Sumer

VGA

User Manual

NEC

The marketing and sales of the equipment was reported to the BZT.

(Federal Approvals

Office

for Telecommunications)

The right to retest this equipment to verify compliance with the regulation

was given to BZT.

ES MUSS SICHERGESTELLT WERDEN, DASS DIR VORGESEHENE

NETZSTECKDOSE NAHE AM GERÄT ANGEBRACHT UND

LETCHT ZUGÄNGLICH IST.

Die ergonomischen Anforderungen an Bildschirmgeräte im Bürobereich

nach

ZH1/618

werden in Verbindung mit der

Videokarte: Prisma

Graphic

Sys. VGA RT800

erfüllt. Aus ergonomischen Gründer wird empfohlen, die Grundfarben

Blau und Rot nicht auf dunklem Untergrund zu verwenden (schlechte

Lesbarkeit und erhöhte Augenbelastung bei zu geringem Zeichenkontrast

wären die Folge). Weiterhin muß sichergestellt werden,

daß

die minimale

Bildwiederholfrequenz von

und 76 Hz bei Positivdarstellung

64 Hz bei Negativdarstellung

nicht unterschritten wird (störendes Bildschirmflimmern könnte die Folge

sein).

Customer’s

Record

The serial number of this

product

appears on the back of the unit.

You should note this serial number in the space provided below and retain

this manual as a permanent

record

of your purchase to aid in identifica-

tion in the event of theft or

loss.

Model number: JC-1431VMB

Serial number:

WARNING: To reduce the risk of fire or electric shock, do not expose

this Computer Display to rain or moisture.

Caution

For 120V Operation,use only with power cord plug having a parallel

blade, grounding type plug, rated 125V

10A.

For 240V Operation,use only with power cord having a tandem blade,

grounding type plug, rated 250V

5A.

Bescheinigung des

Herstellers/lmporteurs

Hiermit wird bescheinigt,

daß

der/die/das

Monitor JC-1431VMB

(Gerät, Typ, Bezeichnung)

In Übereinstimmung mit den Bestimmungen der

BMPT Vfg. 243/1991

(Amtsblattverfugung)

funk-entstört ist.

Dem Bundesamt fur Zulassungen in der Telekommunikation wurdedas

inverkehrbringen dieses Gerätesangezeigt und die Berechtigungzur

Überprüfung der Serie auf Einhaltung der Bestimmungen eingeräumt.

Declaration

of the Manufacturer or Importer

We hereby certify that the Monitor JC-1431VMB

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Equipment, Type, Model-No.

in compliance with the requirement of BMPT Vfg.

24311991

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

RFI

Suppressed.

Contents

Ill

1 NEC SVGA Monitor

2 Setting Up Environment

.........................

Connecting the Monitor

................

3 Using the Monitor

Front Panel Controls

...................

Power Switch

.......................

Horizontal Size Control

...............

Vertical Size Control

.................

Brightness Control

...................

Contrast Control

....................

Rear Panel Controls

....................

Horizontal Position Control

...........

Vertical Position Control

..............

Tilt/Swivel

Base

......................

Problem Solving

......................

Troubleshooting

......................

Cleaning............................

4 Reviewing Technical Data

Pin Assignments

Timing Tables

2-l

2-2

3-2

3-3

3-4

3-5

3-6

4-3

4-4

List of Tables

Troubleshooting

.....................

3-6

SVGA Monitor Specifications

..........

4-l

Pin Assignments

......................

4-3

Preset Timing

VGA

.................

4-5

Preset Timing

SVGA/EVGA

.........

4-6

Preset Timing

VESA VGA

...........

4-7

NEC SVGA

Monitor

Congratulations on your purchase of the NEC

SVGA color monitor.

NEC’s

SVGA Monitor offers

a maximum horizontal resolution of 1024

Pixels

a maximum vertical resolution of 768

Pixels.

Additionally, the SVGA Monitor provides

System

compatibility via the following features:

provides automatic adjustment to vertical and

horizontal frequencies including VGA, SVGA,

EVGA, and VESA VGA.

displays an infinite number of colors (limited by

hardware and Software applications).

horizontal and vertical size and

Position

controls.

To properly set up and use your monitor, read the

sections that follow.

Setting Up

The SVGA Monitor shipping

carton

contains the

monitor, user manual and power

cable.

If these items

are missing, contact your NEC

dealer.

Please save the original box and packing materials

for future transportation 0; shipment of this monitor.

ENVIRONMENT

Use

the following guidelines to set up your monitor:

Place the monitor in a dry, clean, dust-free

location.

Allow adequate Ventilation around the monitor

so that heat generated

can

dissipate properly.

Place the monitor away from high-capacity

transformers, electric motors. and other strong

magnetic fields.

To minimize eye fatigue:

do not place the monitor against a bright

background or where sunlight will shine

directly on it.

position

the monitorjust below eye level.

2-2 Setting Up

CONNECTING Use the following

steps

to connect the monitor to

THE MONITOR pur

Computer.

1. Turn off and unplug the computer’s power

Cord.

Unplugging the

Computer

2. The voltage selector is located on the rear of the

monitor. Determine the appropriate voltage,

115V

23OV,

and set the switch accordingly.

Se tting the

voltage

Voltage Selector

Setting Up 2-3

3. Attach the monitor

signal

cable to the

video

connector at the rear of the Computer.

Secure the connection by tightening the two

screws on either side of the

signal

cable’s

connector.

Attaching the

signal

ca ble

Signal Cable

2-4 Setting Up

4. Connect one end of the monitor power cable to

the rear of the monitor. Plug the other end into a

properly

grounded

wall outlet.

Connecting the

power cable

WARNING: DO not place the monitor or any other

object

on the power cable. Darnage to a power cable

can

cause

fire or electrical

shock.

Setting Up 2-5

5. If you are setting up the Computer for the first

time, see your user manual. Otherwise, continue

with the following

step.

6. Plug in the Computer power

cable.

If you have any Problems, please refer to the

Troubleshooting section of this mannual.
