Nokia C3-01 Manuale utente

Nokia C3–01 User Guide

Issue .0

Contents

Safety 4

Get started 5

Keys and parts 5

Insert the SIM card and battery 6

Insert or remove a memory card 7

Charge the battery 7

Charge the battery over USB 8

GSM antenna 9

Attach a strap 9

Attach the stylus 10

Switch it on 10

Network services and costs 10

Access codes 10

Switch the device on or off 11

Lock the keys and screen 11

Touch screen actions 11

Touch screen settings 13

Interactive home screen elements 13

Change the volume of a call, song, or

video 13

Indicators 14

Copy contacts or pictures from your old

device 14

Functions without a SIM card 15

Use your device offline 15

Flashlight 16

Device management 16

Support 16

My Nokia 16

Update device software using your

device 17

Restore original settings 17

Organise files 18

Synchronise your calendar and contacts

with Ovi by Nokia 18

Back up your pictures and other content

to a memory card 18

Telephone 19

Make a call 19

View your missed calls 19

Call the last dialled number 19

Divert calls to your voice mailbox or

another phone number 19

Save a number from a received call or

message 20

About internet calls 20

Make an internet call 20

Make a conference call 21

Allow calls only to certain numbers 22

Prevent making or receiving calls 22

Contacts 22

Save a name and phone number 22

Use speed dial 22

Send your contact information 23

Create a contact group 23

Move or copy contacts to your SIM

card 23

Write text 24

Switch between text input modes 24

Traditional text input 24

Predictive text input 25

Messaging 25

Send a message 25

Send a message to a group of

people 26

Save an attachment 26

View a conversation 27

Listen to voice messages 27

Send an audio message 27

Mail and Instant Messaging 28

Nokia Messaging mail 28

Nokia Messaging IM 29

2Contents

Personalisation 30

About the home screen 30

Add a shortcut to the home screen 31

Add your important contacts to the

home screen 31

Personalise the Go to menu 31

Personalise the home screen 32

Change the look of your device 32

Create your own profile 32

Personalise your tones 32

Connectivity 33

Connectivity security 33

Bluetooth 33

USB data cable 36

Connect to a WLAN 37

Nokia's Ovi services 38

Ovi by Nokia 38

Access Nokia's Ovi services 39

About Nokia Ovi Suite 39

Ovi Player 39

Time management 40

Change the time and date 40

Set an alarm 40

Snooze an alarm 40

Time your workout 40

Set the countdown timer 41

Calendar 41

Make a shopping list 42

Lunar calendar 42

Pictures and videos 43

Take a picture 43

Record a video 43

Send a picture or video 43

Photos 44

Print a picture 44

Music and audio 45

Media player 45

FM radio 47

Use voice recorder 49

Web 49

About the web browser 49

Browse the web 49

Clear browsing history 50

Games and applications 50

About games and applications 50

Improve your gaming experience 50

Download a game or application 50

About Communities 51

Use the calculator 51

Convert currency and

measurements 51

Protect your device 52

Lock your device 52

Password protect your memory

card 53

Format a memory card 53

Prepare your device for recycling 53

Green tips 54

Save energy 54

Recycle 54

Nokia original accessories 54

Practical rules about accessories 55

Battery 55

Product and safety information 56

Index 72

Contents 3

Safety

Read these simple guidelines. Not following them may be dangerous or illegal. Read

the complete user guide for further information.

SWITCH OFF IN RESTRICTED AREAS

Switch the device off when mobile phone use is not allowed or when it may

cause interference or danger, for example, in aircraft, near medical

equipment, fuel, chemicals, or blasting areas.

ROAD SAFETY COMES FIRST

Obey all local laws. Always keep your hands free to operate the vehicle while

driving. Your first consideration while driving should be road safety.

INTERFERENCE

All wireless devices may be susceptible to interference, which could affect

performance.

QUALIFIED SERVICE

Only qualified personnel may install or repair this product.

BATTERIES AND OTHER ACCESSORIES

Use only batteries, chargers and other accessories approved by Nokia for use

with this device. Do not connect incompatible products.

KEEP YOUR DEVICE DRY

Your device is not water-resistant. Keep it dry.

PROTECT YOUR HEARING

Listen to a headset at a moderate level, and do not hold the device near your

ear when the loudspeaker is in use.

