Nokia C2-02 Manuale utente

Nokia C2–02 User Guide

Issue 1.0

Contents

Safety 4

Get started 5

Keys and parts 5

Insert a SIM card and battery 5

Insert a memory card 7

Charge the battery 8

Attach a strap 9

Switch the phone on or off 9

GSM antenna 10

Basic use 10

Access codes 10

Lock or unlock the keys and screen 11

Touch screen actions 11

Swipe to open an application or

activate a feature 13

Indicators 13

Copy contacts or messages from your

old phone 13

Change the volume of a call, song, or

video 14

Calls 14

Make a call 14

Call the last dialed number 14

View your missed calls 15

Contacts 15

Save a name and phone number 15

Use 1-touch dial 15

Text input 16

Switch between text input modes 16

Write using traditional text input 16

Use predictive text input 17

Messaging 17

Send a message 17

Retrieve a multimedia message 18

Listen to voice messages 19

Send an audio message 19

Personalize your phone 19

About the home screen 19

Customize the home screen 20

Customize your phone tones 20

Time management 21

Change the time and date 21

Set an alarm 21

Add an appointment 22

Connectivity 22

Bluetooth 22

USB data cable 23

Music and audio 23

FM radio 23

Media Player 25

Pictures and videos 25

Take a picture 25

Record a video 26

Send a picture or video 26

Web 26

About the web browser 26

Browse the web 27

Clear browsing history 27

Mail and chat 27

About Mail 27

Send a mail 28

Read and reply to mail 28

About Chat 28

Chat with your friends 28

Maps 29

About Maps 29

2Contents

View your current location on the

map 29

Find a place 30

Share your location or a place 30

Create a walking route 30

Nokia's Ovi services 31

Availability and costs of Nokia's Ovi

services 31

Access Nokia's Ovi services 31

Find help 31

Support 31

Subscribe to the Tips and Offers

service 31

Keep your phone up to date 32

Protect the environment 34

Save energy 34

Recycle 34

Product and safety information 35

Index 41

Contents 3

Safety

Read these simple guidelines. Not following them may be dangerous or illegal. For

further information, read the complete user guide.

SWITCH OFF IN RESTRICTED AREAS

Switch the device off when cell phone use is not allowed or when it may cause

interference or danger, for example, in aircraft, in hospitals or near medical

equipment, fuel, chemicals, or blasting areas. Obey all instructions in

restricted areas.

ROAD SAFETY COMES FIRST

Obey all local laws. Always keep your hands free to operate the vehicle while

driving. Your first consideration while driving should be road safety.

INTERFERENCE

All wireless devices may be susceptible to interference, which could affect

performance.

QUALIFIED SERVICE

Only qualified personnel may install or repair this product.

KEEP YOUR DEVICE DRY

Your device is not water-resistant. Keep it dry.

PROTECT YOUR HEARING

Listen to a headset at a moderate level, and do not hold the device near your

ear when the loudspeaker is in use.

4Safety

Get started

Keys and parts

1Display

2Call key

3Keypad

4Earpiece

5Wrist strap hole

6Volume up/Zoom in key

7Volume down/Zoom out key

8Key lock switch

9End/Power key

10 Microphone

11 Nokia AV Connector (3.5 mm)

12 Micro-USB connector

13 Charger connector

14 Camera lens. Before using the camera, remove the protective tape from the lens.

15 Loudspeaker

Insert a SIM card and battery

Note: Switch the device off and disconnect the charger and any other device before

removing any covers. Avoid touching electronic components while changing any covers.

Always store and use the device with any covers attached.

Get started 5

Important: Do not use a mini-UICC SIM card, also known as a micro-SIM card, a micro-

SIM card with an adapter, or a SIM card that has a mini-UICC cutout (see figure) in this

device. A micro-SIM card is smaller than the standard SIM card. This device does not

support the use of micro-SIM cards and use of incompatible SIM cards may damage the

card or the device, and may corrupt data stored on the card.

Important: To prevent damage to the SIM card, always remove the battery before

you insert or remove the card.

This phone is intended for use with a BL-5C battery. Always use original Nokia batteries.

The SIM card and its contacts can be easily damaged by scratches or bending, so be

careful when handling, inserting, or removing the card.

1 Place your finger in the recess at the top of the phone, and carefully lift and remove

the back cover (1). If the battery is inserted, lift it out (2).

2 Open the SIM card holder (3), and insert or remove the SIM card (4 or 5). Make sure

the contact area of the card is facing down.

6Getstarted

3 Line up the contacts of the battery and the battery compartment, and insert the

battery (6). To replace the back cover, direct the bottom locking catches toward

their slots (7), and press down until the cover locks into place (8).

Insert a memory card

Use only compatible memory cards approved by Nokia for use with this device.

Incompatible cards may damage the card and the device and corrupt data stored on the

card.

Your phone supports memory cards with a capacity of up to 32 GB.

1 Switch the phone off, and remove the back cover and battery.

2 To release the memory card holder, slide the holder in the direction indicated by

the arrow on the holder. Lift the memory card holder (1).

3 Insert a compatible memory card. Make sure the contact area of the card is facing

down (2).

4 Lower the memory card holder (3).

5 To lock the memory card holder, slide the holder to its original position (4).

Remove the memory card

1 Switch the phone off.

Get started 7

2 Remove the back cover and battery.

3 To release the memory card holder, slide the holder in the direction indicated by

the arrow on the holder. Lift the memory card holder, and remove the memory card.

Charge the battery

Your battery has been partially charged at the factory, but you may need to recharge it

before you can switch on your phone for the first time. If the phone indicates a low

charge, do the following:

1 Connect the charger to a wall outlet.

2 Connect the charger to the phone.

3 When the phone indicates a full charge, disconnect the charger from the phone,

then from the wall outlet.

You do not need to charge the battery for a specific length of time, and you can use the

phone while it is charging.

If the battery is completely discharged, it may take several minutes before the charging

indicator is displayed or before any calls can be made.

If the battery has not been used for a long time, to begin charging, you may need to

connect the charger, then disconnect and reconnect it.

8Getstarted

Attach a strap

Straps may be available separately.

Switch the phone on or off

Press and hold the power key .

You may be prompted to get the configuration settings from your network service

provider. For more information on this network service, contact your network service

provider.

Get started 9

GSM antenna

The antenna area is highlighted.

Avoid touching the antenna area while the antenna is in use. Contact with antennas

affects the communication quality and may reduce battery life due to higher power level

during operation.

Basic use

Access codes

PIN or PIN2 code

(4-8 digits)

These protect your SIM card against unauthorized use or are

required to access some features.

You can set your device to ask for the PIN code when you switch

it on.

If not supplied with your SIM card or you forget the codes,

contact your service provider.

If you enter the code incorrectly three times in a row, you need

to unblock the code with the PUK or PUK2 code.

PUK or PUK2 code

(8 digits)

These are required to unblock a PIN or PIN2 code.

If not supplied with your SIM card, contact your service provider.

IMEI number

(15 digits)

This is used to identify valid devices in the network. The number

can also be used to block, for example, stolen devices.

To view your IMEI number, dial *#06#.

10 Basic use
