Nista Devices IP39-4 Series Manuale utente

IP39-4x

IP Secured Access Control

Edition 3.01

IP Door Phones

IP 39-4X

Installation and Programming Manual

Document Release: 3.01

Release Date: 01/04/18

Notification

Notification is hereby given that Nista Devices GmbH. reserves the right to modify, change, update or revise this

document from time to time as required without the prior obligation to notify any person, company or organization.

Further, Nista Devices GmbH. makes no warranty or representation, either express or implied, with respect to

merchantability, or fitness of its products for a particular purpose.

This document or any parts thereof are not to be reproduced or transmitted in anyform or byany means, electronic or

mechanical, including photocopying, recording, or information storage and retrieval systems for any purpose

whatsoever without the express written permission of Nista Devices GmbH.



Table of Contents
1Introduction ...................................................................................................................................................................1
1.1
 Model Nomenclature:....................................................................................................................................................1
1.1.1 List of Available Models.......................................................................................................................................2
2Product Overview..........................................................................................................................................................3
3IP Door Phone Package Content..................................................................................................................................4
3.1
 “What’s in the Box”........................................................................................................................................................4
4IP Door Phone Front Panel...........................................................................................................................................5
5IP Door Phone Main Functionality ................................................................................................................................6
6Installation.....................................................................................................................................................................7
6.1
 Mounting .......................................................................................................................................................................7
6.2
 Connections..................................................................................................................................................................8
6.3
 Reset Device to Factory DefaultConfiguration...........................................................................................................14
6.4
 LED Panel Indication ..................................................................................................................................................15
7Programming ..............................................................................................................................................................16
7.1
 Access to Web Management Interface.......................................................................................................................16
7.2
 Home Screen..............................................................................................................................................................17
7.3
 Network Parameters...................................................................................................................................................19
7.3.1 Network Configuration Parameters...................................................................................................................19
7.3.2 Network -> HTTPS Activation...........................................................................................................................20
7.3.3 Network / NAT Traversal ..................................................................................................................................21
7.3.4 Auto Provision...................................................................................................................................................22
7.3.5 IP39-4x APS Configuration File’s Naming rules: ..............................................................................................23
7.3.6 IP39-4x APS Firmware update.........................................................................................................................23
7.4
 SIP Parameters...........................................................................................................................................................25
7.4.1 SIP Account Screen..........................................................................................................................................25
7.4.2 SIP / Port Settings ............................................................................................................................................25
7.4.3 SIP Audio Codecs.............................................................................................................................................26
7.4.4 SIP Video Codecs.............................................................................................................................................27
7.4.5 SIP Advanced Settings.....................................................................................................................................27
7.4.6 SIP -> Transport ...............................................................................................................................................28
7.4.7 SIP -> Upload Certificate..................................................................................................................................28
7.5
 Telephony ...................................................................................................................................................................29
7.5.1 Telephony Parameters......................................................................................................................................29
7.5.2 Day and Night Settings.....................................................................................................................................30
7.5.3 Speed Dial and System Subscribers Table......................................................................................................31
7.6
 Door Functions............................................................................................................................................................33
7.6.1 Door Functions / Parameters............................................................................................................................33
7.6.2 Door Access Codes..........................................................................................................................................34
7.6.3Sensor...............................................................................................................................................................36
7.6.4 Master-Slave HTTPS Door opening via Ethernet network...............................................................................40
7.6.5 LED Display Settings........................................................................................................................................45



7.7
 System Parameters.....................................................................................................................................................46
7.7.1 Sound Volume ..................................................................................................................................................46
7.7.2 NTP and Time (System Time Configuration)....................................................................................................47
7.7.3 Video.................................................................................................................................................................49
7.8
 AdministrationParameters..........................................................................................................................................53
7.8.1 Save Configuration File / IP Door Phone Backup.............................................................................................53
7.8.2 Restore Configuration.......................................................................................................................................54
7.8.3 Firmware Update ..............................................................................................................................................55
7.8.4 Set to Default....................................................................................................................................................61
7.8.5 Restart / Cold Reset .........................................................................................................................................61
7.8.6 Web-Management Credentials.........................................................................................................................62
7.8.7 Syslog Server Settings......................................................................................................................................63
7.8.8 Ping Test...........................................................................................................................................................69
8User Operations..........................................................................................................................................................70
8.1
 Access by using the ‘Door AccessCode’....................................................................................................................70
8.1.1 To open the door: .............................................................................................................................................70
8.2
 Door Opening by Using the External SwitchButton....................................................................................................71
8.3
 The Door Status Sensor / Serial Doors Opening........................................................................................................71
8.3.1 Serial Door Opening* ( *- feature required special firmware )..........................................................................71
8.4
 Call to the Day / NightOperator..................................................................................................................................72
8.4.1 To dial the Operator:.........................................................................................................................................72
8.4.2 Peer-to-Peer Calls ............................................................................................................................................72
8.5
 Direct Call to Destination Number...............................................................................................................................73
8.5.1 To dial directly to a destination number:...........................................................................................................73
8.6
 Dialing by Using Speed DialDestinations...................................................................................................................73
8.6.1 Speed Dialing by Using the SPD Code ............................................................................................................74
8.6.2 Speed Dialing by Using the LED Display Search.............................................................................................74
8.7
 Door Opening from IP Extension by Using the Extension’s Door Opening Code ......................................................74
8.7.1 To open a door from an Extension: ..................................................................................................................74
8.8
 Setting the Maximum ConversationTime ...................................................................................................................75
8.9
 Case Opening/Tempering Alarm ................................................................................................................................76
8.10
Door Opening/Tempering Report in the Syslog Server...............................................................................................76
8.11
Door opening via Ethernet network by HTTPS commands........................................................................................80
8.11.1 Configuration Door Opening via Ethernet network...........................................................................................81
8.11.2 To open a door by using HTTPS commands via Ethernet network: ................................................................84
9TechnicalSpecification ...............................................................................................................................................85


