Vanity Touch User Manual

Contents

1. For your safety ........................................................................................................................................................... 4

Policies .......................................................................................................................................................................... 4

2. Phone profile............................................................................................................................................................... 4

Front view ..................................................................................................................................................................... 5

Back view ...................................................................................................................................................................... 6

3. For the first use .......................................................................................................................................................... 7

Install the SIM Card....................................................................................................................................................... 7

Scheme –SIM cards insertion....................................................................................................................................... 7

Install the Memory card................................................................................................................................................ 8

Scheme –Memory card installation ............................................................................................................................. 8

Install the battery.......................................................................................................................................................... 9

Scheme –Bettery installation ....................................................................................................................................... 9

Charge the battery ...................................................................................................................................................... 10

Scheme - Connections................................................................................................................................................. 10

Notes on battery .........................................................................................................................................................10

PIN code ......................................................................................................................................................................11

4. General instructions.................................................................................................................................................11

Icons in Standby mode................................................................................................................................................ 11

Call Key........................................................................................................................................................................13

Keypad lock .................................................................................................................................................................13

Language and input method ....................................................................................................................................... 14

Incoming call alert....................................................................................................................................................... 14

Services .......................................................................................................................................................................14

Caller groups ...............................................................................................................................................................14

5. Basic Operations...................................................................................................................................................... 15

Power ON....................................................................................................................................................................15

Power Off ....................................................................................................................................................................15

Dial a Call..................................................................................................................................................................... 15

Adjust the earpiece volume ........................................................................................................................................16

Answering a Call.......................................................................................................................................................... 16

Quick Read SMS ..........................................................................................................................................................17

Missed Calls................................................................................................................................................................. 17

Answering machine.....................................................................................................................................................17

6. The menu functions .................................................................................................................................................17

Phonebook ..................................................................................................................................................................19

Messages.....................................................................................................................................................................20

Call...............................................................................................................................................................................23

Images.........................................................................................................................................................................25

Music........................................................................................................................................................................... 25

Video ...........................................................................................................................................................................27

Wi-Fi ............................................................................................................................................................................27

Bluetooth .................................................................................................................................................................... 28

File manager................................................................................................................................................................ 28

Camera........................................................................................................................................................................30

Settings........................................................................................................................................................................ 31

Vanity Touch User Manual

Profiles ........................................................................................................................................................................34

Email............................................................................................................................................................................ 34

Twitter......................................................................................................................................................................... 35

Facebook.....................................................................................................................................................................35

Yahoo ..........................................................................................................................................................................35

MSN............................................................................................................................................................................. 35

Opera Mini ..................................................................................................................................................................35

Gsearch ....................................................................................................................................................................... 36

Gtalk............................................................................................................................................................................36

Gmap........................................................................................................................................................................... 36

Games .........................................................................................................................................................................37

Services .......................................................................................................................................................................37

Organizer..................................................................................................................................................................... 38

Calendar ......................................................................................................................................................................39

Alarm...........................................................................................................................................................................39

Wishes list ...................................................................................................................................................................39

Sense Me.....................................................................................................................................................................39

Ebook .......................................................................................................................................................................... 40

FM Radio .....................................................................................................................................................................40

Tasks............................................................................................................................................................................ 41

Calculator .................................................................................................................................................................... 41

Videorec ...................................................................................................................................................................... 41

Soundrec .....................................................................................................................................................................41

Slideshow ....................................................................................................................................................................42

Cube Media.................................................................................................................................................................42

7. Private area............................................................................................................................................................... 43

8. Text Entry..................................................................................................................................................................44

9. Using USB devices.................................................................................................................................................. 45

10. Maintenance and safety........................................................................................................................................46

Charger / Adapter ....................................................................................................................................................... 46

Battery Information .................................................................................................................................................... 46

General remarks..........................................................................................................................................................46

Troubleshooting.......................................................................................................................................................... 47

11. Abbreviations.......................................................................................................................................................... 47

12. Certifications........................................................................................................................................................... 49

Vanity Touch User Manual

1. For your safety

Policies

Per your safety

For your safety and proper use of the telephone, please observe the following guidelines:

• Do not switch the phone in proximity to chemical plants, gas stations or other areas at risk of explosion.

