Nilfisk-Advance SC430 Manuale utente

Nilﬁsk A/S

Kornmarksvej 1

DK-2605 Brøndby

Denmark

Tel.: +45 43 23 40 50

Fax: +45 43 43 77 00

mail.com@nilﬁsk.com

www.nilﬁsk.com

If the machine has been used until the red light illuminates on the battery level indicator on the machine, a full recharge of the batteries (10-12 hours) will be required. Failure to carry out this this

procedure may cause damage to the batteries. Charging the batteries after every use is recommended.

Use & maintenance

- SC430

17. Park the machine with the recovery

tank cover open.

16. Charge the batteries: Connect the

battery charger cable to the mains

electricity supply.

15. Clean the machine using a damp

cloth and where needed use a

neutral cleaning product.

14. Check and clean the squeegee

blades.

10. Wash with clean water the recovery

tank and the vacuum grid.

11. Remove the brush/pad and clean

them.

12. Take the squeegee off and remove

debris.

13. Check and clean the squeegee

blades.

5. Place the brush or the pad-holder

under the deck. Use the appropriate

brush to clean the ﬂoor.

9. At the end of the work. Empty the

recovery tank with the hose. Then

empty the solution tank with the

trasparent hose.

6. Adjust the eco solution ﬂow control

valve.

8. Press the handle switch to engage

the brush and run the machine.

7. Switch on the brush and vac motors

to activate the machine.

2. Fill the tank with a clean water. The

clean water temperature must not

exceed 40 °C.

1b. Disconnect the battery charger

cable from the mains electricity

supply.

3. If the squeegee is not connected to

the machine: install and fasten it with

the handwheels, then connect to the

suction hose.

1a. Switch off charger by unplug

charger cable from red battery plug.

Reconnect the red battery plug to

the machine.

4. If the squeegee is in upper position,

lower it with the lever.

ATTENTION! Do not use the machine before you have read and understood the Instructions for User Manual