1Introduction

The IP39-4x Series IP Door Phones offer a wide range of options for both indoor / outdoor access control and door

entry options, based on industry standard SIP protocol.

The IP39-4x IP Door Phones are standalone SIP phones, which enhance the functionality of a VoIP network by

providing entrance door connectivity, access control, video monitoring and more.

The IP39-4x Series are designed using cutting edge technology, incorporating a high quality full duplex

speakerphone with microphone and speaker volume settings for optimum environmental performance as well as a

built in electromagnetic lock controller.

All models are simple to set up, have modern aesthetics and are made of durable construction and provide “plug and

play” installation.

1.1

Model Nomenclature:

IP39-4X-P/PC IP39-4X–This is the IP39-4x Series Model

X –Model Number –“0” Keypad / “1” Single Call Button

P –Piezo Faceplate

A - Acrylic Faceplate

C - Camera

IP39-40PC IP39-40P

IP39-41PC IP39-41P

1.1.1 List of Available Models

Model

Description

IP39-40PC

IP Door Phone, Piezo Keypad, Integrated Internal Video Camera

IP39-40P

IP Door Phone, Piezo Keypad

IP39-41PC

IP Door Phone, Piezo Single Button, Integrated Internal Video Camera

IP39-41P

IP Door Phone, Piezo Single Button

2Product Overview

Nista Devices GmbH IP39-4x Door Phones are smart, surface mounted access control devices connected to an IP

network allowing door entry control and monitoring. They are designed for both indoor and outdoor use and are

constructed in an aluminum case with piezo or touch keypads.

The Nista Devices GmbH IP Keypad and Single Button versions support the following features:

Feature

Keypad

Single

Button

Multiple door access codes

Remote Door opening from extension

Master/Slave –secured HTTPS Door opening

Programmable day and night destinations

Integration with local LAN and VoIP networks

Network Configuration: DHCP or Static

Authorized registration with existing VoIP switching system (SIP Proxy)

Automatic busy & disconnect detection

99 Speed Dialing Memories

Up to 99 System accounts

Up to 10 Personal Door Opening codes for each relay

Destination No answer call forwarding

Day and Night weekly time profiles

System Clock and Auto DST

Informative Display

Speed dial memory directory listing / scrolling

External switch buttons

Door Status Sensors

Two separate doors control

POE-Power over Ethernet

High quality speakerphone with WEB volume control

Keypad volume control

High quality Video over IP (for models with internal video camera)

Video Streaming (HTTP; RTSP) (for models with internal video camera)

Configurable and adaptive video resolutions: QCIF; CIF; QVGA; VGA; 720p

Web Management interface

Web GUI password protection

Weather resistant and anti-vandal PIEZO keypad

Case Opening Alarm

Automatic configuration and software updates –Auto Provisioning

Media Encryption

3IP Door Phone Package Content

3.1

“What’s in the Box”

•IP Door phone unit

•Set of connectors

•Hex key wrench for securityscrew

Note:

1. If POE equipment is not available, it is possible to use External Power Supply (not supplied). External Power

Supply shall be:

•Input: 100 –240 V AC

•Output: 5VDC; 2A

2. 5VDC Power Supply shall be connected to IP Door Phone in accordance with the required polarity.

3. The External Power Supply does not include in standard Ip39-4x package.

4. The 5 VDC source is connected to the unit via a terminal block. Observe polarity on the PCB where the

terminal block is located.

4IP Door Phone Front Panel

Figure 4-1 The IP Door Phone Unit Front Panel

•▲▼ –scroll a speed dial directory.

•–enter the programming mode or use as a“Backspace”

•–dial predefined day/night extensions and hang up acall.
