Nokia C3 Manuale utente

Nokia C3–00 User Guide

Issue 2.3

Contents

Safety 4

Support 5

Nokia C3 in brief 5

Key features 5

Keys and parts 5

Get started 7

Insert SIM card and battery 7

Switch on or off 8

Antennas 8

Charge the battery 8

Headset 8

Insert a microSD card 9

Remove the microSD card 9

Connect a USB data cable 9

Attach the wrist strap 10

Magnets and magnetic fields 10

Access codes 10

Home screen 10

Keypad lock 12

Use your device without a SIM card 12

Applications running in background 12

Calls 13

Make and answer a call 13

Loudspeaker 13

Dialling shortcuts 13

Write text 14

Write text using the keyboard 14

Predictive text input 14

Navigate the menus 15

Messaging 16

Text and multimedia messages 16

Flash messages 17

Nokia Xpress audio messages 17

Nokia Messaging Service 17

Voice messages 17

Message settings 18

Contacts 18

Music 19

Media player 19

FM radio 20

Photos 21

Capture images and record video

clips 21

View your images and video clips 21

Applications 22

Alarm clock 22

Gallery 22

Extras 22

Voice recorder 22

To-do list 23

Calendar 23

Settings 24

Profiles 24

Tones 24

Display 24

Date and time 24

Shortcuts 24

Synchronisation and backup 24

Connectivity 25

Call and phone 27

Accessories 28

Configuration 28

Restore factory settings 28

2Contents

About Ovi Browser 29

Operator menu 29

SIM services 30

Nokia original accessories 30

Practical rules about accessories 30

Battery 31

Protect the environment 31

Save energy 31

Recycle 31

Product and safety information 32

Index 39

Contents 3

Safety

Read these simple guidelines. Not

following them may be dangerous or

illegal. Read the complete user guide for

further information.

SWITCH ON SAFELY

Do not switch the device on

when wireless phone use is

prohibited or when it may

cause interference or danger.

ROAD SAFETY COMES FIRST

Obey all local laws. Always

keep your hands free to

operate the vehicle while

driving. Your first

consideration while driving

should be road safety.

INTERFERENCE

All wireless devices may be

susceptible to interference,

which could affect

performance.

QUALIFIED SERVICE

Only qualified personnel may

install or repair this product.

ACCESSORIES AND BATTERIES

Use only approved accessories

and batteries. Do not connect

incompatible products.

WATER-RESISTANCE

Your device is not water-

resistant. Keep it dry.

4Safety

Support

When you want to learn more about how

to use your product or you are unsure

how your phone should function, read

the user guide thoroughly.

If this does not resolve your issue, do one

of the following:

•Reboot your phone. Switch off the

phone, and remove the battery.

After about a minute, replace the

battery, and switch on the phone.

•Update your phone software

•Restore the original factory settings

If your issue remains unsolved, contact

Nokia for repair options. Go to

www.nokia-asia.com/repair. Before

sending your phone for repair, always

back up your data.

Nokia C3 in brief

Model number: Nokia C3-00

Key features

•Enjoy the messaging features with

the full QWERTY keyboard.

•Manage your social networking

profiles while on the move.

•Read and reply to your mail when out

and about.

•Access the internet easily through a

wireless LAN (WLAN).

•View your correspondence with

someone in the conversational

messaging view.

Keys and parts

1Earpiece

2Selection keys

3Call key

4Navi™ key (scroll key)

Support 5

5End/Power key

6Backspace key

7Enter key

8Microphone

9Space key

10 Contacts key

11 Messaging key

12 Function key

13 Shift key

14 Symbol key

15 Ctrl key

16 Charger connector

17 Headset connector/Nokia AV

connector (3.5 mm)

18 Micro USB connector

19 Memory card slot

20 Release button

21 Loudspeaker

22 Camera lens

23 Wrist strap eyelet

Special key functions

•Contacts key and messaging key. To

access some messaging or contacts

features, press the contacts or

messaging key. You can assign

different functions to the keys.

•Function key. To change the writing

language, press the function key,

then the ctrl key.

•Shift key. To switch between the

character cases, press the shift key.

To copy or cut text, press and hold

the shift key, and scroll to highlight

the word, phrase, or line of text you

want to copy or cut. Press and hold

the ctrl key, and then press C (copy)

or X (cut).

•Symbol key. To insert a special

symbol, press the symbol key, and

select the desired symbol.

6 Nokia C3 in brief

Get started

Insert SIM card and battery

Safe removal. Always switch the device

off and disconnect the charger before

removing the battery.

Important: Do not use a mini-UICC

SIM card, also known as a micro-SIM card,

a micro-SIM card with an adapter, or a

SIM card that has a mini-UICC cutout (see

figure) in this device. A micro SIM card is

smaller than the standard SIM card. This

device does not support the use of

micro-SIM cards and use of incompatible

SIM cards may damage the card or the

device, and may corrupt data stored on

the card.

The SIM card and its contacts can be

easily damaged by scratches or bending,

so be careful when handling, inserting, or

removing the card.

1 Press the back cover release

buttons, and remove the back cover

(1, 2). Remove the battery (3).

2 Make sure the contact area of the

SIM card is facing down, and place

the SIM card in the SIM card holder

(4, 5, 6).

3 Replace the battery and back cover

(7, 8, 9).

Get started 7

Switch on or off

Press and hold the power key.

Antennas

Your device may have internal and

external antennas. Avoid touching the

antenna area unnecessarily while the

antenna is transmitting or receiving.

Contact with antennas affects the

communication quality and may cause a

higher power level during operation and

may reduce the battery life.

