Nokia Digital Pen Manuale utente

User’s Guide for Nokia Digital Pen

DECLARATION OF CONFORMITY

We, NOKIA CORPORATION declare under our sole responsibility that the product

SU-1B is in conformity with the provisions of the following Council Directive:

1999/5/EC. A copy of the Declaration of Conformity can be found at

http://www.nokia.com/phones/declaration_of_conformity/.

Reproduction, transfer, distribution or storage of part or all of the contents in this

document in any form without the prior written permission of Nokia is

prohibited.

Nokia is a registered trademark of Nokia Corporation. Bluetooth is a registered

trademark of Bluetooth SIG, Inc. Other product and company names mentioned

herein may be trademarks or tradenames of their respective owners.

Nokia operates a policy of continuous development. Nokia reserves the right to

make changes and improvements to any of the products described in this

document without prior notice.

Under no circumstances shall Nokia be responsible for any loss of data or income

or any special, incidental, consequential or indirect damages howsoever caused.

The contents of this document are provided "as is". Except as required by

applicable law, no warranties of any kind, either express or implied, including, but

not limited to, the implied warranties of merchantability and fitness for a

particular purpose, are made in relation to the accuracy, reliability or contents of

this document. Nokia reserves the right to revise this document or withdraw it at

any time without prior notice.

The availability of particular products may vary by region. Please check with the

Nokia dealer nearest to you.

In some countries there may be restrictions in using Bluetooth devices. Check

with your local authorities.

9310000 / Issue 1

 !

Contents

1. Introduction ........................ 3

Bluetooth wireless technology......... 3

2. Getting started ................... 5

Charging the battery........................... 6

Chargers and batteries.................... 7

Pairing your Nokia Digital Pen......... 7

Pairing the pen from your phone. 7

Activating pairing from your pen 8

3. Using the Nokia Digital Pen

with your compatible phone ...9

Switching the pen on or off.............. 9

Nokia Digital Pen indicators.......... 9

Writing and drawing with

the pen.................................................. 10

Using the notepads........................ 11

Using the stylo settings................ 11

Creating and sending a multimedia

message to the phone ...................... 12

4. Using the Nokia Digital Pen

with a PC ................................13

Installing the PC application .......... 13

Sending and saving notes

on your PC............................................ 13

Resetting the Nokia Digital Pen .... 14

Partial reset...................................... 14

Full reset ........................................... 14

Changing the ink cartridge

of the pen............................................. 15

5. Battery information .......... 16

Charging and Discharging............... 16

Care and Maintenance .........17

 !

Introduction

English

1. Introduction

The Nokia Digital Pen allows you to create colourful and personal

multimedia messages (MMS). Draw a picture or write a poem, and send

it to the compatible phone that supports Bluetooth wireless technology.

Display the image on your phone or forward it as a multimedia message

to another compatible phone or to an e-mail address.

The Nokia Digital Pen also allows you to write meeting minutes or

personal notes, and save them in your PC. The Nokia Digital Pen can save

up to 100 A5 pages, all of which can be sent to your PC by placing the

pen in the Connectivity Stand, which is connected to your PC via the

USB port.

Read this user’s guide carefully before using the Nokia Digital Pen. For

important safety and maintenance information and for details about

phone features, check the user’s guide of your phone.

■Bluetooth wireless technology

The Nokia Digital Pen is specially designed for compatible phones that

support Bluetooth wireless technology and Object Push Profile, Dial-up

Networking Profile, Generic Object Exchange Profile and Serial Port

Profile (A profile is a set of Bluetooth commands that your phone uses to

control the pen).

With the Bluetooth wireless technology you can connect compatible

devices without cables to other products using Bluetooth wireless

technology. A Bluetooth connection does not require that the phone

and the Nokia Digital Pen be in line of sight, but both devices should be

within 10 metres of each other, although the connection can be subject

to interference from obstructions, such as walls, or other electronic

devices.

 !

Introduction

The Nokia Digital Pen is compliant with and adopts Bluetooth

Specification 1.1. However, interoperability between the Nokia Digital

Pen and other products with Bluetooth wireless technology is not

guaranteed because it depends on compatibility. For more information

on the compatibility between the Nokia Digital Pen and other products

with Bluetooth wireless technology, check with your dealer.

" !

Getting started

English

2. Getting started

Note: The use of wireless devices may be restricted in some

situations. Observe any restrictions and obey all signs and

instructions concerning use of wireless devices.

Figure 1 shows the main parts of the Nokia Digital Pen. Note that

operations and some features are network dependent.

1- Ink cartridge

2- Reset hole

3- Ink cartridge removal tool

4- Cap

5- Power on/off indicator

6- Data status indicator

7- Battery level indicator

8- Charging connector

Figure 1

# !

Getting started

Before you can start using your Nokia Digital Pen, you must:

• Charge the battery.

• Pair a compatible phone with the pen, see Pairing your Nokia Digital

Pen on page 7.

You need your Bluetooth passcode to pair the Nokia Digital Pen. The

Bluetooth passcode is included in the sales package. Keep the card in

a secure place.

• To use the Nokia Digital Pen with your PC, install the PC application

to your computer that is provided on the CD-ROM in the sales

package, see Using the Nokia Digital Pen with a PC on page 13.

■Charging the battery

Charge the pen in either of the two ways:

• Plug the charger into an AC wall outlet and connect it to the

charging connector on the pen, see Figure 2 (1).

• Plug the charger into an AC wall outlet, connect it to the

Connectivity Stand, and place the pen in the stand, see Figure 2 (2).

The battery indicator on the pen blinks during charging. Charging the

battery fully takes up to 2 hours depending on the charger. Note that

the pen need not be fully charged before you can use it.

Figure 2

(2)

(1)

$ !

Getting started

English

Chargers and batteries

Check the model number of any charger before using it with this device.

The Nokia Digital Pen is intended for use with the following chargers:

ACP-8, ACP-12 and LCH-12.

Warning! Use only chargers approved by Nokia for use with this

particular enhancement. The use of any other types will

invalidate any approval or warranty applying to the

enhancement, and may be dangerous.

For availability of approved chargers, check with your local dealer.

When you disconnect the power cord of any enhancement, grasp and

pull the plug, not the cord.

■Pairing your Nokia Digital Pen

You must pair the pen with a compatible phone to enable it to

communicate with the phone. You can start the pairing from either your

phone or from your pen. The pen can be paired with one phone at a time.

If you want to use your pen with another phone, you must pair it with

that phone.

Note: Do not point the IR (infrared) beam at anyone's eye or

allow it to interfere with other IR devices.

Pairing the pen from your phone

1. Take the cap off the pen and make sure that both your pen and

compatible phone are switched on. Create the Bluetooth connection

within 5 minutes.

2. Activate the Bluetooth connection from the phone. For more

information, see the user’s guide of the phone.

3. Set the phone to search for Bluetooth devices as instructed in the

user’s guide of the phone.

The phone searches for all Bluetooth devices within approximately

10 metres and displays them in a list.

% !

Getting started

4. Select the Nokia Digital Pen from the list and key in the Bluetooth

passcode included in the sales package

When you have keyed in the correct passcode, the pen vibrates three

times to indicate that pairing has succeeded and that the pen is

ready for use.

Activating pairing from your pen

1. Activate the Bluetooth connection from the phone. For more

information, see the user’s guide of the phone.

2. Use the pen to select the pairing box. (The pairing box is in the end of

the notepad).

The indicator blinks to show that the pen is searching for

Bluetooth devices within approximately 10 metres.

3. The pen selects the nearest device and asks to be paired with it. Enter

the Bluetooth passcode included in the sales package.

When you have keyed in the correct passcode, the pen vibrates three

times to indicate that pairing has succeeded.

4. To allow the pen to create the Bluetooth connection automatically

and to send data to the compatible Bluetooth phone automatically,

set your phone to accept Bluetooth connection requests without

your permission.

In Nokia phones, this can be done by changing your paired devices

settings in the Bluetooth menu.

5. Start using the pen.

Note that the Bluetooth connection between the Nokia Digital Pen and

the compatible phone is active only when the Nokia Digital Pen is

sending data to the phone.

 !

Using the Nokia Digital Pen with your compatible

phone

English

3. Using the Nokia Digital Pen with

your compatible phone

Note: The use of wireless devices may be restricted in some

situations. Observe any restrictions and obey all signs and

instructions concerning use of wireless devices.

■Switching the pen on or off

To switch the pen on, remove the cap. The pen vibrates briefly and the

on/off indicator appears.

To switch the pen off, replace the cap.

To save power and to protect the lens from dirt, always keep the cap on

when you are not using the pen.

Nokia Digital Pen indicators

Off: The pen is switched off or the battery has run out of charge.

White: The pen is ready for use or is registering strokes.

Flashing: The pen has not been used for over 5 minutes. Put the

cap on to save power.

Flashing: The pen is connecting to a Bluetooth device and/or

sending data.

Flashing red: A message transmission has failed due to a

Bluetooth connection failure or other service error.

White: Message has been sent successfully.

Off: The pen is sufficiently charged and the charger is not

connected to the pen.

Red: You need to charge the pen. The pen will soon switch off.

Flashing white: The pen needs to be recharged, but it can still be

used.

White: The pen is fully charged, but the charger is connected to

the pen.

& !

Indice

Altri manuali Nokia Penna digitale

Nokia

Nokia SU-27W Manuale utente

Manuali Penna digitale popolari di altre marche

PENANDFREE

PENANDFREE PT Pen Manuale utente

Kogan

Kogan NBAPCLMGWSA Manuale utente

I.R.I.S.

I.R.I.S. IRISNOTES EXECUTIVE 1.0 Manuale utente

Ctouch

Ctouch 10051955 Manuale utente

Displays2go

Displays2go eMark Pen Manuale utente

eBEAM

eBEAM SMARTMARKER Manuale utente

Livescribe

Livescribe PULSE Manuale utente

Finger System

Finger System I-pen Manuale utente

interactive scape

interactive scape Capore Shape Manuale utente

Legamaster

Legamaster e-Board Manuale di istruzioni

Delta Electronics

Delta Electronics POINTRACER Manuale utente

Anoto

Anoto DP-201 Manuale utente

Benevo

Benevo ultrapen Manuale utente

C-Pen

C-Pen Reader Pen Manuale utente

Panasonic

Panasonic ET-PEN100 Manuale utente

interactive scape

interactive scape Capore Magnify Large Manuale utente

Anoto

Anoto ADP-301 Manuale utente

NEO Smartpen

NEO Smartpen Dimo Manuale utente
