Nokia 1616 Manuale utente

Nokia 1616 User Guide

Issue 1.0

Contents

Safety 3

Get started 4

Insert the SIM card and battery 4

Remove the SIM card 4

Charge the battery 4

Antenna 5

Switch on or off 5

Your phone 6

Keys and parts 6

Main features 6

Calls 7

Write text 7

Message 8

Contacts 8

Multi-phonebook 8

FM Radio 9

Flashlight shortcuts in standby mode 9

Access codes 10

Product and safety information 11

2Contents

Safety

Read these simple guidelines. Not following them may be dangerous or illegal. Read

the complete user guide for further information.

SWITCH ON SAFELY

Do not switch the device on when wireless phone use is prohibited or when

it may cause interference or danger.

ROAD SAFETY COMES FIRST

Obey all local laws. Always keep your hands free to operate the vehicle while

driving. Your first consideration while driving should be road safety.

INTERFERENCE

All wireless devices may be susceptible to interference, which could affect

performance.

SWITCH OFF IN RESTRICTED AREAS

Follow any restrictions. Switch the device off in aircraft, near medical

equipment, fuel, chemicals, or blasting areas.

QUALIFIED SERVICE

Only qualified personnel may install or repair this product.

ACCESSORIES AND BATTERIES

Use only approved accessories and batteries. Do not connect incompatible

products.

WATER-RESISTANCE

Your device is not water-resistant. Keep it dry.

Safety 3

Get started

Insert the SIM card and battery

This phone is intended for use with the BL-5CB battery.

Safe removal. Always switch the device off and disconnect the charger before removing

the battery.

Important: Do not use a mini-UICC SIM card, also known as a micro-SIM card, a micro-

SIM card with an adapter, or a SIM card that has a mini-UICC cutout (see figure) in this

device. A micro-SIM card is smaller than the standard SIM card. This device does not

support the use of micro-SIM cards and use of incompatible SIM cards may damage the

card or the device, and may corrupt data stored on the card.

1 Place your finger in the recess at the bottom of the device, and carefully lift and

open the back cover (1).

2 Lift the battery, and remove it (2).

3 Insert the SIM card (3). Ensure the contact surface area is facing down and the

beveled corner of the SIM card is facing the bottom of the device.

4 Replace the battery (4) and back cover (5, 6, 7).

Remove the SIM card

Press the release spring (1), and slide out the SIM card (2).

Charge the battery

Your battery has been partially charged at the factory. If the device indicates a low

charge, do the following:

4Getstarted

1 Connect the charger to a wall outlet.

2 Connect the charger to the device.

3 When the device indicates a full charge, disconnect the charger from the device,

then from the wall outlet.

Tip: To save energy, unplug the charger when the battery is fully charged.

You do not need to charge the battery for a specific length of time, and you can use the

device while it is charging. If the battery is completely discharged, it may take several

minutes before the charging indicator appears on the display or before any calls can be

made.

Antenna

The antenna area is marked in gray.

Your device may have internal and external antennas. Avoid touching the antenna area

unnecessarily while the antenna is transmitting or receiving. Contact with antennas

affects the communication quality and may cause a higher power level during operation

and may reduce the battery life.

Switch on or off

Press and hold the end key.

Get started 5

Your phone

Keys and parts

1Earpiece

2Display

3 Selection keys

4 Navi™ key (scroll key)

5 Call key

6 End/Power key

7Keypad

8Microphone

9 Flashlight

10 Headset connector (3.5mm)

11 Wrist strap eyelet

12 Charger connector

Main features

Select Menu and from the following:

Messages Create, send, and manage messages.

Contacts Save names and phone numbers.

Call log Access missed, received, and dialed calls.

Settings Set up various features of your device.

Clock Set the time for the alarm.

Radio Manage radio features.

Reminders Manage reminders.

Games Play or set up the games in your device.

Extras Access various applications.

SIM services Use supported SIM card services.

6 Your phone

Calls

To make a call, enter the phone number, including the country code and area code, if

necessary, and press the call key. To answer a call, press the call key. To end or reject a

call, press the end key.

To use a loudspeaker or earpiece during a call, select Loudsp. or Hands.. To adjust the

volume during a call, scroll left or right.

When the volume is high, do not hold the device near your ear.

Write text

To enter text, you can use traditional or predictive text input. Not all languages are

supported by predictive text input.

Use traditional text input

Press a key repeatedly until the desired letter is displayed.

