Night Owl CS-MINI-DVR-4GB Manuale utente
2
Chapter 1 : FCC Radiation Norm ..............................................3
Chapter 2 : Package Contents ..................................................4
Chapter 3 : System Requirements............................................5
Chapter 4 : Hardware Description ............................................6
Chapter 5 : Charging Your Mini DVR........................................7
Chapter 6 : Changing the Time and Date.................................8
Chapter 7 : Recording a Video................................................10
Chapter 8 : Taking a Picture....................................................11
Chapter 9 : Download Your Videos / Pictures.......................12
Chapter 10 : Reset Your Mini DVR..........................................14
Chapter 11 : Warranty..............................................................15
Interactive How-To videos are available for
the chapters indicated with this icon.
You can also visit Night Owl’s website at
http://www.nightowlsp.com/Videos
Table of Contents
3
FCC
This equipment has been tested and found to comply with limits for
Class B digital device pursuant to Part 15 of Federal Communications
Commission (FCC) rules.
FCC Compliance Statement
These limits are designed to provide reasonable protection against
frequency interference in residential installation. This equipment
generates, uses, and can radiate radio frequency energy, and if not
installed or used in accordance with the instructions, may cause harmful
interference to radio communication. However, there is no guarantee
that interference will not occur in television reception, which can be
determined by turning the equipment off and on. The user is encouraged
to try and correct the interference by one or more of the following
measures:
Reorient or relocate the receiving antenna
Increase the separation between the equipment and the receiver
Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected to.
CAUTION!
The Federal Communications Commission warns the user that changes
or modifications to the unit not expressly approved by the party
responsible for compliance could void the user’s authority to operate the
equipment.
Chapter 1: FCC Radiation Norm
4
Your new Mini Video DVR will contain the following items.
- Mini Video DVR
- USB Cable
- 4GB Micro SD Card
- User Manual
- Neck Lanyard
- Clip on Case
- Mounting Bracket
- Protective Clear Case
Chapter 2: Package Contents
5
Please be sure the computer that you will use the Mini DVR with
complies with the following specifications:
- IBM PCs or 100% Compatible
- Windows®2000, XP, Vista, 7
- Mac® OS 10.3 and above
- Available USB Port
Chapter 3: System Requirements
6
Chapter 4: Hardware Description
7
1. To charge your Mini DVR, locate the USB cable that was
provided in the packaging. Plug the smaller end of the
cable into the USB connection slot on the mini DVR.
2. Connect the other end of the USB cable to your computer.
The LED indicator will flash between green and red while
the mini DVR is charging.
3. Once the mini DVR is completely charged, the LED
indicator will turn to a solid red color.
Prior to use, please charge your new
Mini DVR using the included USB
cable for 8 hours for optimal
performance.
Chapter 5: Charging Your Mini DVR
8
1. To change the time on your mini DVR, connect it to your
computer.
2. A window will pop-up once you have inserted the USB
into the computer. Click “Open folder to view files”.
3. Create a text file named “Time.txt”to edit the time and
date. The format of the time and date must be set in
“YYYY.MM.DD HH:MM:SS” using Military Time.
Chapter 6: Changing the Time and Date
9
4. Go to “File”, “Save” the document and safely remove the
mini DVR from your computer.
5. Turn on the mini DVR once to initiate the reset.
When your mini DVR’s battery is too low, the time may reset
to factory default. You will need to reset the time again if you
want your recorded files to have the correct recording time.
