Muratec MFX-1450 Manuale utente

Quick Reference

Murata Machinery, Ltd. 2007

Printed in Chine 2007-05

Part Number: DA7-909K0-60

MAI order number: OMF525QRG

031981 92727 7

3301 East Plano Parkway, Suite 100

Plano, Texas 75074

Muratec America, Inc.

http://www.muratec.com

DA7-909K0-60.indb 1 2007/04/27 13:41:17

Contents
Basic Copy ........................................................................................1
Duplex Copying................................................................................2
Sorting ..............................................................................................8
Card copy..........................................................................................9
Soft Key Programming ..................................................................11
Registering an Address Book location ..........................................13
Sending a fax..................................................................................18
Sending to an e-mail address ........................................................21
Adding a text message to your e-mail...........................................24
Scanning to a network folder ........................................................27
Scanning to an FTP server ............................................................31
Color scan to print..........................................................................35
Clearing a document jam in ADF..................................................36
DA7-909K0-60.indb   1 2007/04/27   13:41:17

Basic Copy

Set the document.

ADF �Face UP Document glass �Face DOWN

The document glass is available only for the MFX-2050 and MFX-1450.

Press <COPY>.

Set each copy setting as necessary. (Ex. Document type, Contrast.)

Enter the number of copies using the numeric keys.

You can set up to 99 copies. If you make an incorrect entry, overwrite it

with the correct entry.

Press <Start>.

NOTE

To stop copying, press <Stop>.

Mixed Original Copying

Letter and legal-sized paper can be inserted into the ADF and the scanner

will automatically detect the paper size. The output will match the original

paper size if the appropriate paper has been loaded into the cassettes.

DA7-909K0-60.indb 1 2007/04/27 13:41:18

Duplex Copying

One-sided copying of a duplex document (2 -->1 sided)

1Scan the front side. 2Turn over the document

and scan the backside. 3The scanned data temporarily

saved in the memory will be

sorted and printed.

To ADF To ADF

Set the front side of the duplex document in the ADF.

ADF �Face UP Document glass �Face DOWN

Press <COPY>.

Press [Others], [DuplexCopy]. Then press [2 -> 1 sided].

DA7-909K0-60.indb 2 2007/04/27 13:41:18

NOTE

If the duplex printing unit is not installed, press [Others], [DuplexScan].

Then press [ON].

Press [Enter] twice to return to the standby display.

Press <Start>.

The front side of the duplex document will be scanned.

When the following display is shown, place the backside of the duplex

document in the same direction as the front side and press <Start>.

Duplex copying of a duplex document (2 --> 2 sided)

This mode will convert two-sided originals into two-sided documents.

NOTE

•The duplex printing unit is required.

•For details of duplex copy, please see Chapter 2, “Copy Functions” in the

MFP User’s Guide.

Press <Copy>

Set the front side of the duplex document in the ADF.

Press [Others], [DuplexCopy].

DA7-909K0-60.indb 3 2007/04/27 13:41:19

Press [2 -> 2 sided].

•If you set any advanced functions, proceed to step 5.

•If you do not set any advanced functions, proceed to step 7.

Press [Advance].

(1) Press [Bind] to set document bind position.

• Press [DuplexCopy] to return to the duplex copy display.

(2) Press [Right&Left] or [Top].

(3) Press [Enter].

Press [Enter] twice to return to the standby mode.

Press <Reset> to cancel the duplex copy settings.

Press <Start>.

Scan the front side of the duplex document.

DA7-909K0-60.indb 4 2007/04/27 13:41:19

When the following display is shown, set the document in the correct direc-

tion and press <Start>.

•Be sure to set the document in the correct direction. (See the table on

page 2-17 in the MFP User’s Guide.)

Duplex copying of a one-sided document (1 --> 2 sided)

NOTE

•The duplex printing unit is required.

•For details of duplex copy, please see Chapter 2, “Copy Functions” in the

MFP User’s Guide.

Press <COPY>.

Set the document.

Press [Others], [DuplexCopy].

Press [1 -> 2 sided].

•If you set any advanced functions, proceed to step 5.

•If you do not set any advanced functions, proceed to step 7.

Press [Advance].

DA7-909K0-60.indb 5 2007/04/27 13:41:19

(1) Press [Bind] to set the binding position.

• Press [DuplexCopy] to return to the duplex copy display.

(2) Press [Right&Left] or [Top].

(3) Press [Enter].

Press [Enter] twice to return to the standby mode.

Press <Start>.

Press [Yes] while the document is being scanned.

Selecting [No] will cause one-sided document output.

After the document has been scanned, set the next document.

DA7-909K0-60.indb 6 2007/04/27 13:41:19

Press [Next Doc].

•The Next Doc setting can be deleted by pressing [Complete].

•To scan another document, press [Yes] while the document is being

scanned.

DA7-909K0-60.indb 7 2007/04/27 13:41:19

Sorting

Copied documents can be collated into proper page order. This eliminates

the need to manually sort documents after copying.

Sort OFF

The paper is sorted by page.

Sort ON

The paper is collated into sets.

To enable/disable automatic sorting:

“ON” and “OFF” toggle every time you press [Sort].

DA7-909K0-60.indb 8 2007/04/27 13:41:20
