SPECIFICATIONS SHEET

CONVENIENCE OUTLETS

• Home Theater Convenience Outlets

• Speaker/Ampliﬁer Convenience Outlets - Five-way Binding Post

• Modular Panel for Convenience Outlets

Modular Panels and Convenience Outlets

CONVENIENCE OUTLETS AND CONNECTORS

NILES AUDIO CORPORATION 12331 SW 130 Street, Miami, FL 33186 1-800-BUY-HIFI – www.nilesaudio.com

2-Gang Home Theater

Convenience Outlet

HTP-7.1

Stock Number

FG01216

Features

■ 1/2 Frame Speaker Wall Plate Panel

■ Gold-Plated Five-Way Binding Posts

■ Connect Up To Six Pairs of Speakers

■ Accommodates up to 12 gauge speaker wire,

spade lugs, pins, or banana plugs

Warranty: Ten-year limited

Shipping weight: 1 lb.

In-wall Speaker Panel for up to

Six Pairs of Speakers

5W-24C

Stock Number

FG01221

Home Theater Convenience Outlets

Features

■ Connects all speakers for 5.1, 6.1,

and 7.1 digital surround systems

■ Pro Logic™/Pro Logic II™ analog systems

■ Gold-plated, color-coded binding posts

■ Gold-plated RCA connectors

■ Accommodates up to 14 gauge speaker wire,

spade lugs, pins, or banana plugs

■ Provisions for powered and passive subwoofers

■ Requires 2-gang electrical box

Warranty: Ten-year limited

Shipping weight: 1 lb.

In-wall Speaker Panel for up to

Twelve Pairs of Speakers

5W-48C

Stock Number

FG01220

Features

■ Full Frame Speaker Wall Plate Panel

■ Gold-Plated Five-Way Binding Posts

■ Connect Up To 12 Pairs of Speakers

Specifications

■ Frame dimensions: 9-3/4" x 12"

■ Hole cutout dimensions: 8" x 10-1/2"

Warranty: Ten-year limited

Shipping weight: 1 lb.

Speaker/Amplifier Convenience Outlets - Five-way Binding Posts

CONVENIENCE OUTLETS AND CONNECTORS

NILES AUDIO CORPORATION 12331 SW 130 Street, Miami, FL 33186 1-800-BUY-HIFI – www.nilesaudio.com

Modular Panel for Six Decora

Convenience Outlets

MB6-DI

Stock Number

FG01219

Features

■ Frame and insert for installing six Decora

style Convenience Outlets

■ Can be used with any single gang Decora

style Convenience Outlets

Specifications

■ Frame dimensions: 9-3/4" x 12"

■ Hole cutout dimensions: 8" x 10-1/2"

Warranty: Ten-year limited

Shipping weight: 1 lb.

Features

■ Frame and insert for installing one or

two 5W-24C In-wall panels

■ One blank 1/2 frame panel &

mounting screws included

■ Required for installation of all 5W-24C

In-wall panels

Specifications

■ Frame dimensions: 9-3/4" x 12"

■ Hole cutout dimensions: 8" x 10-1/2"

Warranty: Ten-year limited

Shipping weight: 1 lb.

Modular Panel for Mounting 5W-24C

MB-2

Stock Number

FG01218

Modular Panel for Convenience Outlets
