Nokia 230 Dual SIM Manuale utente
User Guide
Nokia 230 Dual SIM
Issue 1.0 EN
For your safety
Read these simple guidelines. Not following them may be dangerous or against local laws and
regulations.
SWITCH OFF IN RESTRICTED AREAS
Switch the device off when mobile phone use is not allowed or when it may cause interference
or danger, for example, in aircraft, in hospitals or near medical equipment, fuel, chemicals, or
blasting areas. Obey all instructions in restricted areas.
ROAD SAFETY COMES FIRST
Obey all local laws. Always keep your hands free to operate the vehicle while driving. Your first
consideration while driving should be road safety.
INTERFERENCE
All wireless devices may be susceptible to interference, which could affect performance.
QUALIFIED SERVICE
Only qualified personnel may install or repair this product.
BATTERIES, CHARGERS, AND OTHER ACCESSORIES
Use only batteries, chargers, and other accessories approved by Microsoft Mobile for use with
this device. Do not connect incompatible products.
KEEP YOUR DEVICE DRY
Your device is not water-resistant. Keep it dry.
PROTECT YOUR HEARING
To prevent possible hearing damage, do not listen at high volume levels for long periods.
Exercise caution when holding your device near your ear while the loudspeaker is in use.
© 2015 Microsoft Mobile. All rights reserved. 2
Get started
Get started with the basics, and have your phone up and running in no time.
Keys and parts
Explore the keys and parts of your new phone.
1 Front camera
2 Earpiece
3 Front-facing flash
4 Headphone connector (3.5 mm)
5 Selection keys
6 End/Power key
7 Microphone
8 Call key
9 Scroll key
10 Antenna area
11 Flashlight
12 Main camera. Before using the camera,
remove the protective tape from the lens.
13 Loudspeaker
14 Back cover lock
15 Charger connector
Avoid touching the antenna area while the antenna is in use. Contact with antennas affects the
communication quality and may reduce battery life due to higher power level during operation.
Do not connect to products that create an output signal, as this may damage the device. Do not
connect any voltage source to the audio connector. If you connect an external device or headset,
other than those approved for use with this device, to the audio connector, pay special attention to
volume levels.
Parts of the device are magnetic. Metallic materials may be attracted to the device. Do not place
credit cards or other magnetic storage media near the device, because info stored on them may be
erased.
Some of the accessories mentioned in this user guide, such as charger, headset, or data cable, may
be sold separately.
Note: You can set the phone to ask for a security code. The pre-set code is 12345. Change it to
protect your privacy and personal data. Note, however, that when you change the code, you
need to remember the new code, as Microsoft Mobile is not able to open or bypass it.
Insert the SIM, memory card, and battery
Learn how to insert the battery and SIM and memory cards.
© 2015 Microsoft Mobile. All rights reserved. 3
Important: This device is designed to be used with a standard SIM card (see figure) only. Use of
incompatible SIM cards may damage the card or the device, and may corrupt data stored on the
card. Please consult your mobile operator for the use of a SIM card that has a mini-UICC cutout.
Use only compatible memory cards approved for use with this device. Incompatible cards may
damage the card and the device and corrupt data stored on the card.
Note: Switch the device off and disconnect the charger and any other device before removing
any covers. Avoid touching electronic components while changing any covers. Always store and
use the device with any covers attached.
1. Slide the back cover lock with your thumb.
2. While holding the cover lock, carefully lift the bottom edge of the back cover with your fingers, and
remove the cover.
3. If the battery is in the phone, lift it out.
4. Open the SIM holder, and put the SIM in place with the contact area face down. If you have a second
SIM, put the SIM in place in the same way.
5. Slide the memory card into the memory card slot.
© 2015 Microsoft Mobile. All rights reserved. 4
6. Line up the battery contacts, and put the battery in.
7. Replace the back cover.
Remove the SIM card
Open the back cover, remove the battery, open the SIM holder, and take the SIM out.
Remove the memory card
Open the back cover, remove the battery, and pull the memory card out.
Switch your phone on
Press and hold the power key.
Charge the battery
Your battery has been partially charged at the factory, but you may need to recharge it before you
can use your phone.