• When driving, use only the headset, do not forget to always park your car at the roadside before starting a

conversation with the apparatus.

• Since the use of mobile phones can cause interference on aircraft, not use any phone on an airplane. Such a

wireless phone use is dangerous and illegal, always switch off your phone before boarding.

• Pay special attention to the use of the phone near cardiac pacemakers, hearing aids and other medical

equipment, because the phone can be source of interference.

• The use of non genuine parts and accessories will void the warranty.

• Do not disassemble the phone without permission. In case of failure, please contact the supplier as soon as

possible.

• Do not connect the charger to the phone when there is no battery connected. Turn off your phone before

removing the battery, otherwise, the phone's memory may be damaged.

• When the phone is connected to the charger, always make sure that the room there is good ventilation or a heat

sink, and the unit is away from flammable items or explosives.

• To avoid the risk of demagnetization, keep the phone away from magnetic objects such as CDs, credit cards, etc.

• Make sure the phone does not come into contact with any type of liquid in the case of such cases, remove the

battery and contact your supplier immediately.

• Do not use the phone in situations with ambient temperature is too high or too low, do not expose the unit to

strong direct sunlight or humid environments. The operating temperature for the correct phone and its accessories

is between 0 ° and 40 °. The altitude when using the telephone should not exceed 2,000 meters.

• Do not use liquid or soft cloth moistened with detergent to clean the phone energetic.

• The phone has features of sound recording, video and photographs, which must be used according to the laws

and regulations.

• Keep the phone away from children. Do not throw or shake the phone, because the internal circuits and

structures accurately could be damaged.

• Do not dispose of batteries with household waste.

Note: The manufacturer assumes no responsibility for any failure of the policy set forth above or for any

unauthorized use of your phone. The manufacturer reserves the right to alter without notice the information

contained in this guide. The contents of this manual may differ from actual content displayed in the phone. In this

case, the latter shall prevail.

2. Phone profile

Profile

Phone Profiles

The phone has a screen, a vibrating motor and a joint submission to the charger port / data.

This model is also equipped with a touchscreen display that allows for intuitive navigation and simple functions by

tapping the screen with your fingers.

The following pages show the front view, rear, top and bottom of the phone.

Vanity Touch User Manual

Front view

Vanity Touch User Manual

Back view

Vanity Touch User Manual

3. For the first use

Install the SIM Card

Since the phone supports two SIM cards, you can take two different numbers, with two different network

operators and then install the two respective SIM (Subscriber Identification Module).

With these two SIM cards, you can use all the features of your phone. The SIM cards save the parameters

required for communications and personal information, including PIN (Personal Identification Number), address

book, messages and other system services additional.

Warning: do not deform or scratch the SIM card and avoid coming into contact with static

electricity, dust and humidity. If lost, please immediately contact your network operator.

The SIM cards are placed in the back of the phone, after shutting it and removed the battery.

Insert the SIM cards in their slots with the gold contacts to the cut-off corner facing you. See the diagram below.

Insert the SIM card slot in the main SIM1 and SIM card in the secondary SIM2 slot.

Scheme –SIM cards insertion

Vanity Touch User Manual

Note: If you insert a SIM card slot SIM1 only, then it will work only the primary SIM, also, if you insert a SIM card

slot only SIM 2, SIM will work solely with the secondary. When both SIM cards are inserted in their slots, you can

choose the operating mode.

Note: Since the SIM card is a small object, always remember to keep it out of reach of children!

Install the Memory card

Install the memory card

Since the phone does not have enough storage space for the use of certain features you need to install a memory

card (specifically, this phone uses a T-FLASH card.) The micro SD card is placed in the back of the phone, after

shutting it and removed the battery, its slot is located next to those in SIM cards. Open the metal cage sliding it

trough external side. Put the micro SD card with the gold contacts facing down. Then close the cage sliding it

trough SIM slot side until it clicks.

