Multitech MultiModem MT2834ZDX Series Manuale utente

MT2834ZDX-Series

External Data/Fax Modem

Quick Start Guide

MT2834ZDX-Series Quick Start Guide

Quick Start Guide

MT2834ZDX-Series

82010220 Rev. A

This publication may not be reproduced, in whole or in part, without prior expressed written

Multi-Tech Systems, Inc. makes no representations or warranties with respect to the contents

hereof and specifically disclaims any implied warranties of merchantability or fitness for any

particular purpose. Furthermore, Multi-Tech Systems, Inc. reserves the right to revise this

publication and to make changes from time to time in the content hereof without obligation of

Multi-Tech Systems, Inc. to notify any person or organization of such revisions or changes.

Revision Date Description

A 09/15/03 Initial release.

Patents

This device is covered by one or more of the following patents: 6,031,867; 6,012,113;

6,009,082; 5,905,794; 5,864,560; 5,815,567; 5,815,503; 5,812,534; 5,809,068;

5,790,532; 5,764,628; 5,764,627; 5,754,589; 5,724,356; 5,673,268; 5,673,257;

5,644,594; 5,628,030; 5,619,508; 5,617,423; 5,600,649; 5,592,586; 5,577,041;

5,574,725; 5,559,793; 5,546,448; 5,546,395; 5,535,204; 5,500,859; 5,471,470;

5,463,616; 5,453,986; 5,452,289; 5,450,425; D353,598; 5,355,365; 5,309,562; 5,301,274.

Other patents pending.

Trademarks

Multi-Tech, and the Multi-Tech logo are trademarks of Multi-Tech Systems, Inc. All other brand

and product names mentioned in this publication are trademarks or

registered trademarks of their respective companies.

Technical Support

Country By Email By Phone

U.S. and Canada: [email protected] (800) 972-2439

World Headquarters

Multi-Tech Systems, Inc.

2205 Woodale Drive

Mounds View, Minnesota 55112 U.S.A.

(763) 785-3500 or (800) 328-9717 - Fax (763) 785-9874

http://www.multitech.com

MT2834ZDX-Series Quick Start Guide

Getting Started

This guide shows you step-by-step how to set up your Multi-

Tech MT2834ZDX–Series modem.

For detailed information on how to install, test, and use your

modem, see the User Guide, located on the MT2834ZDX

system CD provided with your modem.

Safety Warnings

•Use this product only with UL- and CUL-listed computers (US).

•Never install phone wiring during a lightning storm.

•Never install a phone jack in a wet location unless the jack is

specifically designed for wet locations.

•Never touch uninsulated phone wires or terminals unless the

phone line has been disconnected at the network interface.

•Use caution when installing or modifying phone lines.

•Avoid using a phone during an electrical storm; there is a risk

of electrical shock from lightning.

•Do not use a phone in the vicinity of a gas leak.

•To reduce the risk of fire, use only 26 AWG or larger

telephone line cord.

We Supply

•The MT2834ZDX-Series data/fax modem

•A DC power supply module

•One set of four plastic feet

•One telephone cable

•A system CD containing modem drivers, the User Guide,

Phone Tools (a data communications program), and Acrobat

Reader

MT2834ZDX-Series Quick Start Guide

Modem Installation

Step 1: Attach the Self-Adhesive Feet

The modem comes with a set of self-adhesive plastic feet,

which you can optionally attach to the modem. To install, simply

peel them from their paper strip and press them into the

recesses on the bottom of the modem.

Step 2: Connect the Modem to Your System

Turn off your computer. Place the modem in a convenient

location, and then connect it to your computer’s serial port, the

phone line, AC power, and your phone.

PWR RS232 PHONE LINE

MT2834ZDX-Series Quick Start Guide

RS232 Connection

Plug one end of the serial cable into the RS232 connector on

the modem, and the other end into a serial port connector on

your computer, such as COM1 or COM2.

LINE Connection

Plug one end of the phone cable into the MT2834ZDX’s LINE

jack and the other end into a phone line wall jack.

Note: The LINE jack is not interchangeable with the PHONE

jack. Do not plug the phone into the LINE jack or the line cable

into the PHONE jack.

PHONE Connection

You may optionally plug a telephone into the PHONE jack. This

jack is provided as a convenience; you may also plug a

telephone into a duplex jack inserted into your wall jack.

POWER Connection

Plug the power supply module into an AC power outlet or power

strip. Plug the power supply’s cable into the POWER jack on

the modem.

Note: Use only the power supply supplied with the

MT2834ZDX. Use of any other power supply will void the

warranty and could damage the modem.

Power-On Test

Test the modem by turning it on (a power on/off switch is

located on the right side). When you apply power, the modem

performs a diagnostic self-test, indicated by the speed

indicators flashing in sequence for a second or two, after which

the 28 indicator should light. If this does not happen, check that

the power switch is on, the power supply is solidly connected,

and the AC outlet is live. If these measures do not work, see

Chapter 4, “Troubleshooting” in your User Guide.

MT2834ZDX-Series Quick Start Guide

Step 3: Install the Modem Driver

If you use Windows 98+, you must install the modem driver,

which is installed using the Windows Plug and Play feature.

Follow the four-step procedure below. If you use another

operating system, see the User Guide.

1. Make sure your modem is connected properly, and then turn

on your computer. Windows should detect your new modem

and open the Install New Modem wizard.

2. Insert the system CD, and then click OK.

3. Windows installs and configures the modem.

4. Click Finish to exit.

For Windows NT, the Install New Modem wizard presents one

additional prompt before Step 2. At this prompt, select Don’t

detect my modem; I will select it from a list, and then click

Next.

A dialog box with a list of manufacturers and a list of modem

models appears. Select your modem. Continue with Step 2

above.

Note: If Windows cannot identify your modem (for instance, if it

identifies your modem as a “Standard Modem”), click Change.

A dialog box with a list of manufacturers and a list of modems

appears.

Step 4: Install Data Communications Software

Data communications software is designed to send and receive

messages. Multi-Tech includes PhoneTools communications

software with your modem. However, the modem will work with

most data communications software. To install PhoneTools,

insert the CD into the CD-ROM drive; click the PhoneTools icon.

You will be asked to choose your language. The software

automatically loads onto your PC.

MT2834ZDX-Series Quick Start Guide

82010220