Charge the battery

Your battery has been partially charged

at the factory. If the device indicates a

low charge, do the following:

1 Connect the charger to a wall outlet.

2 Connect the charger to the device.

3 When the device indicates a full

charge, disconnect the charger from

the device, then from the wall outlet.

You do not need to charge the battery for

a specific length of time, and you can use

the device while it is charging. If the

battery is completely discharged, it may

take several minutes before the charging

indicator appears on the display or

before any calls can be made.

Headset

Warning:

When you use the headset, your ability to

hear outside sounds may be affected. Do

not use the headset where it can

endanger your safety.

When connecting any external device or

any headset, other than those approved

by Nokia for use with this device, to the

Nokia AV Connector, pay special

attention to volume levels.

Do not connect products that create an

output signal as this may cause damage

to the device. Do not connect any voltage

source to the Nokia AV Connector.

8 Get started

Insert a microSD card

Use only compatible microSD cards

approved by Nokia for use with this

device. Nokia uses approved industry

standards for memory cards, but some

brands may not be fully compatible with

this device. Incompatible cards may

damage the card and the device and

corrupt data stored on the card.

Your phone supports microSD cards with

a capacity of up to 8 GB.

A compatible memory card may be

supplied with the device, and may

already be inserted in the device. If not,

do the following:

1 Open the cover of the memory card

slot.

2 Insert the card into the memory card

slot with the contact surface facing

up, and press until it locks into place.

3 Close the cover of the memory card

slot.

Remove the microSD card

Important: Do not remove the

memory card during an operation when

the card is being accessed. Doing so may

damage the memory card and the device,

and corrupt data stored on the card.

You can remove or replace the memory

card during phone operation without

switching the device off, but you need to

ensure that no application is currently

accessing the memory card.

Connect a USB data cable

Connect a compatible USB data cable to

the USB connector. You may need to

purchase a USB data cable separately.

Get started 9

To modify the USB settings, select

Menu > Settings > Connectivity > USB

data cable and the desired mode.

Attach the wrist strap

Thread the wrist strap as shown, and

tighten it.

Magnets and magnetic fields

Keep your device away from magnets or

magnetic fields.

Access codes

The security code helps to protect your

device against unauthorised use. You can

create and change the code, and set the

device to request the code. Keep the

code secret and in a safe place separate

from your device. If you forget the code

and your device is locked, your device will

require service. Additional charges may

apply, and all the personal data in your

device may be deleted. For more

information, contact a Nokia Care point

or your device dealer.

The PIN code supplied with the SIM card

protects the card against unauthorised

use. The PIN2 code supplied with some

SIM cards is required to access certain

services. If you enter the PIN or PIN2

code incorrectly three times in

succession, you are asked for the PUK or

PUK2 code. If you do not have them,

contact your service provider.

The module PIN is required to access the

information in the security module of

your SIM card. The signing PIN may be

required for the digital signature. The

barring password is required when using

the call barring service.

To set how your device uses the access

codes and security settings, select

Menu > Settings > Security.

Home screen

When the device is ready for use, and you

have not entered any characters, the

device is in the home screen.

10 Get started

Altri manuali per C3

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Nokia Telefono cellulare

Nokia

Nokia 7250 Manuale utente

Nokia

Nokia 3250 - XpressMusic Cell Phone 10 MB Manuale utente

Nokia

Nokia 8800 - Cell Phone 64 MB Manuale utente

Nokia

Nokia 5300 Xpress Music Manuale utente

Nokia

Nokia RH-59 Istruzioni per l'installazione

Nokia

Nokia C2-01.5 Manuale utente

Nokia

Nokia C2-01 Manuale utente

Nokia

Nokia RM-815 Manuale utente

Nokia

Nokia 3210 Manuale utente

Nokia

Nokia E71 Manuale utente

Nokia

Nokia X7-00 Manuale utente

Nokia

Nokia X Scheda tecnica

Nokia

Nokia 206 Manuale utente

Nokia

Nokia 2600 classic Manuale utente

Nokia

Nokia NSM-9DX Istruzioni per l'installazione

Nokia

Nokia CK-10 Manuale utente

Nokia

Nokia C5-03 Manuale utente

Nokia

Nokia 3600s Manuale utente

Nokia

Nokia Sprint Lumia 635 Scheda tecnica

Nokia

Nokia 6510 Istruzioni per l'installazione

Nokia

Nokia N95-4 Scheda tecnica

Nokia

Nokia E90 Communicator Manuale utente

Nokia

Nokia NAVIGATOR 6210 Istruzioni per l'installazione

Nokia

Nokia 7380 - Cell Phone 52 MB Manuale utente

Manuali Telefono cellulare popolari di altre marche

Zte

Zte BLADE A520 Manuale utente

Blackbe;rry

Blackbe;rry KEYone Manuale utente

Bea-fon

Bea-fon X5 Premium Manuale utente

Blackbe;rry

Blackbe;rry 8707 Series Manuale utente

Blackbe;rry

Blackbe;rry Storm Istruzioni operative

LG LM-X420QN Manuale utente

LifeWatch

LifeWatch V Manuale utente

Bea-fon

Bea-fon SILVER LINE SL860 Manuale utente

IKI Mobile

IKI Mobile KF4.5i Manuale utente

Hitech

Hitech HT-850 Manuale utente

Yezz

Yezz Fashion F10 Manuale utente

Point Mobile

Point Mobile PM60 Manuale utente

Blackbe;rry

Blackbe;rry Q10 Manuale utente

Blackbe;rry

Blackbe;rry Bold 9900 Manuale utente

Blackbe;rry

Blackbe;rry STORM 9500 - VERSION 5.0 Manuale utente

LG LM-K420EMW Manuale utente

ISAFE MOBILE

ISAFE MOBILE IS655.2 Manuale utente

LG Thrive Manuale utente
