SPECIFICATIONS
KA РУССКИЙ
3
C 510
<0.0005% (0dBFS)
<0.002% (-60dBFS)
IMD Distortion 0.0001%
Signal/Noise Ratio <-123dB (ref. 0dBFS 2V out)
Channel Separation >-115dB (ref. 0dBFS Volume -1dB)
Sample Rate 32kHz to 192kHz (USB and digital S/PDIF)
Frequency Response ±0.5dB (ref. 20Hz - 96kHz @ 192kHz sample rate)
Output Level 2V (ref. input 0dBFS)
INPUT
AES/EBU XLR
SPDIF Coaxial x 1
Optical x 1
HDMI x 2 (2-channel PCM)
USB Class 2 Audio: asynchronous 24/192 support
IR In
Trigger In 12V ±20%
OUTPUT
HDMI Video Out (3D video pass through)
Analogue Unbalanced
Balanced 47 ohms
110 ohms
Trigger Out 12V ±20%
GENERAL
AC Supply 100-240V AC ~ 50/60Hz
Standby Power <0.5W
Idle Power 16W
Unit Dimension (WxHxD) - Gross* 435 x 99 x 309mm
17 1/8 x 3 15/16 x 12 3/16 inches**
Net Weight 4.7kg (10.4lb)
Shipping Weight 5.6kg (12.3lb)
* Gross dimensions include feet, extended buttons and rear panel terminals.
** Non-metric measurements are approximate. NAD Electronics will not assume any liability for errors being made by retailers, custom installers,
cabinet makers, or other end users based on information contained in this document.
Note: Installers should allow a minimum clearance of 55mm for wire/cable management.