1. Plug the charger into a wall outlet.
2. Connect the charger to the phone. When done, unplug the charger from the phone, then from the
wall outlet.
If the battery is completely discharged, it may take several minutes before the charging indicator is
displayed.
Tip: You can use USB charging when a wall outlet is not available. Data can be transferred while
charging the device. The efficiency of USB charging power varies significantly, and it may take
a long time for charging to start and the device to start functioning.
Make sure your computer is switched on.
© 2015 Microsoft Mobile. All rights reserved. 5
Lock or unlock the keys
To avoid accidentally pressing the keys, use keypad lock.
1. Quickly press .
2. Select Lock.
Unlock the keypad
Press , and select Unlock.
© 2015 Microsoft Mobile. All rights reserved. 6
Basics
Learn how to get the most out of your new phone.
Set which SIM card to use
If you have 2 SIM cards in your phone, you can select which one you want to use.
1. Select Menu > Settings > Connectivity > Dual SIM > Dual SIM settings.
2. To choose which SIM to use for calls, select Call, switch Always ask to Off, and select Preferred
SIM.
3. To choose which SIM to use for messages, select Messaging, switch Always ask to Off, and select
Preferred SIM.
4. To choose which SIM to use for mobile data, switch Mobile data connection to On, and select
Mobile data > Preferred SIM.
Forward calls between your 2 SIMs
Get the most out of your 2 SIM cards. If you forward your calls between your SIMs, when someone
calls you on one SIM while you’re having a call on the other, you can manage your calls from both SIMs
just like with only one SIM.
Make sure you have 2 SIM cards inserted in your phone.
1. Select Menu > Smart Dual SIM > SIM numbers.
2. Type in the numbers of your both SIMs.
3. Depending on how you want to forward the calls when one of your SIMs is out of reach or busy,
select Between two SIMs, From SIM1 to SIM2, or From SIM2 to SIM1.
Tip: To check if your calls are being forwarded, select Check status.
Explore your phone
Explore the views and features of your phone.
See the apps and features of your phone
Select Menu.
Menu
Go to an app or feature
Press the scroll key up, down, left, or right.
© 2015 Microsoft Mobile. All rights reserved. 7
Open an app or select a feature
Select Choose.
Choose
Go back to the previous view
Select Back.
Back
Go back to the home screen
Press the end key.
© 2015 Microsoft Mobile. All rights reserved. 8
Switch the flashlight on
On the home screen, quickly scroll up twice.
To switch the flashlight off, scroll up once.
Do not shine the light in anyone’s eyes.
Change the volume
Trouble hearing your phone ringing in noisy environments, or calls too loud? You can change the
volume to your liking.
Scroll up or down to change the volume during a call or when listening to the radio.
Change the wallpaper
You can change the background of your home screen to your liking.
© 2015 Microsoft Mobile. All rights reserved. 9
1. Select Menu > Settings > Display settings > Wallpaper.
2. Select a wallpaper.
Set the ringtone
Set a ringtone for your phone. You can set a different ringtone for each SIM card.
1. Select Menu > Settings > Tones.
2. Select Ringtone. If needed, select a SIM card.
3. Pick a ringtone, and select OK.
Write text
Writing with the keypad is easy and fun.
Press a key repeatedly until the letter is shown.
Type in a space
Press 0.
Type in a special character or punctuation mark
Press *.
Switch between character cases
Press # repeatedly.
Type in a number
Press and hold a number key.
Use predictive text
To speed up your writing, your phone can guess what you are starting to write. Predictive text is based
on a built-in dictionary. This feature is not available for all languages.
1. Select Options > Dictionary and the language.
2. Start writing a word. When the word you want is shown, press 0.
Change a word
Press * repeatedly until the word you want is shown.
Add a new word to the dictionary
If the word you want isn't in the dictionary, write the word, press * repeatedly to skip all unwanted
words, select Spell, and write the word.
Switch between predictive and traditional text
Press # repeatedly.
Switch predictive text off
Select Options > Dictionary > Dictionary off.
Browse the web
Catch up on the news, and visit your favourite websites on the go.
1. Select Menu > Internet > Surf or search.
© 2015 Microsoft Mobile. All rights reserved. 10
