Next X10 Manuale utente
X SERIES
USER GUIDE
X10, X12, X212, Xs15, Xs18 and XH18
X10, X12, X212, Xs15, Xs18 and XH18 User Guide
www.next-proaudio.com
1
Contents Page
1. Introduction 2
2. Safety first 2
3. Unpacking 4
4.General Overview 4
4.1 X10 Full-range system 5
4.2 X12 Full-range system 6
4.3 X212 Full-range system 7
4.4 Xs15 Sub-bass system 8
4.5 Xs18 Sub-bass System 9
4.6 Mounting configurations 10
5. Amplification 11
6. Connections 12
7. X10 and X12 grille removal 13
8. System configurations 14
9. Technical Specifications 16
10. Warranty Information 17
11. Contacts 17
MARTIN AUDIO
L O N D O N
X10, X12, X212, Xs15, Xs18 and XH18 User Guide
www.next-proaudio.com
2
1. INTRODUCTION
Thank you for purchasing a NEXT X-line Speaker system. The X-line is a range of
portable loudspeaker enclosures designed for a wide variety of portable sound
reinforcement and club applications. This manual is intended to provide necessary
information about the X-line products covered, which include the X10, X12 and
X212 full-range enclosures, as well as the Xs15 and Xs18 sub-woofer enclosures.
For optimum performance, it is recommended that X-line systems to be
used with the NEXT LMS-242 digital signal processor. The controller provides
crossover, delay, EQ and limiter functions for every possible X-line configuration.
Please refer to NEXT LMS242 user’s guide for further information.
2. SAFETY FIRST
General considerations
It is important that loudspeaker systems are used in a safe manner. All
systems are meant to be installed and operated by qualified personnel. Please take
some time to read this manual concerning safe and proper use of X-line Series
loudspeakers. Always use protection gear to prevent injuries or death, and do not
allow general public presence too close to the work area during equipment
installation.
Professional loudspeakers are capable of producing extremely high sound
level pressures and should be used with care. Hearing loss is cumulative and
can result from prolonged exposure to sound pressure levels above
90dB. Never stand too close to driven loudspeakers, and use protection
equipment during equipment operation.
Tripod Mounting
The X10, X12 and loudspeakers incorporate a pole mounting socket to make
mounting on tripod stands possible. When using stands, the following precautions
are should be taken:
-Ensure that the stand will support the weight of the speaker by checking
the stand manufacturers rating.
-Make sure that the stand is placed on even and solid surface that can
withstand the weight and that its’legs are fully extended.
-Never, ever, try to place more than one speaker on a single stand.
X10, X12, X212, Xs15, Xs18 and XH18 User Guide
www.next-proaudio.com
3
-Place cables so that they do not present a trip hazard which could pull
the system over and cause injuries.
-When used outdoors, take preventive measures because of dynamic
forces like wind. (i.e. add some weight to the base of the stand).
-Do not attempt to move the stand while mounted with the enclosures
-Do not attempt to move the enclosures while connected
-Do not operate the systems under rain or moisture.
-Do not expose the systems to extreme heat or cold conditions to prevent
component damage.
-Isolate the immediate area to the stand to prevent injuries from a
possible fall.
-When using a pole mount with a sub-woofer enclosure, observe similar
precautions.
Stacking
-Always ensure that the floor or structure is leveled and can withstand
the weight of the complete stack.
-Do not stack speakers too high, especially outdoors where winds could
topple the stack.
-Be aware that speakers working at very high power levels generate
vibrations that can drag the systems. Take additional measures to
prevent this.
-Place cables in a way that they do not present a trip hazard.
-Do not attempt to move the enclosures while connected
-Do not operate the systems under rain or moisture.
-Do not expose the systems to extreme heat or cold conditions to prevent
component damage.
-Isolate the immediate area to the stack to prevent injuries from a
possible fall.
X10, X12, X212, Xs15, Xs18 and XH18 User Guide
www.next-proaudio.com
4
Rigging and Suspension
WARNING: Suspending the system should only be carried by qualified personnel
following safe rigging practices. Secure fixings to the building structure are vital.
