neverdark The LOG Brass Guida
THE LOG
(LOG)
Technical documentation
Smart fireplace
neverdark.one
X
Y
Z
Power consumption 900 W
weight 55.67 kg
SN_____________________
Автоматический биокамин "Тне LOG".
•
Производитель: OOO "Невердарк", Украина.
•
Этот документ является частью устройства.
•
Только для декоративного и бытового использования.
•
Держите подальше от детей.
•
Убедитесь, что стена/стол/пол, на котором вы размещаете прибор, может выдержать его вес.
•
Устанавливайте только в защищенном от сквозняков проветривания месте.
•
Верхние и боковые вентиляционные решетки не должны быть закрыты.
•
Не ставьте легковоспламеняющиеся предметы на прибор.
•
Держите углекислотный огнетушитель в пределах видимости.
•
Автоматический биокамин "Тне LOG".
•
Производитель: OOO "Невердарк", Украина.
•
Этот документ является частью устройства.
•
Только для декоративного и бытового использования.
•
X
Y
Z
Model
Code
Length, mm
Width, mm
Height, mm
Weight, kg
The LOG Brass
LOG-B
1083 314 842 56
The LOG Black
Glossy Glass
LOG-G
2
NEVERDARK The LOG
Technical documentation
General view
neverdark.one
Черная матовая покраска
The LOG Brass
The LOG Black Glossy Glass
Черное стекло
Standard configuration
Опции
Доступные опции
RC
Пульт ДУ
Fireplace
1pc
Decorative Stones
1set
Ceramic firewood
1set
Fiber for glow effect
1set
Glass
1pc
Filling hose
1pc
Fuel drain hose (service only)
1pc
Instructions
1pc
Warranty card
1pc
Micro USB cable (service only)
1pc
Packaging
1pc
3
NEVERDARK The LOG Technical
documentation
Options
neverdark.one
1080
DD
315
840
570
150
314
D-D
Fire area
Thermal insulation
100°
5
Clearence
10
Clearence
775
Installation
in a corner
Installation
against the wall
4
NEVERDARK The LOG Technical
documentation
Dimensions
neverdark.one
3,5 Touch Screen
Filling hose connection
Power button
Micro USB port
(service only)
Авто поджиг
F
Spark plug (auto
ignition)
Do not fill auto ignition
with decorative stones or
firewood
Control panel
(Push-to-Open)
Air intake (must not
be blocked)
Decorative stones and
ceramic firewood tray
Power plug
F
5
NEVERDARK The LOG
Technical documentation
Fireplace
neverdark.one
The surface can be heated
up to 90
C
min 500 mm
To curtains or
easily flammable
objects
Hot air output
Align horizontally
WARNING!
The manufacturer does not recommend placing objects above or next to the fireplace that are
sensitive to high temperatures, as this can significantly shorten their service life. If the technical
documentation were not followed, the manufacturer is not responsible for any damage to
objects above or next to the fireplace resulting from exposure to high temperatures.
6
NEVERDARK The LOG Technical
documentation
Installation
neverdark.one
Keep away from children;
•
Ensure that the wall/table/floor on which you place the appliance can support its weight;
•
Install only in a place protected from draughts;
•
Do not cover top and side ventilation grids;
•
Do not place flammable objects on the appliance;
•
Keep a carbon dioxide fire extinguisher within sight;
•
The use of a separate line with a fuse and/or circuit breaker is compulsory;
•
For comfortable use of the fireplace it is necessary to ensure the supply of fresh air into
•
the room and a removal of combustion products. It can be a ventilation extractor,
recuperator or an opened window;
Keep these installation instructions for the life of the fireplace.
•
7
NEVERDARK The LOG Technical
documentation
Features
neverdark.one
