NEC MultiSync FE700 FE700 FE700 Manuale utente

MultiSync FE700

User's Manual

100

Declaration

Declaration of the Manufacturer

We hereby certify that the color monitors

MultiSync FE700 (JC-17W01)

is in compliance with

Council Directive 73/23/EEC:

- EN 60950

Council Directive 89/336/EEC:

- EN 55022

- EN 60555-2

- EN 61000-3-3

- EN 50082-1

(IEC 801-2)

(IEC 801-3)

(IEC 801-4)

and marked with

NEC Home Electronics, Ltd.

686-1, NISHIOI OI-MACHI

ASHIGARAKAMI-GUN

KANAGAWA 258-8533, JAPAN

100

Safety Instruction

Caution:

When operating the FE700 with a 220-240V AC power source in Europe

except UK, use the power cord provided with the monitor.

In UK, a BS approved power cord with moulded plug has a Black (five

Amps) fuse installed for use with this equipment. If a power cord is not

supplied with this equipment please contact your supplier.

When operating the FE700 with a 220-240V AC power source in

Australia, use the power cord provided with the monitor.

For all other cases, use a power cord that matches the AC voltage of the

power outlet and has been approved by and complies with the safety

standard of your particular country.

ENERGY STAR®Product

As an ENERGY STAR Partner, NEC Technologies has determined that this

product meets the ENERGY STAR guidelines for energy efficiency. The

ENERGY STAR emblem does not represent EPA endorsement of any product

or service.

IBM is registered trademark of International Business Machines Corporation.

Apple and Macintosh are registered trademarks of Apple Computer Inc.

Microsoft and Windows are registered trademarks of the Microsoft Corporation.

ENERGY STAR is a U.S. registered trademark.

NEC is a registered trademark of NEC Corporation.

ErgoDesign is a registered trademarks of NEC Home Electronics, Ltd. in U.K., Germany, France, Spain, Italy, Denmark,

Norway, Sweden and Benelux.

IPM, OSM, ColorControl, OptiClear, GlobalSync, EdgeLock and Advanced Digital Control System are trademarks of

NEC Home Electronics, Ltd.

MultiSync is a registered trademark of NEC Technologies, Inc in U.S. and of NEC Home Electronics, Ltd in Canada, U.K.,

Germany, France, Spain, Italy, Austria, Benelux, Switzerland, Denmark, Finland, Norway and Saudi Arabia.

All other trademarks or registered trademarks are property of their respective owners.

100

TCO’99

Congratulations!

You have just purchased a TCO'99 approved

and labelled product! Your choice has

provided you with a product developed for

professional use. Your purchase has also

contributed to reducing the burden on the

environment and also to the further

development of environmentally adapted

electronics products.

Why do we have environmentally labelled

computers?

In many countries, environmental labelling has become an established

method for encouraging the adaptation of goods and services to the

environment. The main problem, as far as computers and other

electronics equipment are concerned, is that environmentally harmful

substances are used both in the products and during their manufacture.

Since it is not so far possible to satisfactorily recycle the majority of

electronics equipment, most of these potentially damaging substances

sooner or later enter nature.

There are also other characteristics of a computer, such as energy

consumption levels, that are important from the viewpoints of both the

work (internal) and natural (external) environments. Since all methods of

electricity generation have a negative effect on the environment (e.g.

acidic and climate-influencing emissions, radioactive waste), it is vital to

save energy. Electronics equipment in offices is often left running

continuously and thereby consumes a lot of energy.

What does labelling involve?

This product meets the requirements for the TCO'99 scheme which

provides for international and environmental labelling of personal

computers. The labelling scheme was developed as a joint effort by the

TCO (The Swedish Confederation of Professional Employees), Svenska

Naturskyddsforeningen (The Swedish Society for Nature Conservation)

and Statens Energimyndighet (The Swedish National Energy

Administration).

Approval requirements cover a wide range of issues: environment,

ergonomics, usability, emission of electric and magnetic fields, energy

consumption and electrical and fire safety.

100

The environmental demands impose restrictions on the presence and use

of heavy metals, brominated and chlorinated flame retardants, CFCs

(freons) and chlorinated solvents, among other things. The product must

be prepared for recycling and the manufacturer is obliged to have an

environmental policy which must be adhered to in each country where

the company implements its operational policy.