Seek help from architects, structural engineers or other specialists if you have
doubts.
X-line Series enclosures are designed for portable applications, but can
be suspended by means of the threaded inserts provided or using compatible
NEXT-PROAUDIO wall Brackets. The X10, X12 and X212 enclosures are fitted
internally with steel corner reinforcement brackets to ensure that each cabinet is
strong enough to be hung from its top.
The common practice of using commercially available eye bolts for
suspension should only be undertaken with great caution. Eye bolts are strongest
along the thread axis. Angling the enclosure will result in an angle pull and it is
important to use eye bolts that are safe in these circumstances. Only forged
shoulder eye bolts should be considered and it is important that the thread length
is at least 30mm. A flat washer should be inserted between the eyebolt and the
enclosure. Formed eye bolts (i.e. those which are formed from a steel rod
bent into an eye) should be avoided. In case of portable suspended use
always perform a visual inspection for component damage and/or deformation,
including the cabinets. If you find any signs of damage or deformation DO NOT
USE THE AFFECTED COMPONENT. REPLACE IT IMMEDIATELY.
3. UNPACKING
Every Next X-line Series loudspeaker is built to the highest standard and is
thoroughly inspected before it leaves the factory. After unpacking the system,
examine it carefully for any signs of transport damage and inform your dealer if
any such damage is found. It is suggested that you retain the original packaging
so that the system can be repacked for transport if necessary. Please note that
Next-proaudio and its distributors cannot accept any responsibility for damage that
occurs to any returned product using non-approved packaging.
4. GENERAL OVERVIEW
The X-line X10, X12, Xs15, Xs18 and XH18 are ideally suited for applications that
require very compact size, high output and ease of transportation. They also make
ideal fill-in speakers for use with larger X-line systems and their very small size is
particularly useful in situations that require visually discrete solutions.
The X212 is the most powerful X-line solution, intended for more
demanding situations, where higher power is needed, like (but not limited to) small
to medium live venues.
X10, X12, X212, Xs15, Xs18 and XH18 User Guide
www.next-proaudio.com
5
4.1 X10 Full-range system
The X10 is a 2-way passive system, designed to provide exceptional club sound
reinforcement and stage monitoring from a very compact enclosure. It features a
powerful 10” low frequency driver and a 1" HF compression driver mounted on a
constant directivity 50º-100º H x 50° V asymmetric horn. Depending on the
application, the HF horn can be rotated to allow the multi-angle enclosure to be
used in either its vertical or horizontal orientation. To rotate the horn for horizontal
use, remove the grille (see below), unscrew the horn and rotate it 90 degrees.
The enclosure also contains 14 M6 threaded inserts for a variety of
mounting configurations. It is also provided with a top hat fitting underneath for
use with a tripod or as a pole socket for mounting above an X-line subwoofer.
The use of a NEXT LMS242 digital signal processor with every X-line
systems is recommended but optional. Please take into consideration that using
them without a proper signal processing unit may result in poor sound quality
and/or damage to the components.
Applications:
-Theatres and houses of worship;
-Night clubs;
-Compact voice reinforcement;
-Front and under balcony systems;
-Portable or installed audio-visual reproduction.
-General applications requiring high quality sound reproduction with a
compact enclosure;
X10, X12, X212, Xs15, Xs18 and XH18 User Guide
www.next-proaudio.com
6
4.2 X12 Full-range system
The X12 is a 2-way passive system, designed to provide exceptional club sound
reinforcement and stage monitoring from a very compact enclosure. It features a
powerful Neodymium 12” low frequency driver and a 1" HF compression driver
mounted on a constant directivity 50º-100º H x 50° V asymmetric horn.
Depending on the application, the HF horn can be rotated to allow the multi-angle
enclosure to be used in either its vertical or horizontal orientation. To rotate the
horn for horizontal use, remove the grille (see below), unscrew the horn and rotate
it 90 degrees.
