Nextar MA852s Manuale utente

MA852 MP3/MP4 Digital Audio/Video Player

Instruction Manual

-1-

TABLE OF CONTENT

Cautions ….……………………………………………………………………………….……3

1 KeyFeatures……………………………………………………………………………….. 4

2 System Requirements………………………………………………………………………4

3 PackageContent…………………………………………………………………………….5

4 BeforeUsing………………………………………………………………………………….5

5 KeysDescription……………………………………………………………………………..7

6 Power On/Off… … … … … … … … … … … … … … … … … … … … … … … … … … … … … … ...8

7 Basic operation………………………………………………………………………………8

8 Playingmusic………………………………………………。……………………………….9

9 Playingvideos………………………………………………………………………………10

10 Viewing photos………………………………………………………………………...….11

11 Reading E-book… … … … … … … … … … … … … … … … … … … … … … … … … … … … .12

12 Browsingallfiles…………………………………………………………………………..13

13 Voice Recording…………………………………………………………………………..13

14 Deleting file………………………………………………………………………………..14

15 FM Radio………………………………………………………………………………….14

16 Playinggame……………………………………………………………………………...17

-2-

17 Customizing Settings… … … … … … … … … … … … … … … … … … … … … … … … … … .18

18 Troubleshooting… … … … … … … … … … … … … … … … … … … … … … … … … … … … ..21

19 Technical Specifications… … … … … … … … … … … … … … … … … … … … … … … … … .24

20 Notice………………………………………………………………………………………25

21 Precautions………………………………………………………………………………..26

22 Listening caution………………………………………………………………………….27

23 FCC Caution………………………………………………………………………………28

24 FCCCompliance………………………………………………………………………….29

-3-

Cautions

Do not subject the device to severe impact or drop it from high position.

Do not use the player in extreme hot or cold, dusty or damp field. Do not

expose it to direct sunshine.

Back up the data frequently in case of accident data loss.

Avoid using the player in strong magnetic field.

Keep the device away from water or other liquids. In the event that water or

other liquids enter the device, power off the product immediately, and clean

the device.

Do not use chemical solution to clean the device in order to avoid corrosion.

Clean it with a dry cloth.

We are not responsible for the damages or lost data caused by malfunction,

misusing, repairing the device or battery replacement.

Do not attempt to disassemble, repair or modify the product. This will

invalidate guarantee.

The design of the player or actual display may be different from what is shown

in this manual. It should be subject to the actual display or design.

-4-

1 Key Features

MP3&WMA Player

AVI Video player

JPEG image viewer

Folder Navigation

Voice Recorder

FM Tuner

FM Encoding

Removable Storage Device

Funny games

Built-in rechargeable lithium-ion battery

Customized settings

2 System Requirements

Hardware: IBM PC & Compatible PC, Notebook with USB interface

Operating System: Windows98/SE, Windows Me, Windows2000/XP

-5-

3 Package Content

Please check the package for the following items. If any one of them is missing,

please contact the vendor:

Main Unit

Stereo earphones

USB cable

User Manual

Driver CD

4 Before Using

4.1 Connect to a PC and download audio files

This player is plug & play for WIN2000/XP/ME OS. But for Windows98/SE, you are

required to install a driver before connection (See “Driver Installation”section for

details). To connect it with PC for transferring files,

(1) Plug the larger end of the USB cable to the USB port of the PC, and plug the

smaller end to the USB port of the player.

(2) When the “ ”icon appear at the right bottom of the PC screen, double click

“My Computer”on the desktop, you see a removable disk which indicates the

-6-

player. Just use the removable disk as a regular local disk, copying files from

or to it.

4.2 Removing the player from the PC safely

For Windows2000/XP:

(1) Left click the icon at the right hand corner of the taskbar.

(2) Click the pop-up mini-window with message of “Stop the USB Mass Storage

Device –Drive (X)”.

(3) When you are prompted to remove the device, pull out the player.

For Win98, please make sure the data transfer is completed before unplugging the

MP3 player.

4.3 Charge the battery

The device has a built-in lithium-ion rechargeable battery. It is charged via USB

connection. You are required to charge it before you use it for the first time. It takes

about 3 hours to fully charge the battery.

To charge the battery, connect the larger end of the USB cable to the USB interface of

PC, and connect the other smaller end of the USB cable to the USB interface of this

player. The device is connected to PC and being charged. If you want to know the

-7-

charge progress, disconnect the device safely by clicking the “ ”icon. You see an

animating battery icon indicating charge progress. When the icon becomes green, the

battery is fully charge.

Notice:

For maximum performance, lithium-ion batteries need to be used often. If you

don’t use the device often, be sure to recharge the battery at least once per

month.

5 Keys Description

-8-

6 Power On/Off

To power on,

(1) Switch on the POWER button.

(2) Press and hold the key until you see prompt on the display.

To power off,

(1) Press and hold the key until you see prompt on the display.

(2) Switch off the POWER button.

Note: This player has a power-saving feature which enables the device to power

off automatically if it is idle for about 3 minutes.

7 Basic operation

Function Operation

Play/Pause Press the PLAY/PAUSE button to play or pause.

Adjust Volume (1) Shortly press the VOL button to see a volume adjustment

icon animating.

(2) Press the PREVIOUS/NEXT button to decrease or

increase volume.

-9-

(3) Press the VOL button to confirm.

Move to the

previous file

Shortly press the PREVIOUS button.

Move to the next file Shortly press the NEXT button.

Fast Forward Press and hold the NEXT button.

Rewind Press and hold the PREVIOUS button.

Lock/unlock buttons Hold down the Play/Pause and VOL button simultaneously.

A-B Repeat To repeat a specified section of a track,

(1) During playing, shortly press the VOL button to enter A-B

repeat mode.

(2) Press the MENU button to select the start point.

(3) Press the MENU button again to select the end point.

To stop A-B repeat, press the MENU button first, and then

press the VOL button to exit.

8 Playing music

8.1 Enter the music mode

Press and hold the MENU button to display the main menu. Use the PREVIOUS/NEXT
