Nokia Asha 302 Manuale utente

Nokia Asha 302 User Guide

Issue 1.1

Contents

Safety 4

Get started 5

Keys and parts 5

Write with the keyboard 6

Messaging key 7

Insert a SIM card and battery 7

Insert a memory card 8

Charge the battery 9

Switch the phone on or off 10

Antenna locations 10

Attach a strap 11

Basic use 11

Access codes 11

Lock the keys 12

Indicators 12

Copy contacts and other stuff from

your old phone 13

Change the volume of a call, song, or

video 13

Use your phone without a SIM card 14

Calls 14

Make a call 14

Call the last dialled number 14

View your missed calls 14

Contacts 14

Save a name and phone number 14

Use speed dial 15

Write text 15

Write using the keyboard 15

Predictive text input 16

Messaging 17

Send a message 17

Listen to voice messages 17

Send an audio message 18

Personalise your phone 18

About the home screen 18

Add shortcuts to your home screen 18

Personalise your home screen 19

Personalise your phone tones 19

Time management 19

Change the time and date 19

Alarm clock 20

Add an appointment 20

Connectivity 20

Bluetooth 20

USB data cable 21

Connect to a WLAN 22

Music and audio 23

FM radio 23

Media player 25

Camera 26

Take a picture 26

Record a video 26

Send a picture or video 27

Web 27

About the web browser 27

Browse the web 28

Fit a web page to your phone display 28

Add a bookmark 29

Clear your browsing history 29

Keep in touch with your online

friends 29

About Social 29

Mail and chat 30

About Mail 30

Send a mail 30

Read and reply to mail 30

2Contents

About Chat 30

Chat with your friends 31

Nokia Services 31

Availability and costs of Nokia

Services 31

Access Nokia Services 31

Phone management 31

Update phone software using your

phone 31

Update phone software using your

PC 32

Restore original settings 32

Back up your pictures and other

content to a memory card 33

Protect the environment 33

Save energy 33

Recycle 33

Nokia original accessories 34

Practical rules about accessories 34

Battery 34

Product and safety information 34

Index 52

Contents 3

Safety

Read these simple guidelines. Not following them may be dangerous or illegal. For

further information, read the complete user guide.

SWITCH OFF IN RESTRICTED AREAS

Switch the device off when mobile phone use is not allowed or when it may

cause interference or danger, for example, in aircraft, in hospitals or near

medical equipment, fuel, chemicals, or blasting areas. Obey all instructions

in restricted areas.

ROAD SAFETY COMES FIRST

Obey all local laws. Always keep your hands free to operate the vehicle while

driving. Your first consideration while driving should be road safety.

INTERFERENCE

All wireless devices may be susceptible to interference, which could affect

performance.

QUALIFIED SERVICE

Only qualified personnel may install or repair this product.

KEEP YOUR DEVICE DRY

Your device is not water-resistant. Keep it dry.

PROTECT YOUR HEARING

Listen to a headset at a moderate level, and do not hold the device near

your ear when the loudspeaker is in use.

4Safety

Get started

Keys and parts

1Charger connector

2Headset connector/Nokia AV connector (3.5 mm)

3Micro-USB connector

4Earpiece

5Screen

6Selection key

7Social key

8Call key

9Bluetooth key. Press and hold to access the Bluetooth settings.

10 WLAN key. Press and hold to access the WLAN settings.

11 Navi™ key (scroll key)

12 Selection key

13 Messaging key

14 End/Power key

15 Keyboard

Get started 5

1Camera lens. Before using the camera, remove the protective tape from the lens.

2Wrist strap hole

3Loudspeaker

4Memory card slot

5Back cover release latch

Write with the keyboard

Your phone has a full keyboard.

1Function key. To insert special characters printed at the top of keys, press the

function key, and then press the corresponding key. To enter several special

characters in a row, press the function key twice. To return to normal mode, press

the function key.

2Shift key. To switch between the upper and lower case modes, press the shift

key twice. To enter a single upper case letter in lower case mode, or a single lower

6 Get started

case letter in upper case mode, press the shift key, and then press the desired

alphabet key.

3Sym key. To insert special characters not shown on the keyboard, press the

sym key, and select the desired character.

4Backspace key. To delete a character, press the backspace key. To delete

several characters, press and hold the backspace key.

5Enter key. To move the cursor to the next row or text input field, press the

enter key. Additional functions are based on the current context.

6Ctrl key. To copy, cut, or paste selected text, while pressing and holding the

ctrl key, press C, X, or V. To select all the text, while pressing and holding the ctrl

key, press A.

Insert a variation of a letter

You can insert, for example, letters with accents. To insert á, press and hold the sym

key, and then press Arepeatedly, until the desired letter is displayed. The order and

availability of letters depends on the selected writing language.

Messaging key

To quickly write a mail or message, view your inbox, or start chatting, on the home

screen, press the messaging key .

Set what happens when you press the key

Select Menu > Settings and My shortcuts > Messaging key, and select an option.

Insert a SIM card and battery

Important: This device is designed to be used with a standard SIM card (see figure)

only. Use of incompatible SIM cards may damage the card or the device, and may

corrupt data stored on the card. Please consult your mobile operator for the use of

a SIM card that has a mini-UICC cutout.

This phone is intended for use with a BL-5J battery. Always use original Nokia

batteries.

1 Pull the back cover release latch toward the bottom of the phone, and remove

the cover.

Get started 7

2 If the battery is inserted, lift it out.

3 Slide the SIM card holder to unlock it (1), and use your fingernail to lift it. Make

sure the contact area would face down when the SIM card holder is lowered (2),

insert the SIM card into the holder, and lower the holder (3). Slide the card holder

to lock it (4).

4 Line up the contacts of the battery and the battery compartment, and insert the

battery. To replace the back cover, direct the top locking catches toward their

slots, and press down until the cover locks into place.

Insert a memory card

Use only compatible memory cards approved by Nokia for use with this device.

Incompatible cards may damage the card and the device and corrupt data stored on

the card.

Your phone supports memory cards with a capacity of up to 32 GB.

8 Get started

1 Open the cover of the memory card slot (1).

2 Make sure the contact area of the memory card is facing down, and insert the

card (2). Push the card in, until it locks into place.

3 Close the cover of the memory card slot (3).

Remove the memory card

Push the card in, until it is released, and pull the card out.

Charge the battery

Your battery has been partially charged at the factory, but you may need to recharge

it before you can switch on your phone for the first time. If the phone indicates a low

charge, do the following:

1 Connect the charger to a wall outlet.

2 Connect the charger to the phone.

3 When the phone indicates a full charge, disconnect the charger from the phone,

then from the wall outlet.

You do not need to charge the battery for a specific length of time, and you can use

the phone while it is charging.

Get started 9

If the battery is completely discharged, it may take several minutes before the

charging indicator is displayed or before any calls can be made.

If the battery has not been used for a long time, to begin charging, you may need to

connect the charger, then disconnect and reconnect it.

Switch the phone on or off

Press and hold the power key until the phone vibrates.

You may be prompted to get the configuration settings from your network service

provider. For more information on this network service, contact your network service

provider.

Antenna locations

The antenna area is highlighted.

10 Get started