Activate predictive text input

Select Options > Predictive text and the desired language.

Deactivate predictive text input

Select Options > Predictive text > Prediction off.

When using predictive text input, press each key once for a single letter. If the desired

word is displayed, press 0, and start writing the next word. If ? is displayed after the

word, the word is not in the dictionary.

Change a word

Press *repeatedly until the desired word is displayed.

Add a word

Select Spell, enter the word using traditional text input, and select OK.

Add a space

Press 0.

Change text input method

Press #repeatedly, and check the indicator at the top of the display.

Add a number

Press and hold the desired number key.

Add a special character

Press *when using traditional text input; press and hold *when using predictive text

input.

Your phone 7

Undo clearing of a message

Select Options > Undo clear.

Message

The message services can only be used if they are supported by your service provider.

Your device supports text messages beyond the limit for a single message. Longer

messages are sent as two or more messages. Your service provider may charge

accordingly. Characters with accents, other marks, or some language options take more

space, and limit the number of characters that can be sent in a single message.

Write and send a message

1 Select Menu > Messages > Create message.

2 Write the message. The message length indicator shows how many characters you

can enter in the message.

3 Select Options > Send, enter the recipient's phone number or select it from the

contacts list, and select OK.

Delete messages

Select Menu > Messages > Delete messages > All read or the desired folder.

Contacts

You can save names and phone numbers in the phone and SIM card memory. The

contacts list can contain up to 500 contacts, stored in the phone memory.

Search for a contact

Scroll down in the standby mode, enter the first characters or letters of the name, and

scroll to the desired contact.

Save contacts to the contacts list

Select Menu > Contacts > Add name.

Copy contacts between the phone and SIM card memory

Select Menu > Contacts > Copy.

Multi-phonebook

Your phone supports up to five separate phonebooks for multiple users. When the multi-

phonebook is activated, only the contacts in the active phonebook are visible.

A contact can belong to one or several phonebooks. The contacts in Shared contacts are

accessible from all phonebooks.

Select Menu > Contacts > Settings > Multi-Phonebook and the appropriate options.

8 Your phone

Activate the multi-phonebook

Select Phonebook style > Multi-Phonebook.

Activate a phonebook

Select Current phonebook and the desired phonebook or Shared contacts.

Assign a contact to one or more phonebooks

Select Manage contacts and the desired contact.

Rename a phonebook

Select Rename phonebooks and the desired phonebook.

FM Radio

The FM radio depends on an antenna other than the wireless device antenna. A

compatible headset needs to be attached to the device for the FM radio to function

properly. You may need to purchase a compatible headset separately.

To open the radio, select Menu > Radio. To adjust the volume of the radio, scroll left

or right.

You need at least one saved channel for the clock radio to function properly.

Warning:

Continuous exposure to high volume may damage your hearing. Listen to music at a

moderate level, and do not hold the device near your ear when the loudspeaker is in

use.

Flashlight shortcuts in standby mode

To switch on, scroll up twice. To switch off, scroll up once.

Do not shine the flashlight in anyone's eyes.

Your phone 9

Access codes

PIN or PIN2 code

(4-8 digits)

These protect your SIM card against unauthorized use or are

required to access some features.

You can set your device to ask for the PIN code when you switch

it on.

If not supplied with your SIM card or you forget the codes,

contact your service provider.

If you enter the code incorrectly three times in a row, you need

to unblock the code with the PUK or PUK2 code.

PUK or PUK2 code

(8 digits)

These are required to unblock a PIN or PIN2 code.

If not supplied with your SIM card, contact your service provider.

IMEI number

(15 digits)

This is used to identify valid devices in the network. The number

can also be used to block, for example, stolen devices.

To view your IMEI number, dial *#06#.

Lock code (security

code)

(min. 5 digits or

characters)

This helps you protect your device against unauthorized use.

You can set your device to ask for the lock code that you define.

The default lock code is 12345.

Keep the code secret and in a safe place, separate from your

device.

If you forget the code and your device is locked, your device will

require service. Additional charges may apply, and all the

personal data in your device may be deleted.

For more information, contact a Nokia Care Point or your device

dealer.

The personal unblocking key (PUK) code and the universal personal unblocking key

(UPUK) code (8 digits) are required to change a blocked PIN code and UPIN code,

respectively. The PUK2 code (8 digits) is required to change a blocked PIN2 code. These

codes are not supplied with the SIM card. Contact your local service provider for the

codes.

10 Access codes