The energy requirements include a demand that the computer and/or

display, after a certain period of inactivity, shall reduce its power

consumption to a lower level in one or more stages. The length of time to

reactivate the computer shall be reasonable for the user.

Labelled products must meet strict environmental demands, for example,

in respect of the reduction of electric and magnetic fields, physical and

visual ergonomics and good usability.

Below you will find a brief summary of the environmental requirements

met by this product. The complete environmental criteria document may

be ordered from:

TCO Development

SE-114 94 Stockholm, Sweden

Fax: +46 8 782 92 07

Email (Internet): [email protected]

Current information regarding TCO'99 approved and labelled products

may also be obtained via the Internet, using the address:

http://www.tco-info.com/

Environmental requirements

Flame retardants

Flame retardants are present in printed circuit boards, cables, wires,

casings and housings. Their purpose is to prevent, or at least to delay the

spread of fire. Up to 30% of the plastic in a computer casing can consist

of flame retardant substances. Most flame retardants contain bromine or

chloride, and those flame retardants are chemically related to another

group of environmental toxins, PCBs. Both the flame retardants

containing bromine or chloride and the PCBs are suspected of giving rise

to severe health effects, including reproductive damage in fish-eating

birds and mammals, due to the bio-accumulative* processes. Flame

retardants have been found in human blood and researchers fear that

disturbances in foetus development may occur.

100

The relevant TCO'99 demand requires that plastic components weighing

more than 25 grams must not contain flame retardants with organically

bound bromine or chlorine. Flame retardants are allowed in the printed

circuit boards since no substitutes are available.

Cadmium**

Cadmium is present in rechargeable batteries and in the

colour-generating layers of certain computer displays. Cadmium

damages the nervous system and is toxic in high doses. The relevant

TCO'99 requirement states that batteries, the colour-generating layers of

display screens and the electrical or electronics components must not

contain any cadmium.

Mercury**

Mercury is sometimes found in batteries, relays and switches. It damages

the nervous system and is toxic in high doses. The relevant TCO'99

requirement states that batteries may not contain any mercury. It also

demands that mercury is not present in any of the electrical or electronics

components associated with the labelled unit.

CFCs (freons)

The relevant TCO'99 requirement states that neither CFCs nor HCFCs

may be used during the manufacture and assembly of the product. CFCs

(freons) are sometimes used for washing printed circuit boards. CFCs

break down ozone and thereby damage the ozone layer in the

stratosphere, causing increased reception on earth of ultraviolet light with

e.g. increased risks of skin cancer (malignant melanoma) as a

consequence.

Lead**

Lead can be found in picture tubes, display screens, solders and

capacitors. Lead damages the nervous system and in higher doses, causes

lead poisoning. The relevant TCO'99 requirement permits the inclusion of

lead since no replacement has yet been developed.

* Bio-accumulative is defined as substances which accumulate within

living organisms

** Lead, Cadmium and Mercury are heavy metals which are

Bio-accumulative.

100

English

Deutsch

Français

Español

Italiano

100

English

100

Contents

MultiSync FE700 (JC-17W01) monitor box* should contain

the following:

• MultiSync FE700 Monitor with tilt/swivel base

• Power cord

• Captive Signal Cable

• User’s manual

* Remember to save your original box and packing material to transport

or ship the monitor.

User's

manual

Captive Signal

Cable

Power cord

E-1

100

Quick Start

To attach the MultiSync FE700 monitor to your system,

follow these instructions:

1. Turn off the power to your computer and MultiSync monitor.

2. If necessary, install the display card. For more information, refer to the

display card manual.

3. For the PC: Connect the

15-pin mini D-SUB of the

captive signal cable to the

connector of the display

card in your system (Figure

A.1). Tighten all screws.

For the Mac: Connect the

Macintosh Cable Adapter

(not included) to the

monitor connector on the

Macintosh (Figure B.1).

Attach the 15-pin mini

D-SUB end of the captive

signal cable to the

Macintosh cable adapter

on the computer (Figure

B.1). Tighten all screws.

Captive Signal Cable

15-pin mini D-SUB

Figure A.1

Captive Signal Cable

15-pin

mini D-SUB

Mac Adapter

(not included)

Computer

Figure B.1

E-2

100
