MSI PF560 Istruzioni operative

MSI PF560

TFT Monitor

User Operation Guide

MSI PF560

Features:

•Playback of photo, music, or video files stored in data storage

devices through dual High-Speed USB 2.0 port or various

card-reader port, or internal memory.

•Supported data storage devices include USB disk, memory

card, MP3 player, hard disk, etc.

•Dual High-Speed USB 2.0 can be configured as OTG, Host, or

Device

•Supports up to 8000x8000 mega pixel image files (JPEG

format)

•Compatible with most digital cameras stored JPEG images

including Motion JPEG files

•Automatic slideshow with multiple transition effects and

adjustable display time

•Dedicated hardware JPEG decoder for super fast JPEG display

•Plays slideshow with MP3 music on in the background

•Plays MP3 music through the integrated speakers

•Plays MPEG-I, II, or IV video files (including DIVX) stored on

supported memory cards or external USB devices.

•Supports SD, SM, MS, MMC, and XD memory cards

•User friendly on-screen display

•Build in alarm clock and calendar

•Supports default alarm sound or user-selected alarm music.

•Supports firmware upgrade via USB device or memory cards.

MSI PF560

Buttons

UP, or Turn on the info bar during

playback

DOWN

LEFT

RIGHT

Enter Select items, Execute commands on the

info bar.

OSD Turn-on/off menu or Function bar

Remoter (Optional)

DOWN

LEFT

RIGHT

Enter Select items, Execute commands on

the info bar

OSD Turn-on/off menu or Function bar

Mute Mute/Unmute audio

Vol + Audiovolumeplus

Vol - Audio volume minus

Play/Pause Playback a multi-media file/ Pause

Stop Stopplaying

Rotate Rotate the picture 90 degree

Zoom Zoom in the picture

Bluetooth Enter into bluetooth navigation mode

Photo Enter into photo auto playback mode

Music Enter into music auto playback mode

Movie Enter into movie auto playback mode

File Enter into File list display screen

Combo Enter into Photo +music auto playback

mode

MSI PF560

User Operation Guide:

1. Play List Screen

With USB device/Memory cards rightly inserted into the Digital

Picture Frame: volume label list screen displays. (Exhibit 1)

Actions:

a) Press /to select a volume label, then press ENTER to

enter the filelist.

b) Press /to select a file/folder, then press to enter the

folder or press ENTER to play the file. (Exhibit 2)

c) Press to return to previous directory.

d) Press ENTER to enable the command tool bar.

Exhibit 1. Volume Label List

MSI PF560

Exhibit 2. File Play List

1.1 File management screen

Action:

a) Select a file to copy, press on the original file. A will

appear in front of the file name indicating the file has been

selected.

b) Press /to locate and enter the copy-to destination

directory.

c) Press OSD and Cancel/Paste/Del menu displays on the

screen. (Exhibit 3)

d) Select Paste and press ENTER to paste the file. (Exhibit 4)

e) Press ENTER (ok) to return to the file list.

Exhibit 3. File Operation

MSI PF560

Exhibit 4. File Copy

2. Playback screens

Actions:

During Playback, press ENTER and info bar displays on the screen.

Then select a function item by pressing /, and press ENTER to

perform the corresponding function. (Exhibit 5)

Press ENTER to enable command tool bar.

2.1 Movie playback screen

Exhibit 5. Video Playback with Info Bar

Info bar layout and functions:

MSI PF560

•Status indicator

•Playback time

•Play/Pause

•Stop

•Previous movie clip

•Fast backward

•Fast forward

•Next movie clip

•Show file info

•Zoom

•Sub-title switch

a) It can play film and AVI file.

b) For management , please found the other films on different files

except AVI file

2.2 Picture display screen

Exhibit 6. Picture Playback with Info Bar

Info bar layout and functions:

•Status indicator

•Play/Pause

•Stop

•Picture rotate

•Zoom

•Previous picture

•Next picture

MSI PF560

•Show file info

•Picture thumbnail display

•Picture resolution display

2.3 Music playback screen

Exhibit 7. Music Playback with Info Bar

Info bar layout and functions:

•Status indicator

•Play/Pause

•Stop

•Previous song

•Fast backward

•Fast forward

•Next song

•Show file info

•ID3 tag display

•Play mode (Standard, Repeat one, Dir Directory)

MSI PF560

3. Calendar

Exhibit 8. Calendar Screen

Actions:

Press OSD to enable command tool bar. Select Calendar to

enter Calendar Screen. Press / to move to the previous or

next month.

Display Information:

•Monthly calendar display

•Picture display

•Time display

•Alarm display

MSI PF560

4. Alarm screen

Exhibit 9. Alarm Screen

When alarm goes off, the screen displays current date and time.

(Exhibit 9) Press any button to return to the previous mode.

5. Setup Menu

Press Menu to enable command tool bar. Select Setup to enter

Setup Screen. (Exhibit 10)

Actions:

a) Press /to select an item

b) Press or ENTER to enter the sub-menu.

c) Press ENTER to choose the setup.

d) Press to return.
