Netsys NP-100SE+/PD Manuale utente

’

PoE SERIES NP-100SE+/PD USER’S MANUAL Ver. A6

Trademarks

NETSYS is a trademar of National Enhance Technology Corp.

Other brand and product names are registered trademar s or trademar s of their respective holders.

Legal Disclaimer

The information given in this document shall in no event be regarded as a guarantee of conditions or characteristics. With respect

to any examples or hints given herein, any typical values stated herein and/or any information regarding the application of the

device, National Enhance Technology Corp. hereby disclaims any and all warranties and liabilities of any ind, including without

limitation warranties of non-infringement of intellectual property rights of any third party.

Statement of Conditions

In the interest of improving internal design, operational function, and/or reliability, NETSYS reserves the right to ma e changes to

the products described in this document without notice. NETSYS does not assume any liability that may occur due to the use or

application of the product(s) or circuit layout(s) described herein.

Maximum signal rate derived from IEEE Standard specifications. Actual data throughput will vary. Networ conditions and

environmental factors, including volume of networ traffic, building materials and construction, and networ overhead, lower actual

data throughput rate. Netsys does not warrant that the hardware will wor properly in all environments and applications, and ma es

no warranty and representation, either implied or expressed, with respect to the quality, performance, merchantability, or fitness for

a particular purpose. Ma e sure you follow in line with the environmental conditions to use this product.

PoE SERIES NP-100SE+/PD USER’S MANUAL Ver. A6

Safety Warnings

For your safety, be sure to read and follow all warning notices and instructions before using the device.

 DO NOT open the device or unit. Opening or removing the cover may expose you to dangerous high voltage points or other

ris s. ONLY qualified service personnel can service the device. Please contact your vendor for further information.

 Use ONLY the dedicated power supply for your device. Connect the power to the right supply voltage (110V AC used for

North America and 230V AC used for Europe).

 Place connecting cables carefully so that no one will step on them or stumble over them. DO NOT allow anything to rest on

the power cord and do NOT locate the product where anyone can wor on the power cord.

 DO NOT install nor use your device during a thunderstorm. There may be a remote ris of electric shoc from lightning.

 DO NOT expose your device to dampness, dust or corrosive liquids.

 DO NOT use this product near water, for example, in a wet basement or near a swimming pool.

 Connect ONLY suitable accessories to the device.

 Make sure to connect the cables to the correct ports.

 DO NOT obstruct the device ventilation slots, as insufficient air flow may harm your device.

 DO NOT place items on the device.

 DO NOT use the device for outdoor applications directly, and ma e sure all the connections are indoors or have waterproof

protection place.

 Be careful when unplugging the power, because it may produce spar s.

 Keep the device and all its parts and accessories out of the reach of children.

 Clean the device using a soft and dry cloth rather than liquid or atomizers. Power off the equipment before cleaning it.

 This product is rec clable. Dispose of it properly.

PoE SERIES NP-100SE+/PD USER’S MANUAL Ver. A6

Foreword

The Netsys Power over Ethernet (PoE) Adapter delivers data and electrical power to access points using standard Category 5

Ethernet Cable. This eliminates the need for electrical cable and power converters at each access point location.

The Power over Ethernet (PoE) Adapter is easy to install. It’s Plug and Play and requires no tools or software. Best of all, the PoE is

lightweight and compact in size meaning you can locate it virtually anywhere and never now it’s there. The PoE transfer data on

Category 5 Ethernet cable pairs 1/2 and 3/6. Power is transmitted on unused Ethernet pairs 4/5 and 7/8. It has an operational range

of up to 328 ft/100m which is a requirement of the Fast Ethernet standard.

Terminal unit with the PoE you can mount devices such as an access point virtually anywhere in a building without worrying about

the location of a power supply.

Attention:

Be sure to read this manual carefully before using this product. Especially Legal Disclaimer, Statement

of Conditions and Safety Warnings.

Caution:

The NP-100SE+/PD is for indoor applications only. This product does not have waterproof protection, please do not use in outdoor

applications.

