MSI M610 Series Manuale utente

2-1

Congratulationson purchasingtheMSIM610SeriesNotebook

PC!

Thisfirstchapterprovidesageneral introduction of your Note-

bookPC, introducingyoutothehardwarecomponents. Read

on tolearnmoreaboutthepowerfulfeatures andmultimedia

functionof yournewNotebookPC.

GettingStarted

1-2

M610SeriesNotebookPC

First,unpacktheshipping carton and check allitemscarefully.Ifanyitem

containedisdamagedormissing,please contactyourlocaldealerimmedi-

ately.Also,keeptheboxandpacking materialsincaseyou needtoshipthe

unit inthefuture.

Thepackageshouldcontainthefollowingitems:

OneNotebook PC

RecoveryCDs

WarrantyCard

High-capacityLi-Ionbatterypack

ACadapterandpowercord

Unpacking

1.1BeforeYou Begin

1-3

FeaturesandBenefits

Next GenerationCPU Support. YourNotebook PC isequipped withone

ofthe latestCPU (centralprocessingunit)namelytheAMD Mobile

AthlonXP-Mforexcellentsystemperformance andultimatemobilefunc-

tion.

Integrated Wireless LAN Solution. Thecomputerispre-installedwithan

802.11gwirelessLANthatallowsyou toroambetweendifferentroomsin

the office or athomeandoffermaximumnetworkbandwidth.

USB 2.0Support. Thecomputer has fourUSB2.0portsthatsupport data

transfer rateupto480Mb/s. TheUSBstandardallowsyoutoconnectup

to127devicesthroughthesingleinterface,includingmouse,keyboard,

printer, harddiskdrive,digitalcamera,andmore.

Communication Ports. Support 56KFax/MODEM(Cablesize atleast 26

orabove).Inaddition,sharing files andprinterscanbeeasy tasks.

Memory. Thecomputerprovides twomemoryslotsthatallowsyou to

expandthememorysizeupto2GB.

Innovative Direct PlayFunction. Without turning onthesystem, you can

enjoyyour favoritemultimediawithDVD, video CD, audioCD,MP3withits

unparalleledsound system(using thewireless remotecontrol).

15.4 WideScreen. Experiencethe greatestvisualpresentation onyour

Notebook PC!Youcanenjoyextremeentertainmentwiththe15.4”wide

screencolorTFT LCD.

1-4

M610SeriesNotebookPC

Top-openView

Thissectionprovides the multi-viewsofyour NotebookPC,andbrieflyintro-

ducesthe functionofeachcomponent.

Press the CoverLatchtoopenthetopcover (see page 1-6), and you canfind

the mainoperatingareaofyourcomputer.

1.2QuickComponentsGuide

1-5

DisplayPanel

The15.4”widescreencolorTFT LCDscreendisplaystheoutputofthe

computer.

Quick Launch Buttonsand PowerButton:

- PowerButton: toturnthecomputerpowerON andOFF

- Quick LaunchButton: Turnson/off the wirelessLAN function

Keyboard

The built-inkeyboardprovidesallthefunctions ofafull-sized 87/88-key key-

board(see UsingKeyboard inChapter 2for moreinformation).

Touchpad

Thepointingdeviceofthecomputer(see Using Touchpad inChapter2for

moreinformation).

StereoSpeakers

Thenext-generation high qualityspeakersoutputthesound fromthe

computer.

LCMPanel

The innovative “DVDDirectPlay”functionwithabuilt-indisplaypanelbrings

you awholenewmultimediaexperience.

1-6

M610SeriesNotebookPC

FrontView

VolumeIncrease-DecreaseController

Press “+”buttontoincreasevolumeleveland press “-”todecreasevolume

level.

CoverLatch

Slidethisbuttontowardtherighttoopen the topcover.

DisplayPanel

It showsthestatusofdirectplayingcontrol.

FrontPanel ControlButtons

The directplay bar.Thefollowingtableshowsthe KeyDefinition.

Knowingthe componentsonthefrontsideof yourcomputer.

OK/Enter ---

Play/Pause

CH-/CH+

Power

---

↓

Power

↓

Menu Menu

Power

Key AV_MODE

(DVD)

DVD LCD

---

Eject/Stop

1-7

ConsumerInfrared

Itisused toreceivetheWireless RemoteControl’ssignal.

AudioPort Connectors

- LineOut isused forspeakersorheadphones;

- MIC isusedformicrophones.

LineOutMIC

1-8

M610SeriesNotebookPC

Right-sideView

Knowingthecomponentsontheright sideofyourcomputer.

StatusLED

- BatteryStatus (Green/Orange):ON (Green) - batteryischarged

fully; ON(Orange)-batteryischarging; Blinking(Orange)-battery

loworbad; Off-the ACadapter isdisconnected.

- PowerOn/Off/Suspend (Blue): Blinking- systeminsuspend mode;

ON -systemfullyon;OFF-systemoff.

- WirelessLAN (Green): ON- wireless LANenabled;OFF- wireless

LANdisabled.

PCCardSlot

Thecomputerprovides aPC cardslottosupport oneType-II PC cardfor

expansion functions,such as asecond LAN orWLAN card,modemcard,

memorycard, etc.

Vent

Theventisdesignedtocoolthe system.DONOTblockthe vent.

S-VideoConnector

ByusingaSuperVHS(S-Video) cable,thisconnector allowsyoutoconnect

atelevision(NTSC/PALsystem)touseas acomputerdisplay.

1-9

USB Ports: The USB 2.0portsallowyou toconnectUSB-interface peripheral

devices, suchasthemouse,keyboard,modem,externalharddiskmodule,

printer, andmore.TherearetwoUSBportsonthe rightside ofyour laptop.

VGAPort

The15-pinD-sub VGAport allowsyou toconnect anexternalmonitor or other

standardVGA-compatibledevice (suchasaprojector).

1-10

M610SeriesNotebookPC

Left-sideView

Knowingthecomponentsonthe left sideofyourcomputer.

Vent

Theventisdesignedtocoolthe system.DONOTblockthe vent.

PowerConnector

Toconnect theACadapter whichsuppliespower tothe computer.

USBPorts

TheUSB 2.0portsallowyou toconnectUSB-interfaceperipheraldevices,

such as themouse,keyboard,modem,externalharddiskmodule,printer,

and more.

RJ-45 Connector

The 100/10EthernetconnectorisusedtoconnectaLANcablefor network

connection.

RJ-11Connector

Thecomputerprovidesabuilt-inmodemthat allowsyoutoconnectanRJ-11

telephonelinethroughthisconnector. Withthemodem,you canmakeadial-

upconnectionorsend/receive faxes.
