Nobles TrailBlazer Lite Manuale utente

Nobles | 701 N. Lilac Drive | P.O. Box 1452 | Minneapolis MN 55440-1452 | 800.553.8033 | www.nobles.com | [email protected]

Specifications subject to change without notice. REV 8.14.06

Vacuum System TrailBlazer®TrailBlazer®Lite TrailBlazer®XP

Maximum coverage rate per hour 10,000 ft2/h 10,000 ft2/h 10,000 ft2/h

Airflow at orifice 95 cfm / 2.7 m3 /h 112 cfm / 3.2 m3 /h 150 cfm / 4.2 m3 /h

Waterlift at sealed orifice 92 in / 2337 mm 63 in / 1600 mm 100 in / 2540 mm

Vacuum motor hp 1.25 hp 1.1 hp 1.8 hp

Vacuum motor stages 2 – stage 1 – stage 1- stage

Debris Recovery System

Vacuum bag capacity 6 quart 6 quart 9.8 quart

Vacuum bag description Equipped with paper Intercept Micro Filter bag

Vacuum bag filtration

Four-level Filtration™ 96.1% efficient at 1micron. Optional High Filtration Media

Disc yields; 99.79% efficient at .3 microns

Power System

Power consumption amps 8.3 A 6.8 A 11.5 A

Voltage frequency 120 V / 60 Hz

Power consumption watts 928 Watts 802 Watts 1340 Watts

Power cord length 50 ft / 15.2 m

Power cord type 16 gauge; 3 wire SJTW, Safety Orange; detachable; UL listed

Standard Equipment / Optional Accessories

Standard equipment

1 ½” 5 ft / 1.5 m vacuum hose; 1 ½” 2-pc. Wand, E-Z Glide™ Multi-surface Floor

Tool, Upholstery Tool, Crevice Tool, Dust Brush, shoulder straps and waist harness;

detachable 50 foot / 15.2 m power cord with belt clip, reusable micro cloth bag

and one paper Intercept Micro Filter vacuum bag.

Optional accessories

Optional High Filtration Media Disc, air-driven turbo brush, 20” JetSweep™ hard

floor tool, Sound Muffler for TrailBlazer only.

Dimensions / Weight / Sound level

Width 9 in / 229 mm 14 in / 356 mm 10 in / 254 mm

Height 23 in / 584 mm 15.5 in / 394 mm 25 in / 635.mm

Net weight 9 lb / 4.1 kg 7.5 lb 3.4 kg 11.5 lb / 5.2 kg

Depth 9 in / 229 mm 9 in / 229 mm 8 in / 203 mm

Sound level 68 dBA 68 dBA 70 dBA

Warranty 3 years/2500 hrs on parts and labor (excluding batteries).

10 years on rotationally-molded polyethylene tanks.

TrailBlazer®

specifications