See the diagram below:

Scheme –Memory card installation

Note: Because T-FLASH card is a small object, always remember to keep it out of reach of children!

Vanity Touch User Manual

Install the battery

Installing the Battery

Your unit is supplied with a lithium-ion battery and is designed for the exclusive use of batteries and accessories

NGM. When the battery is unused for a long period, you should remove it and store it in an appropriate manner.

The battery should be placed in the back of the phone. Align the battery contacts with the connectors inside the

battery itself, then slide the battery into place. See the diagram below:

Note: Install the battery in the diagram below, in order to avoid possible damage to the contacts.

Scheme –Bettery installation

Vanity Touch User Manual

Charge the battery

Charge the Battery

Charge the battery before starting to operate the equipment. Use the supplied USB cable and the USB connector

on the top of the phone.

Connect your device to the USB cable, then connect the cable to an electrical outlet. When the battery is charging,

an animated icon on the screen shows the progress of the process. Once all icon bars are filled, the charge is

completed and the phone can be disconnected from the network.

After the battery is fully charged, remove the connection of the charger with power supply and then connect to the

phone. Follow the diagram below to connect the charger.

Note: A slight warming of the phone while charging is normal. Anew battery could achieve optimal efficiency only

after being subjected to several cycles of charging and recharging. When the battery is being used regularly, it

may be charged at the appropriate time. Excessive discharge can damage the battery.

Caution: Always check the charger and other accessories to be used for charging original or approved by the

manufacturer. Using other accessories may damage the phone and cause trouble! Use the charger and other

accessories exclusively indoors and in dry places.

Scheme - Connections

Notes on battery

Battery performance is influenced by several factors, including network settings, signal strength, intensity of use,

temperature, functions and settings chosen and used, used accessories, ringtones, data or other applications.

For best performance, please observe the following rules:

A new battery or a battery left unused for a long time require longer charging

times. The standard battery voltage is 3.6V-4.2V.

During charging, keep the battery at a temperature close to ambient.

With the passage of time, the battery will gradually be subjected to wear and thus need more time to

recharge. However, if after a normal charging time of use and the decrease of charging increases, you need

to buy another battery from the original manufacturer or authorized it. Batteries of inferior quality could

damage the phone and cause trouble!

If your phone has been used extensively with a low charge level, you may need a longer time before

the indicator is shown on the screen while charging.

Note: Take care to dispose of the batteries according to local regulations. Try to recycle the batteries as possible.

Do not throw batteries in the trash.

Caution: Do not dispose of batteries in fire, as there is a real risk of explosion.

Indice

Manuali Telefono cellulare popolari di altre marche

Zte

Zte BLADE A520 Manuale utente

Nokia

Nokia Lumia 620 Manuale utente

Blackbe;rry

Blackbe;rry KEYone Manuale utente

Bea-fon

Bea-fon X5 Premium Manuale utente

Blackbe;rry

Blackbe;rry 8707 Series Manuale utente

Blackbe;rry

Blackbe;rry Storm Istruzioni operative

LG LM-X420QN Manuale utente

LifeWatch

LifeWatch V Manuale utente

Bea-fon

Bea-fon SILVER LINE SL860 Manuale utente

IKI Mobile

IKI Mobile KF4.5i Manuale utente

Hitech

Hitech HT-850 Manuale utente

Yezz

Yezz Fashion F10 Manuale utente

Point Mobile

Point Mobile PM60 Manuale utente

Blackbe;rry

Blackbe;rry Q10 Manuale utente

Blackbe;rry

Blackbe;rry Bold 9900 Manuale utente

Blackbe;rry

Blackbe;rry STORM 9500 - VERSION 5.0 Manuale utente

LG LM-K420EMW Manuale utente

ISAFE MOBILE

ISAFE MOBILE IS655.2 Manuale utente
