Nokia Xpress-on Manuale utente

User guide for

Nokia Xpress-onTM Fun shell

(for Nokia 3220 phone)

9234345

Issue 1

9234345_CC-140D_1_en.fm Page 1 Tuesday, July 27, 2004 4:22 PM

DECLARATION OF CONFORMITY

We, NOKIA CORPORATION, declare under our sole responsibility that the product CC-140D

is in conformity with the provisions of the following Council Directive: 1999/5/EC.

A copy of the Declaration of Conformity can be found at

http://www.nokia.com/phones/declaration_of_conformity/.

Reproduction, transfer, distribution or storage of part or all of the contents in this document in

any form without the prior written permission of Nokia is prohibited.

Nokia, Nokia Connecting People and Xpress-on are trademarks of Nokia Corporation. Other

product and company names mentioned herein may be trademarks or tradenames of their

respective owners.

Java is a trademark of Sun Microsystems, Inc.

The information contained in this user guide was written for the Nokia Xpress-on

Fun shell product. Nokia operates a policy of ongoing development. Nokia reserves

the right to make changes to any of the products described in this document

without prior notice.

UNDER NO CIRCUMSTANCES SHALL NOKIA BE RESPONSIBLE FOR ANY LOSS OF DATA OR

INCOME OR ANY SPECIAL, INCIDENTAL, CONSEQUENTIAL OR INDIRECT DAMAGES

HOWSOEVER CAUSED.

THE CONTENTS OF THIS DOCUMENT ARE PROVIDED "AS IS". EXCEPT AS REQUIRED BY

APPLICABLE LAW, NO WARRANTIES OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING,

BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A

PARTICULAR PURPOSE, ARE MADE IN RELATION TO THE ACCURACY, RELIABILITY OR CONTENTS

OF THIS DOCUMENT. NOKIA RESERVES THE RIGHT TO REVISE THIS DOCUMENT OR WITHDRAW

IT AT ANY TIME WITHOUT PRIOR NOTICE.

The availability of particular products may vary by region. Please check with the Nokia dealer

nearest to you.

9234345 / Issue 1

9234345_CC-140D_1_en.fm Page 2 Tuesday, July 27, 2004 4:22 PM

Contents

English

Contents

FOR YOUR SAFETY 4

1. Overview......................................................................................... 5

2. Installation ..................................................................................... 6

3. Using the Wave message application........................................... 8

Selecting a language for the application .................................................................... 8

Creating a wave message containing text .................................................................. 9

Creating a wave message containing an image ........................................................ 9

Showing a wave message in the air........................................................................... 11

Showing a previously created wave message in the air....................................... 12

Viewing instructions about using the application................................................. 12

Changing the application settings.............................................................................. 12

4. Playing the motion games .......................................................... 13

Game settings................................................................................................................... 13

AirExpress........................................................................................................................... 14

SwampRacer ..................................................................................................................... 14

Care and maintenance..................................................................... 15

9234345_CC-140D_1_en.fm Page 3 Tuesday, July 27, 2004 4:22 PM

FOR YOUR SAFETY

Read these simple guidelines. Not following them may be dangerous or illegal.

Read the complete user guide for further information.

QUALIFIED SERVICE

Only qualified personnel may repair this device.

WATER-RESISTANCE

Your device is not water-resistant. Keep it dry.

9234345_CC-140D_1_en.fm Page 4 Tuesday, July 27, 2004 4:22 PM

Overview

English

1. Overview

The Nokia Xpress-onTM Fun shell allows you to make a statement, with or

without sound, by waving your Nokia 3220 phone in the air. The shell also

includes two motion games that you can play by tilting and moving the

phone.

The shell comes with a connector that must be plugged into the phone

before the shell can be used. The connector can be found under the shell

in the sales package.

This user guide describes how to install the front and back part of

the Nokia Xpress-on Fun shell and how to use the Wave message

application and the motion games.

Read this user guide carefully before using the Nokia Xpress-on Fun shell.

In addition to this user guide, read the user guide of your Nokia 3220

phone, which provides important safety and maintenance information.

When the Nokia Xpress-on Fun shell is installed on the Nokia 3220 phone,

it may not be possible to use the phone with some enhancements.

The Nokia Xpress-on Fun shell takes its power from the phone battery.

Note that using the shell may drain the phone battery faster.

9234345_CC-140D_1_en.fm Page 5 Tuesday, July 27, 2004 4:22 PM

Installation

2. Installation

Note: Before removing the cover, always switch off the power

from your phone and disconnect the charger and any other

device. Avoid touching electronic components while changing

the covers. Always store and use the device with the covers

attached.