4Safety

Get started

Keys and parts

1Earpiece

2Display

3Call key

4Microphone

5End/Power key

6Keypad

7Nokia AV connector (3.5 mm)

8Micro USB connector

9Volume up key

10 Volume down key

11 Keylock button

12 Camera key

13 Loudspeaker

Get started 5

14 Camera flash

15 Camera lens

16 Charger connector

To ensure optimum performance, remove the protective foil that covers, for example,

the display and the camera lens.

Insert the SIM card and battery

This device is intended for use with a BL-5CT battery. Always use original Nokia batteries.

The SIM card and its contacts can be easily damaged by scratches or bending, so be

careful when handling, inserting, or removing the card.

1 Slide the cover, and remove it. If the battery is inserted, lift the battery out.

2 Insert a SIM card. Make sure the contact area of the card is facing down.

3 Line up the contacts of the battery and the battery compartment, and insert the

battery. To replace the back cover, direct the top locking catches toward their slots,

and slide the cover, until it locks into place.

6Getstarted

Important: Do not use a mini-UICC SIM card, also known as a micro-SIM card,

device does

cards may damage

and may corrupt data stored on the card.

micro-SIM card with an adapter, or a SIM card that has a mini-UICC cutout (see figure)

smaller than the standard SIM card. This

in this device. A micro SIM card is

not support the use of micro-SIM cards and use of incompatible SIM

the card or the device,

Insert or remove a memory card

Use only compatible memory cards approved by Nokia for use with this device.

Incompatible cards may damage the card and the device and corrupt data stored on the

card.

Your device supports memory cards with a capacity of up to 32 GB.

Insert a memory card

1 Remove the back cover.

2 Make sure the contact area of the card is facing down. Push the card in, until you

hear a click.

3 Replace the back cover.

Remove the memory card

You can remove or replace the memory card without switching the device off.

1 Remove the back cover.

2 Push the card in, until you hear a click, and pull the card out.

3 Replace the back cover.

Charge the battery

Your battery has been partially charged at the factory, but you may need to recharge it

before you can switch on your device for the first time.

If the device indicates a low charge, do the following:

Get started 7

Important: Do not remove the memory card when an application is using it.

Doing so may damage the memory card and the device, and corrupt data stored on the

card.

1 Connect the charger to a wall outlet.

2 Connect the charger to the device.

3 When the device indicates a full charge, disconnect the charger from the device,

then from the wall outlet.

You do not need to charge the battery for a specific length of time, and you can use the

device while it is charging.

If the battery is completely discharged, it may take several minutes before the charging

indicator appears on the display or before any calls can be made.

If the battery has not been used for a long time, to begin charging, you may need to

connect the charger, then disconnect and reconnect it.

Charging the device while listening to the radio may affect the quality of reception.

Charge the battery over USB

Battery low, but you don't have a charger with you? You can use a compatible USB cable

to connect to a compatible device, such as a computer.

To avoid breaking the charger connector, be careful when connecting or disconnecting

the charger cable.

Charging over USB can take longer to start, and may not work if you connect through a

non-powered USB hub. Your device charges more quickly when connected to a wall

outlet.

If connected to a computer, you can synchronise your device while charging.

8Getstarted

GSM antenna

The figure shows the GSM antenna area marked in grey.

Avoid touching the antenna area unnecessarily while the antenna is transmitting or

receiving. Contact with antennas affects the communication quality and may cause a

higher power level during operation and may reduce the battery life.

Attach a strap

Get started 9

Attach the stylus

Tip: Attach the stylus to the device as you would a wrist strap.

Switch it on

Network services and costs

Your device is approved for use on the GSM 850/900/1800/1900 MHz networks and

WCDMA 850/900/1900/2100 MHz networks. To use the device, you need a subscription

with a service provider.

Using network services and downloading content to your device may result in data

traffic costs. Some product features require support from the network, and you may

need to subscribe to them.

Access codes

PIN code — This code protects your SIM card against unauthorised use. The PIN code (4

- 8 digits) is usually supplied with the SIM card.

PIN2 code — This code (4 - 8 digits) is supplied with some SIM cards, and is required to

access some functions in your device.

If you forget an access code, contact the network service provider whose SIM card is in

your device. After three consecutive incorrect PIN or PIN2 code entries, the code is

blocked, and you need the PUK code to unblock it.

10 Switch it on

Important: Use only a stylus approved by Nokia for use with this device. Using

any other stylus may invalidate any warranty applying to the device and may damage

the touch screen. Avoid scratching the touch screen. Never use an actual pen or pencil

or other sharp objects to write on the touch screen.
