NIIMBOT B3S Manuale utente
B3S
Operation and Maintenance Manual
Label Printer
PACKAGE CONTENTS
02 02
GUIDE TO APP USAGE
01 01
03
COMPONENT DESCRIPTION
03
04
CHARGING
04
05
BASIC USAGE AND SETTINGS
05
13
CLEANING OF PLATEN
07
10
INSTALLATION OF LABEL ROLL
06
15
TROUBLESHOOTING GUIDE
08
18
WARNINGS
09
19
NOTES
10
21
WARRANTY
11
CONTENTS
Guide to APP Usage
It only takes two steps to start a new marking experience
Download the "NiiMbot" application from the App Store
or Google Play.
APP Open the lid and place the consumables.
App Store
Available on the
GET IT ON
01
Printer (1, including battery)
USB cable (1) Manual (1)
Package Contents
02
01 · 02
03
Component Description
Printer nameplate
Paper case cover
Paper case cover
open button
Paper cutter
Paper Delivery/
Select button
Paper exit
Display screen
Power supply/
Setup
USB interface
Lithium battery
04
Charging
Insert the power adapter plug into the electrical outlet,
and insert the USB plug into the printer's USB slot.
The power adapter is required to be 5V/1A or 1A
above. Please don't remove the battery during the
charging process.
During the charging process: The electricity quantity
indicator icon flashes.
Fully charged: The electricity quantity indicator icon
shows fully charged and stops flashing.
03 · 04
Basic Usage And Settings
1．Start-up
Long press the "Power/Menu" button for two seconds while the
machine is in the OFF state (the screen is not on). The printer will
then start up and the screen will display the main interface.
2． Paper skip
Press the "Paper Skip/Select" button on the main interface,
and the printer will deliver a piece of paper.
3． Paper type display: When you select different paper
types, corresponding icons will be displayed at the
same time.
Device ID
B3S-AB09000001
Adding machine paper: The paper is cut in alignment with the
gaps on the paper, via the cutter.
Black label paper: The paper is directly torn via the K line,
rather than using the cutter.
05
Continuous paper: A complete piece of printing paper whose
cutting point is customizable, cuts are made by the cutter.
Continuous paper: A complete piece of printing paper whose
cutting point is customizable, cuts are made by the cutter.
4 ． Paper Out Detection and Paper Case Opening Inspection
The screen displays relevant information when it is out of paper/
the paper case is opened, and the printer will not respond to the
printing command when in this state.
5． Low Electricity Quantity Inspection
When the battery level is 0, the printer prompts " The battery
level is low. Please charge!" and will shut down 10 seconds later.
Cover Open! Lack of Paper!
The battery level is low.
Please charge!
05 · 06
Device ID
B3S-AB09000001
Device ID
B3S-AB09000001
6．Bluetooth Connection
After Bluetooth pairing and connection, the Bluetooth icon
displays in reversed color.
7．Power Supply Indicator
When the power adapter is inserted, it will display the power
supply indicator icon.
8．Settings
Press the "Power/Menu" button on the main interface to enter
the settings interface, and press the "Power/Menu" button
again to switch between the five different settings interfaces
of "Print Concentration", "Paper Type", "Off Time",
"Language" and "Print Self-check Page". Press the "Paper
Skip/Select" button in the settings interface to change the
option content.
1)Print concentration: Five levels (levels 1, 2, 3, 4 and 5).
2)Type Of Paper: 4 types (crack label, black label , CONT label，
TNSPRT label).
3)Off Time: 4 types ( 15 min, 30 min, 60 min and never off).
Program the amount of time the printer will wait while inactive
before automatically turning off.
Density
< 3 >
Type Of Paper
< crack label >
Shutdown Time
< 60 minutes >
07 · 08