For general instructions on changing the back and front cover of your

Nokia 3220 phone, see the user guide that came with it.

To install the Nokia Xpress-on Fun shell and its connector:

1. Remove the original back cover of your Nokia 3220 phone and insert

the connector supplied with the shell into the corresponding slot in

the phone.

9234345_CC-140D_1_en.fm Page 6 Tuesday, July 27, 2004 4:22 PM

Installation

English

2. Install the front cover of the Nokia Xpress-on Fun shell.

3. Install the back cover of the Nokia Xpress-on Fun shell.

4. Switch on the phone, and make sure that the time and date are set

correctly in the phone.

The shell automatically installs the Cover browser application in the

Collection submenu of the Applications menu in your phone.

5. To install the Wave message application and the two motion games,

select Cover browser in the Collection submenu, and select the

applications that you want to install. The Wave message application is

added to the Collection submenu and the games to the Games

submenu. The installation takes several minutes.

If you do not install all three applications, you can install the

remaining ones later using the Cover browser application.

Your device and its enhancements may contain small parts. Keep them

out of reach of small children.

9234345_CC-140D_1_en.fm Page 7 Tuesday, July 27, 2004 4:22 PM

Using the Wave message application

3. Using the Wave message

application

You can create light messages with the Wave message application. To

start the application, press Menu in standby mode, select Applications,

Collection, and Select application, scroll to Wave message, and press

Open or .

■Selecting a language for the application

When you start the Wave message application for the first time, the

application selects the language that is currently used in the phone if this

language is included in the application.

If the phone language is not included in the application, the application

asks whether you want to try to download the language using the GPRS

(general packet radio service) or HSCSD (high speed circuit switched data)

network service. Press Yes to download the language or No to use English

in the application.

To use the GPRS or HSCSD network service, define the browser settings in

the Services menu of your Nokia 3220 phone for a mobile Internet

connection. For more information, see the user guide of your phone.

For the availability of the GPRS or HSCSD service, related fees, and

appropriate settings, contact your network operator or service provider.

9234345_CC-140D_1_en.fm Page 8 Tuesday, July 27, 2004 4:22 PM

Using the Wave message application

English

The actual invoice for calls and services from your service

provider may vary, depending on network features, rounding off

for billing, taxes and so forth.

■Creating a wave message containing text

Start the Wave message application and select Create message. Key in a

message of up to 15 characters. To insert a smiley, press Options and

select Insert smiley.

To show the message in the air, press Display. See also Showing a wave

message in the air on page 11. To save the message for later use, press

Options and select Save.

You can set the phone to play a sound when you wave the phone in the

air: select Settings in the main menu of the Wave message application,

and select Sound list.

■Creating a wave message containing an image

Start the Wave message application and select Create image. Draw an

image. When the image is complete, press Options, and select Display to

show it in the air.

While drawing, you can do the following:

• To move the cursor, use the scroll keys. Alternatively, press 2to move

up, 4to move left, 6to move right, or 8to move down.

9234345_CC-140D_1_en.fm Page 9 Tuesday, July 27, 2004 4:22 PM

Using the Wave message application

• If the entire image does not fit in the editing screen, you can select the

area to be edited by moving the red-bordered selection frame to the

right or left in the smaller screen.

• To select the drawing mode, press Options, and select Change mode

and then Draw (to draw a line) or Normal (to draw a single dot).

Alternatively, press 1while drawing. The drawing mode indicator is

shown at the top left corner of the display.

When Normal is selected, you can draw a dot or change the color of

the current dot by pressing 5. Normal is the default drawing mode.

When Draw is selected, you can press 5to lift the pen (to move the

cursor) or to put it down (to continue drawing).

• To activate the eraser, press Options, and select Change mode and

Erase. Alternatively, press 3while drawing. While using the eraser, you

can lift it (to move the cursor) or put it down by pressing 5.

• To fill a closed area, press Options, and select Change mode and Fill.

Alternatively, press 7while drawing. Move the cursor to the desired

area and press 5to fill it.

• To insert another image into the current one, press Options and select

Insert image. Select the folder where the desired image is located

(Archive or Templates), scroll to the image, and press Insert. Move the

inserted image where you want to add it, press Options, and select OK.

To remove the inserted image, press Options and select Undo.

9234345_CC-140D_1_en.fm Page 10 Tuesday, July 27, 2004 4:22 PM
