Portable Plasma / Flame CNC Cutting
Machine
USER MANUAL
SNR-BD
Neri Machine Tools Pvt Ltd.
www.nerigroup.in
www.EngineeringBooksPdf.com
2
WE THANK YOU VERY MUCH FOR YOUR INTEREST SHOWN
IN OUR PRODUCT.
Before using this machine, please read the instruction carefully.
1. Open the package, please check the center unit, make sure it is not be
broken, and make sure the packing list conform to the article.
2. Please make the voltage is（AC220V±10%, and use the isolation
transformer or other isolation voltage regulator device to make sure
the system work stably. The machine must be grounded reliably when
it is working.
3. Clean up dust on a regular basis to ensure the rail and rack clean.
4. The display screen of CNC system is easily broken, pay attention to
protect it.
5. This machine should be operated by professional, with some operation
and safety train information.
6. If there is something unclear, please contact with the local dealer or
call the manufactures.
Content
1 Machinery part--------------------------------------------------------------------3
2 CNC control system part---------------------------------------------------------8
www.EngineeringBooksPdf.com
3
Machinery Part
1 Put the crossed beam on the center unit, connect the line with the motor.
2. put the motor into the center unit.
www.EngineeringBooksPdf.com
4
3. Fix the four screws.
4. Put the security cover on the beam.
www.EngineeringBooksPdf.com
5
5. Fixed the screw of the security cover.
6.Install the anti-fire plate.
www.EngineeringBooksPdf.com
6
How to use the special crossed beam trunkings?
①Loosen the screw, remove the anti-fire plate.
②Take the security cover from the center unit.
③Loosen the screw of the trunking, take it out, put the plasma cable into the trunking, and cover
it. Then install security cover and the anti-fire plate as following picture.
www.EngineeringBooksPdf.com
7
Ports details
Parameter
Input voltage 220V
Power frequently 50HZ
Rated power 180W
Display 5.7 inch
Effective cutting range X-axis: 2000mm Y-axis: 1200mm
Speed Flame cutting: 0-1000mm/min unload>8m
Plasma cutting: 0-4000mm/min unload>8m
Cutting thickness Flame cutting: 0-150mm
Plasma cutting: 6-150mm
Transversal beam length (Y-axis) 1500mm
Longitudinal rails frame (X-axis) 2500mm
Total weight 80Kg
Gas depression Max 0.1Mpa
Oxygen depression Max 1.5Mpa
Befitting gas Ethane, propane, methane
www.EngineeringBooksPdf.com
8
CNC system part
Chapter One Summarize
1.1 System features
1) 5.7 high-definition lattice LCD, Small volume, Structure compact.
2) Processing graphics dynamic/static display.
3) High speed 16-bit and 8-bit single-chip microcomputer and hardware interpolator
control. High speed running by 0.5μequivalent 6 meters/minute.
4) Step motor high subdivision control the driver，move smoothly, low noise, the quality
improved clearly.
5) You can set begin speed and the time of rising/falling arbitrarily.
6) Supplying multiple constant loops to program simply.
7) Directly diagnose all input information of system, Convenience for you to check.
8) Multi-settings of parameter, can suit different requires.
1.2 Technology norm
1) Pulse equivalent：X-axis 0.5μ（diameter）Z-axis 1μ（or X axis 0.25μdiameter）
Z-axis 0.5μ）
2) G00 Max-speed：≥6 meter/minute(X-axis 0.25μ（diameter）Z-axis 0.5μ)
3) Number of connected shaft：2 axis
4) Input coordinate scope： +/- 9999。999mm
5) Maximum lines of user program： 540 line
6) User program space： 60K
7) Number of user program：64
8) Dimension：300*200*85
www.EngineeringBooksPdf.com
9
Chapter Two System Operation and Function
２
２２
２.1 Operate panel keyboard illustration
`
【F1】-【F6】Function keys: Under different operate mode, they have different definition.
【 】,【 】Triangle sign Give up and quit：Definition of the left and right key is
same.
6
3
T
。
7
8
9
U
4
V
5
I
1
J
2
M
—
S
0
G
X
Y
F
R
H
N
L
D
-
INS
DEL
S
↓
Pgup
Pgdn
S
↑
www.EngineeringBooksPdf.com
10
【INS】:Insert key under program state. Under others, it is used for increasing LCD brightness.
【DEL】:Delete key under program state. Under others, it is used for decreasing LCD brightness.
【Pgup/ S↑】:Page-up key under program state. Under automatic and manual function, it is used
for adjust cutting-gun, when press/loosen the key, cutting-gun rising/stopping.
【Pgdn/ S↓】: Page-down key under program state. Under automatic and manual function, it is used
for adjust cutting-gun, when press/loosen the key, cutting-gun falling/stopping.
【Shift】∶Space key. It is used for distinguish between upper case and lower case under program
editing state.
【 】：Enter/Effective key
【F↑】:It is used for increase speed under automatic and manual control state, increase 1%/press once
【F↓】:It is used for decrease speed under automatic and manual control state, decrease 1%/press once
Strong current control ：
Ignition automatically key under manual control state.
Strong current control ：
Preheat oxygen key under manual control state
Strong current control ：
Acetylene open key under manual control state
Strong current control ：
Cutting oxygen key under manual control state
Strong current control ：
Perforation key under manual control state
Strong current control ：
Close all states under automatic and manual control state
Acetylene
opened
Ignition
Preheat
oxygen
Cutting
oxygen
Perforation
General
switches
www.EngineeringBooksPdf.com
