NETGEAR Orbi RBR50 Manuale dell'operatore

Connect your computer or mobile device to the Orbi router with an Ethernet or WiFi

connection.

To connect with WiFi, ﬁnd the preset WiFi network name (SSID) and password on the label

on the Orbi router and connect to that network from your WiFi‑enabled computer or mobile

device.

Launch a web browser and visit orbilogin.com.If a login window opens, enter the user name

and password. The user name is admin and the default password is password.

Follow the onscreen instructions to set up your Orbi network.

The Orbi router’s ring LED turns o aer the setup is complete.

1. Connect Your Orbi Router

Unplug your modem and remove and replace the backup battery if it uses one.

Plug the modem back in.

Use the included Ethernet cable to connect your modem to the yellow Internet port on your

Orbi router.

Connect your Orbi router to a power source.

If the Power LED on the back of the Orbi router does not light, press the Power On/O

button.

Wait for the Orbi router’s ring LED to light white.

Modem

2. Set Up Your Orbi Network

Quick Start Guide

Ring LED (not shown in image)

Sync button (also used for WPS connection)

Internet port

Ethernet ports

USB port

Power On/O button and Power LED

DC Power connector

Reset button

Support

Thank you for purchasing this NETGEAR

product. You can visit

www.netgear.com/support to register

your product, get help, access the latest

downloads and user manuals, and join our

community. We recommend that you use

only ocial NETGEAR support resources.

For the current EU Declaration of

Conformity, visit

http://support.netgear.com/app/answers/

detail/a_id/11621/.

For regulatory compliance information, visit

http://www.netgear.com/about/

regulatory/.

See the regulatory compliance document

before connecting the power supply.

NETGEAR INTL LTD

Building 3, University Technology Centre

Curraheen Road, Cork, Ireland

NETGEAR, Inc.

350 East Plumeria Drive

San Jose, CA 95134, USA

are trademarks of NETGEAR, Inc. Any non‑NETGEAR

trademarks are used for reference purposes only.

September 2016

All Set Up!

Orbi Router Overview

Orbi router

(Model RBR50)

Ethernet cable

Power adapter

(varies by region)

Package Contents
