Nexxt Solutions NHB-S710 Manuale utente
WARRANTY
nexxtsolutions.com/warranty
YEAR
2
Smart
Wi-Fi LED
floor lamp
C
M
Product overview
1. Self-adhesive LED light strip: displays various lighting
colors according to your preferred settings through the
application
2. Lamp pole
3. Base
4. Acrylic lamp shade
5. 5-pin data cable
6. Controller
7. AC adapter
English
User guide
Thank you for purchasing the Smart Wi-Fi LED oor lamp
from Nexxt Solutions. We are excited to be part of making
your life easier, safer and bringing peace of mind into your
homes.
Package content
5-foot LED strip (1)
Power adapter (1)
Smart controller (1)
Lamp assembly kit:
Aluminum alloy tubes (4)
Acrylic lamp covers (4)
Square tubes (feet) (2)
Mounting base (1)
3/32 (2mm) Allen wrench (1)
Spare mounting screws (2)
Top cover (1)
User guide (1)
1
2
3 5
4
67
Preliminary steps
Floor lamp assembly
Step 1.
Open the box and make sure no parts are damaged or missing.
1. Fit the four grooved metal tubes together, matching
male with female connectors.
2. Next, unroll the LED strip and insert the end through the
slot on the ring attached at the bottom of the tube, as
shown in the image below. Then, gently extend the LED
strip along the length of the canal.
Note: This RGBIC LED strip is controlled by a single
IC chip and cannot be cut. Doing so will
compromise the functioning of the LEDs.
3. Remove the blue 3M protector from the back section of
the LED strip. Then, carefully stick the LED strip along the
canal following a straight line from top to bottom. The
area must be dry and even to ensure maximum grip.
1
2
3
4
12V
G
R
B
+
12V
G
R
B
+
4. Proceed to install the four white lampshades onto the
tube, starting at the bottom section. Fit each of them in
the rails on the edges of the canal by gently pressing
down until they click into place.
5. Attach the top cover to secure the tube assembly, as
shown below.
Top cover
Note: If the length of the LED
strip matches the total length
of the canal, it means it has
been placed correctly.
Note: For seamless light
output, make sure each
lampshade completely
overlays a section of the tube
from one joint to the next,
avoiding any gaps between
them.
12V
G
R
B
+
12V
G
R
B
+
12V
G
R
B
+
12V
G
R
B
+12V
G
R
B
+
12V
G
R
B
+
12V
G
R
B
+
12V
G
R
B
+12V
G
R
B
+
12V
G
R
B
+
12V
G
R
B
+
12V
G
R
B
+12V
G
R
B
+
12V
G
R
B
+
12V
G
R
B
+
12V
G
R
B
+12V
G
R
B
+
Soft ligth strip
8. Connect the female 5-way connector to the male 5-pin
at connector on the controller, making sure to match
the direction arrows on both ends.
Note: This lamp is originally intended to be placed in a
corner of the room facing the wall, radiating a diused
glow around it, and creating dierent“light painting”
atmospheres to decorate your space or match dierent
moods and occasions. It has not been designed to
substitute for the regular lights in your room.
7. Attach the lamp’s feet (square tubes) to the base and
screw them tight using the Allen wrench. Now you can
place the lamp upright on the oor.
6. Carefully place the tube on its side. Screw the mounting
base into the bottom of the tube, until the feet connectors
end up on the side opposite the lampshades. Make sure the
cable goes through the orice on the bottom ring.
C
M
9. Connect the controller to the power adapter and plug it
into a wall outlet. The LED strip will automatically turn on.
Immediately after, the lights will start blinking in red to
indicate the device has entered pairing mode. Otherwise,
press the power button on the controller for 8 seconds to
turn on the device manually.
10. Pair the lamp using the Nexxt Home App.
Controller buttons
On/O button: Briey press to turn the strip lights on or
o. Press and hold for 8 seconds to start Wi-Fi pairing
Color button: Press it to cycle through eight dierent
lighting eects.
Music button: Allows the selection among six dierent
music synchronization modes
Installing the Nexxt Home App
Download Nexxt Home app from Google Play or Apple App
Store.
60 %
9:41 AM
Nexxt Home
Nexxt Solutions Home App
Cancel
GET
Accvent LLC
Login with existing account
Create New Account
SOLUTIONS
Iniciarsesión con cuenta existente
Crear Cuenta Nueva
SOLUTIONS
60 %
9:41 AM
Nexxt Home
Nexxt Solutions Home App
Cancel
INSTALL
Accvent LLC
Step 1
Register by email. Fill in the required elds.
60 %
9:41 AM
Register by email
United States of America
Email
Get authentication code
Step 3
Create a new password and then select Completed.
60 %
9:41 AM
Set Password
Completed
6-20 characters, including letters and numbers
Step 2
Enter the verication code you received.
60 %
9:41 AM
Enter verication code
Verication code has been sent to your
Step 4
The Nexxt Home account has been successfully congured.
Add device
Step 1
Select Add device and then click on the blue +button.
However, if the device is not recognized automatically,
select the Smart oor lamp icon from the list and continue
to next step.
60 %
9:41 AM
60 %
9:41 AM
60 %
9:41 AM
Step 3
Once the Floor lamp is detected by the application, the
notication Device added successfully will be displayed on
the screen.
Click on the pencil if you want to change the icon and the
name of the device, and also assign a dierent location. You
can choose to do it now or later through the Settings
interface. Select Done to save your settings and go back to
the main interface. The device is now ready to be used.
Step 2
Verify that the smart oor lamp is powered on. You must
connect to a 2.4GHz Wi-Fi network. Enter your network
password. Ensure to use the correct password, otherwise
the device will not connect.
60 %
9:41 AM
60 %
9:41 AM
60 %
9:41 AM
