Next Century LS4 Manuale utente
A) LS4 Leak Sensor
B) Mounting Plate
C) Sheetrock Anchors and Screws
D) Water Sensing Cables
Quick Start Guide
LS4
Additional Resources
For full installation guide, spec sheets, and additional
resources, please visit:
products.nextcenturymeters.com/ls4
Contact Information
Phone: 844.538.8203 opt. 2
Email: support@nextcenturymeters.com
Installation Components
Targeted Cable
Rope Cable
or
C
D
A
Leak Sensor
Meet the new Leak Sensor from NextCentury. The Leak Sensor is capable
of detecting water and sending audible alerts in addition to cloud-managed
alerts and notifications. The Leak Sensor’s wireless communication is
built on the industry-leading NextCentury Connect™ network and is
compatible with the full family of NextCentury wireless devices.
B
LS4
Installa'on
Common Leak Locations
The Leak Sensor can provide alerting when
water is detected in any leak-prone location.
Mount and Connect
Install the Leak Sensor close to where you would like to detect a leak.
Select a dry location that is accessible for inspection and future battery
replacement.
or
Remove the Leak Sensor
mounting plate.
Secure plate using
included tape or screws.
Slide the Leak Sensor
onto mount.
Leak Sensor Leak Sensor
Leak Sensor Leak Sensor
Connect the cable.
Wait for tone.
LS4
Water Sensing Cables
Targeted Cable
Rope Cable
Water sensing Rope Cables or Targeted Cables are installed in the area
where you would like water to be detected. Up to 3 cables can be daisy-
chained together expanding the leak detection area.
The Rope Cable can be used when a larger leak detection area is desired.
This cable type can detect water along its full length:
Install with contact points
touching the floor.
Use the included
screws to secure.
Additional Rope or Targeted Cables
can be daisy-chained at the end.
Ensure the cable is secure and
won’t be accidentally snagged or
moved out of place.
Additional Targeted or
Rope Cables can be
connected.
The Targeted Cable can detect standing water at a single point. It can be
installed at the base of a wall or on the floor. A leak will be detected if water
pools to this spot.
Cloud Connected
LS4
Wireless Made Easy
When installing NextCentury Sensors, you can instantly know if everything
is working correctly by tapping the red Test Connect button. The Leak
Sensor’s RF LED will blink green when it is able to communicate with
the property Gateway.
GW4 Gateway
App Store
iOS App
Google Play
Android App
Mobile App Download
For more, visit: www.nextcenturymeters.com or contact sales@nextcenturymeters.com
Programming
Programming Leak Sensors can be completed quickly on the NextCentury
Web or Mobile App, either ahead of time or on-site. To receive immediate
feedback with the Test Connect button, make sure the Gateway is
programmed and connected to the NextCentury Cloud.
