Muratec MFX-C2280 Manuale utente

Muratec America, Inc. 3301 East Plano Parkway, Suite 100, Plano, Texas 75074

For more information on Muratec products or services,

call (469) 429-3300 or visit our web site at www.muratec.com

MK3243

BUSINESS-CLASS DOCUMENT SOLUTIONS

MFX-C2280/C2880/C3680

COPY

Feature Overview

MFX-C2280

MFX-C2880

MFX-C3680

table of contents

Card Shot Copy Function .......................................... 1

Card Shot Copy Function ........................................ 2

Confirm The User Settings ....................................... 4

Make a Card Shot Copy ......................................... 7

Setting the Home Screen as the Startup Screen ..................... 9

Customizing Copy Screen Function Keys ............................. 10

Main Screen Default Setting — Enlarge Display/Normal View ............. 13

Quick Copy Screen .............................................. 15

Program Quick Key Settings 1 & 2 .................................. 18

Booklet Creation – Booklet Legal using FS-534

(Letter size 8.5" x 11" to legal size 8.5" x 14") ......................... 22

Booklet Legal — Booklet to Booklet using FS-534 ..................... 24

Adding Menu Keys to the Home Screen .......................... 27

Determining the MFP’s IP Address .................................. 30

Determining the MFP’s IP Address #2 ............................... 32

Copy Protect ................................................... 33

Change Default Copy Settings ..................................... 37

PROGRAM — formerly known as “Mode Memory” ..................... 39

Removing Highlighter Marks ....................................... 42

To Recall the Program .......................................... 44

Blank Page Removal — Copy ..................................... 45

Real Time Preview of Copy Job with Finishing Settings .................. 47

Changing the Background of Home Screen ........................ 49

Copying on Tabs ................................................ 51

Setting Up Account Track ......................................... 53

bizhub C754 Series/C554 Series/C364 Series/754 Series

Copy job shops

Card Shot Copy Function

WHAT & WHY

The Card Shot function on the bizhub MFP enables a user to separately scan the

front and back of a card, and then copy them on to one sheet. Use this function

to copy the card at 100% (x1.0) or enlarge (Full Size) the image to ﬁt the paper size

selected. Using the Card Shot function provides several beneﬁts including paper

conservation. The Card Shot function keeps each separately scanned side together,

which ultimately reduces the need to keep track of multiple sheets.

When using this feature, you can position the card on the same physical location

when scanning both sides — the MFP recognizes that it is a front and back scan

and positions the image on the paper according to its size.

APPLICATION

Anyone who has been admitted to a hospital or needed to visit the doctor's office

knows that an insurance card always needs to be produced. Office personnel take

the insurance card and make a copy, or two. The Card Shot function allows the office

personnel to make their copy onto one sheet, rather than several sheets. Other places

the Card Shot would be helpful include the DMV or a car dealership where a license

and other identification materials have to be produced.

HOW

Pre-requisite

To complete the steps listed for the Card Shot function, conﬁrm 8.5" x 11" paper

isloaded LEF (Long Edge First) in the top drawer, and a business card, hotel room

key, insurance card or driver's license is available. First, ensure that Administrator

Security Level 1 is enabled, which provides access to the Card Shot function without

having to enter the Administrator Mode. Administrator Security Level set to Prohibit

disallows changes to the Card Shot function in User Settings.

bizhub C754 Series/C554 Series/C364 Series/754 Series

Copy job shops

CARD SHOT COPY FUNCTION

Set the Administrator Security Level

1. Press Menu Button.

2. Touch Utility Icon.

3. Touch Administrator

Settings and enter

1234567812345678.

4. Touch OK.

5. Touch Security Settings.

bizhub C754 Series/C554 Series/C364 Series/754 Series

Copy job shops

6. Touch Administrator

Security Levels.

7. Touch Level 1.

8. Touch OK.

9. Touch Close 3 times.

HEALTHCARE

VERTICAL

MARKETS

Useful Tips:

• Copy double-sided insurance cards and driver’s licenses

efficiently and with ease of use.

bizhub C754 Series/C554 Series/C364 Series/754 Series

Copy job shops

CONFIRM THE USER SETTINGS

1. Press Menu Button.

2. Press Utility Icon.

3. Touch User Settings.

4. Touch Copier Settings.

bizhub C754 Series/C554 Series/C364 Series/754 Series

Copy job shops

5. Touch (Down) Arrow key

2 times (this will take you

to the third page).

6. Touch Specify Default

Tray when APS off.

7. Touch Default Tray

(the Default Tray is #1).

8. Touch (Down) Arrow key

to screen 4.

9. Touch Card Shot Settings

and then Layout.

10. Touch Left/Right

(Upper Half).

bizhub C754 Series/C554 Series/C364 Series/754 Series

Copy job shops

11. Touch Zoom.

12. Touch x1.0.

NOTE: If you select Full

Size, it will enlarge the

image to ﬁt the paper

selected.

13. While you are here, touch

Store Original Size.

14. Let’s set up a button

for a business card:

a. Set X to 3.5.

b. Set Y to 2.

c. Touch Size One button

to lock in settings you

just made.

d. Touch Original

Name under the

Size 1 button.

e. Enter Business Card.

f. Touch OK 3 times and the Close 2 times.

NOTE: Make this setting permanent, create a Shortcut button.

bizhub C754 Series/C554 Series/C364 Series/754 Series

Copy job shops

MAKE A CARD SHOT COPY

The MFP recognizes the standard business card size. You no longer need to manually

enter the stock size into the LCD panel.

1. Press Menu Button

to enter Copy mode.

2. Touch Paper Tab

and select desired

paper source ex.

8.5" x 11" Tray4.

3. Touch Close.

4. Lift the Dual Scanner

orRADF and place card

inthe upper left corner

ofthe platen glass SEF

(Short Edge First).

bizhub C754 Series/C554 Series/C364 Series/754 Series

Copy job shops

5. Touch Application tab.

6. Scroll (right) or press J

Icon to locate Card Shot.

7. Touch Card Shot.

8. Turn ON Card Shot

function.

If you're using a business

card your Xand Yvalues

should be already visible.

a. If you're using another

type of card enter the

X and Y values now

using (–& +).

b. Touch any Size button

to lock in your value.

c. Touch OK

9. Press Start to scan

thefront side.

10. When prompted, flip

card over to back side.

11. Press Start.

12. When prompted, touch Finish and press Start.
