SNR-MPX-8E1-SFP

8E1 + 1Ethernet Fiber Optical Multiplexer

User’s Manual

SNR-MPX-8E1-SFP

8E1 + 1Ethernet Fiber Optical Multiplexer

6/5/2009 Shop.Nag.Ru Page 1 of 16

To users：

：：

：

Thank you for using our products. Before using, please read this Reference Manual

carefully, and keep properly.

Alarm

1. This product cannot be caught in or be affected with damp, for they can make the

performance degressive and even broken.

2. Before fixing this product, please check the model and according to the User s’

Reference Manual.

SNR-MPX-8E1-SFP

8E1 + 1Ethernet Fiber Optical Multiplexer

6/5/2009 Shop.Nag.Ru Page 2 of 16

Contents

CHAPTER 1 GENERAL INTRODUCTION........................................3

1.1

RODUCT

ESCRIPTION

.............................................................................3

1.2

RINCIPLE

HART AND

ESCRIPTION

..........................................................3

1.2.1 Description........................................................................................4

1.3

HARACTERS

............................................................................................4

CHAPTER 2 FUNCTIONS ..........................................................5

2.1

RONT

ANEL

...........................................................................................5

2.1.1 LED...................................................................................................5

2.1.2 Buttons in front panel........................................................................6

2.1.3 Hot line phone (optional port)............................................................6

2.1.4 Front panel DIP definition .................................................................7

2.2

EAR PANEL

.............................................................................................8

2.2.1 Power Supply....................................................................................9

2.2.2 Ethernet (optional component)..........................................................9

2.2.3 Fiber interface.................................................................................10

2.2.4 E1 interface

（

75Ω

：

BNC

）

..........................................................10

CHAPTER 3 PARAMETERS AND INDEX......................................11

3.1

ARAMETERS

..........................................................................................11

3.1.1 Fiber interface.................................................................................11

3. 1.2 E1 interface....................................................................................11

3.1.3 10/100Base-T Port..........................................................................11

3.2

IMENSION

.............................................................................................11

3.3

OWER SUPPLY

.......................................................................................11

3.4

PERATION

ONDITION

...........................................................................12

CHAPTER 4 OPERATION ........................................................13

4.1

QUIPMENT INSTALLATION

.......................................................................13

4.2

UICK INSTALLATION

...............................................................................13

4.3

AUTIONS ABOUT INSTALLATION

..............................................................14

CHAPTER 5 PACKAGE........................................................... 15

SNR-MPX-8E1-SFP

8E1 + 1Ethernet Fiber Optical Multiplexer

6/5/2009 Shop.Nag.Ru Page 3 of 16

CHAPTER 1. GENERAL INTRODUCTION

1.1 Product Description

8E1 + 1Ethernet Fiber Optical Multiplexer can multiplex to 8 E1 signals for transmission

over an optical fiber, resulting in reaching a longer distance without a repeaters and superior

performance compared to copper media.

8E1 + 1Ethernet Fiber Optical Multiplexer is the 8E1 point-to-point optical transport

equipment that uses the FPGA chips and it is easy to upgrade. It is single board structure

and the largest transmission capacity is 8E1. The outer design use the standard 19 inches

rack, so the volume is little, weight is light and operation is convenient and credit.

8E1 + 1 Ethernet Fiber Optical Multiplexer uses the PDH fiber transmission technologies.

The 2Mbps (E1) interfaces can connect with the exchanger, light loop device and

multi-diplexer directly to the special network. Complete alarm function for 8E1 Fiber Optical

Multiplexer, it is stable and easy to maintenance, install and small in size. It has one digital

service telephone.

1.2 Principle Chart and Description

Fig1. PDH principle chart

SNR-MPX-8E1-SFP

8E1 + 1Ethernet Fiber Optical Multiplexer

6/5/2009 Shop.Nag.Ru Page 4 of 16

1.2.1 Description

Device adopts veneer structure, and can be distinguished according to the functions into 5

parts: A. 2/8 combine unit, B. encode/decode unit, C. hot line unit, D. monitoring system, E.

second power. A, B and E are the basic parts, achieving reverse conversion from 4

2048kbit/s signals to laser signal. C and D are of assistant.

1.3 Characters

•Base on IC of independence intellectual property rights

•Adopt veneer structure

•Offer 1-8 × 2Mb/s digital interfaces

•Up to 8 E1 links on one fiber

•One link to service telephone for duty contract

•Provides 1 channel of 10M/100M, support VLAN setting.

•One channel OA for optional.

•When fiber signal is loss, users can distinguish whether the remote device is power

off or the fiber line is down from the indicator status on the local device.

