see the Main

menu.

From the Main menu, you can access each of your

MP player’s function modes. These modes are:

Music Browse and play music

Video Browse and play movies

Photo Browse and view pictures

Radio Listen to FM radio broadcasts

Text Browse and read text ﬁles

Explorer Browse all ﬁles

Setting Adjust the player’s options

DV Record video clips

Camera Capture still images

Calendar Launch the calendar program

Clock Set the internal clock display

Main Menu Controls

Each function mode is represented by an icon on

the Main Menu screen. To enter a mode, tap the

icon with your ﬁnger.

You may also use the player’s standard controls to

access each mode:

Press the <UP> or <DOWN> button to move the

selection.

Press <ENTER> to conﬁrm.