The enclosure also contains 14 M6 threaded inserts for a variety of
mounting configurations. It is also provided with a top hat fitting underneath for
use with a tripod or as a pole socket for mounting above an X-line subwoofer.
The use of a NEXT LMS242 digital signal processor with every X-line
systems is recommended but optional. Please take into consideration that using
them without a proper signal processing unit may result in poor sound quality
and/or damage to the components.
Applications:
-Theatres and houses of worship;
-Night clubs;
-Live club performance;
-Floor monitor.
X10, X12, X212, Xs15, Xs18 and XH18 User Guide
www.next-proaudio.com
7
4.3 X212 Full-range system
The X212 is a 2-way passive system, designed for all kinds of applications, from
club sound reinforcement to outdoor live applications like small to medium venues.
It features 2 powerful neodymium 12” low frequency drivers and a 2" HF
compression driver. The enclosure also contains 14 M6 threaded inserts for a
variety of mounting configurations.
The use of a NEXT LMS242 digital signal processor with every X-line
systems is recommended but optional. Please take into consideration that using
them without a proper signal processing unit may result in poor sound quality
and/or damage to the components.
Applications:
-Theatres;
-Night clubs;
-Live club performance;
-Small to medium live outdoor performances
X10, X12, X212, Xs15, Xs18 and XH18 User Guide
www.next-proaudio.com
8
4.4 Xs15 Sub-bass system
The Xs15 sub-bass system can be used with the X08, X10 and X12 in order
to extend and increase the total low frequency output power. The Xs15 is a Band-
Pass sub-woofer and provides a powerful bass from a long excursion neodymium
15” driver with 100mm voice coil and it will extend the frequency response of the
complete system to below 40Hz. This cabinet is made with 18mm birch plywood.
Depending on the type of Mid/High speaker, using an active crossover, this
sub-woofer system can reproduce sound signal frequencies between 20Hz to 80Hz
(24 dB/octave). The Xs15 is also provided with a top hat fitting to be used as a
pole socket to mount an X08, X10 and X12 above the enclosure.
The use of a NEXT LMS242 digital signal processor with every X-line
systems is recommended but optional. Please take into consideration that using
them without a proper signal processing unit may result in poor sound quality
and/or damage to the components.
Applications:
-Theatres;
-Night-Clubs;
-Live club performance;
-Portable or installed audio-visual reproduction.
X10, X12, X212, Xs15, Xs18 and XH18 User Guide
www.next-proaudio.com
9
4.5 Xs18 / XH18 Sub-bass system
The Xs18 and XH18 sub-woofer systems can be used with the X10, X12 and X212
in order to extend and increase the total low frequency output power. The Xs18 is
a Band-Pass sub-woofer enclosure while the XH18 is a horn loaded sub-woofer
enclosure and both provide a powerful bass from a long excursion 18” driver with
100mm voice coil and they will extend the response of the complete system to
below 30Hz. Both cabinets are made with 18mm birch plywood. Both the Xs18 and
the XH18 are provided with a top hat fitting to be used as a pole socket to mount
a X10 or X12 above the enclosure.
The use of a NEXT LMS242 digital signal processor with every X-line
systems is recommended but optional. Please take into consideration that using
them without a proper signal processing unit may result in poor sound quality
and/or damage to the components.
Applications:
- Theatres;
- Night clubs;
- Live club performance;
- Portable or installed audio-visual reproduction.
- Live outdoor performances
Questo manuale è adatto per i seguenti modelli
5
Indice
Altri manuali Next Sistema di altoparlanti
Manuali Sistema di altoparlanti popolari di altre marche
Sondpex
Sondpex Active Speaker System and Digital Music... Manuale utente
JVC
JVC NX-PN7 Manuale utente
Marshall Amplification
Marshall Amplification AR-DM61-BT Manuale utente
Yamaha
Yamaha NX-A01 - Speaker Sys Manuale utente
SE Audiotechnik
SE Audiotechnik I-LINE Manuale utente
Gemini
Gemini WRX-843 Series Manuale utente