PoE SERIES NP-100SE+/PD USER’S MANUAL Ver. A6

Table of Contents

Copyright .............................................................................................................................................................. 1

Safety Warnings.................................................................................................................................................... 2

Foreword .............................................................................................................................................................. 3

Table of Contents.................................................................................................................................................. 4

Chapter 1. Unpa king Information......................................................................................................................... 6

1.1 Chec List...................................................................................................................................................................................6

Chapter 2. Hardware Des ription.......................................................................................................................... 7

2.1 LED Indicators ............................................................................................................................................................................8

2.2 Connectors .................................................................................................................................................................................8

Chapter 3. Installation ......................................................................................................................................... 10

3.1 Hardware Installation ................................................................................................................................................................10

3.2 Pre-installation Requirements...................................................................................................................................................10

3.3 Basic connections..................................................................................................................................................................... 11

Appendix A: Cable Requirements ....................................................................................................................... 13

Appendix B: Produ t Spe ifi ation ...................................................................................................................... 15

Appendix C: Troubleshooting.............................................................................................................................. 18

PoE SERIES NP-100SE+/PD USER’S MANUAL Ver. A6

Appendix D: Complian e and Safety Information................................................................................................ 19

Appendix E: DC Power Cable Information .......................................................................................................... 22

Warranty ............................................................................................................................................................. 23

Chinese SJ/T 11364-2006................................................................................................................................... 24

PoE SERIES NP-100SE+/PD USER’S MANUAL Ver. A6

Chapter 1. Unpacking Information

1.1 Check List

Carefully unpac the pac age and chec its contents against the chec list.

Pac age Contents

1. 1 x PSE and 1x PD

2. 1 x 48V DC Adaptor

3. 1 x DC to DC Plug Cable

Note1:

Please inform your dealer immediately for any missing or damaged parts.

If possible, retain the carton including the original pac ing materials.

Use them to repac the unit in case there is a need to return for repair.

Note2:

1. Do not use sub-standard power supply. Before connecting the power supply to the device, be sure to chec

compliance with specifications. The NP-100SE of the power supply at least uses DC48V/0.4A.

2. Power supply included in pac age is commercial-grade. Do not use in harsh environments.

PoE SERIES NP-100SE+/PD USER’S MANUAL Ver. A6

Chapter 2. Hardware Description

This section describes the important parts of the converter. It features the front panel and rear panel.

Figure 2.1 Front Panel of PSE Figure 2.2 Rear Panel of PSE

Figure 2.3 Front Panel of PD Figure 2.4 Rear Panel of PD

PoE SERIES NP-100SE+/PD USER’S MANUAL Ver. A6

.1 LED Indicators

PSE or PD has a LED indicator. The following Table shows the description. (Table 2-1)

Table 2-1

LED Indi ators Des ription and Operation

Model

Color Status

Descriptions

On The PSE is connected with PD and functioning properly.

PSE Green Off PSE is not connected with PD.

On The PD is connected with PSE and functioning properly.

PD Green Off PD is not connected with PSE.

. Connectors

Table 2-2 Connectors shown of the PSE / PD

Model

Connectors

T pe Description

Power Power Jac For connecting to DC 48V power adapter, regarding the PSE power specification

please refer to serial stic er of the bottom.

Data RJ-45 For connecting to an Ethernet equipped device

PSE

PoE Out RJ-45(Green LED) For connecting to PD’s “PoE IN” to transfer Data and DC Power.

DC Out Power Jac Connect proper DC plug from “DC OUT” of PD to remote device.

Data RJ-45 Connect the RJ-45 cable from “Data” of PD to the RJ-45 port of remote device.

PoE IN RJ-45(Green LED) For connecting to PSE’s “PoE Out” to receive Data and DC Power.

PoE SERIES NP-100SE+/PD USER’S MANUAL Ver. A6

Figure 2.5 PSE Connectors

Figure 2.6 PD Connectors