•180-260VAC & -48VDC power options and the positive and negative of DC-48V can

be optional because there is the self-test circuit for the polarity inside th1e device

•Standard 19 inches rack, little volume, light weight, steady capacity and convenient

setup

SNR-MPX-8E1-SFP

8E1 + 1Ethernet Fiber Optical Multiplexer

6/5/2009 Shop.Nag.Ru Page 5 of 16

CHAPTER 2. FUNCTIONS

2.1 Front Panel

Fig2. Sketch map of the front panel

2.1.1 LED

Name Color Status Describe

LOS Red Active E1 signal loss

OLOS

Red Active Optical Signal lost

Red Flick 2time/sec.: the remote device is

power off

OLOF Red Active Optical SYNC loss

LE Red Active Total alert when any alert in local

E3 Red Active Optical BER≥10

-3

F2 Green \ \

PWR Green Active Power on

LINK Green Active LAN Link and Active

SPD Green Active On:100M,OFF:10M

Note: If the function is defined as 4E1/2E1, then LOS5-8/LOS3-8 is ineffective.

SNR-MPX-8E1-SFP

8E1 + 1Ethernet Fiber Optical Multiplexer

6/5/2009 Shop.Nag.Ru Page 6 of 16

2.1.2 Buttons in front panel

PUSH OFF ON

MSK DIP1-5 be used E1 warning shield DIP1-5 be used E1 remote loop

MUTE (standalone) warning voice is on

(standalone) warning voice is off

LRS LED means Local LED means Remote

PH Hot line phone not used Use Hot line phone

2.1.3 Hot line phone (optional port)

Hot line phone, not occupy 2Mbps channel transmission.

On the front panel there is a “PH” button, press on the “PH” button on the remote site it

will sound.

To answer it the remote site just need to press the “PH” button on the remote unit, the

alarm will cut off and just plug in the phone both side able to do the communication.

Setting of the manage phone.

•It does not occupy the 2M circuits

pin definition description

1 MIC- MIC input -

2 SPEAKER+ Loudhailer output +

3 SPEAKER- Loudhailer output -

4 MIC+ MIC input +

1234

SNR-MPX-8E1-SFP

8E1 + 1Ethernet Fiber Optical Multiplexer

6/5/2009 Shop.Nag.Ru Page 7 of 16

2.1.4 Front panel DIP definition

On the front panel of standalone / card in rack, the SW5 DIP definition shows as follows:

When MSK button pushes up, (RLOOP1-8): 1-8 E1 remote loop. If the RLOOP1 is ON,

this means that at the far end it is doing a E1 loop-back

0 means ON,1 means OFF

The Remote x E1 Loop MSK button Bit1 Bit2 Bit3 Bit4 Bit5

1 push up 0 0 0 0 1

2 push up 0 0 0 1 0

3 push up 0 0 0 1 1

4 push up 0 0 1 0 0

5 push up 0 0 1 0 1

6 push up 0 0 1 1 0

7 push up 0 0 1 1 1

8 push up 0 1 0 0 0

All 8E1 Loop push up 0 0 0 0 0

E1 not Loop push up other units

Table 1

When MSK button push down, Bit1-5(mask1-5) mean 1-8E1 warning shielding.

1 means OFF, 0 means ON

Shielding E1

channel

MSK button

contort Bit1 Bit2 Bit3 Bit4 Bit5

8 push down 0 1 0 0 1

7-8 push down 0 1 0 1 0

SNR-MPX-8E1-SFP

8E1 + 1Ethernet Fiber Optical Multiplexer

6/5/2009 Shop.Nag.Ru Page 8 of 16

6-8 push down 0 1 0 1 1

5-8 push down 0 1 1 0 0

4-8 push down 0 1 1 0 1

3-8 push down 0 1 1 1 0

2-8 push down 0 1 1 1 1

1-8 push down 1 0 0 0 0

E1 not shielding push down Other units

Bit 6 : reserved.

Bit-7: ON: fiber interface local loop OFF: Cancel the loop

Bit-8: ON: The Ethernet interfaces are logically separated.

OFF: The Ethernet interfaces are exchangeable.

2.2 Rear panel

Sketch map of rear panel for 75Ω

Sketch map of rear panel for 120Ω

Note: If the function is defined as 4E1/2E1, then No.5-8/ No.3-8 E1 ports are ineffective.

SNR-MPX-8E1-SFP

8E1 + 1Ethernet Fiber Optical Multiplexer

6/5/2009 Shop.Nag.Ru Page 9 of 16

2.2.1 Power Supply

Support AC220V and DC-48V

•AC220V: 180-260VAC, directly insert power wire;

•-48VDC: the positive and negative of DC-48V can be optional because there is the

self-test circuit for the polarity inside the device

2.2.2 Ethernet (optional component)

This model can offer 1-4 channels for 10/100M, full/duplex auto-negotiation LAN

interface, support VLAN protocol, this interface can continuous learn MAC addresses in

the LAN that connected with it, and send the address as frame in another LAN.

Transparence to TCP/IP protocol, offers security connection between different equipments

in the network, used widely in network connection and monitor between WAN and LAN.

•10/100 Base-T Ethernet port parameter

•Rate: 10M or 100M, full/semi duplex self adaption.

•Ethernet rate in optical line: 100Mbps.

•Protocol: support IEEE 802.3, IEEE 802.1Q(VLAN)

•MAC address table: can learn 4096 MAC address

•Ethernet buffer memory: 64 Mbits SDRAM

•Physical interface: RJ45 slot, support AUTO-MDIX

Ethernet operating diagrammatic:
