Nokia BH-111 Manuale utente
Nokia Bluetooth Stereo Headset
BH-111
9227195/1.0
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Introduction
About your headset
With the Nokia Bluetooth Stereo
Headset BH-111, you can handle
calls hands-free and enjoy your
favorite music on the go. The
headset is easy to pair with
compatible devices, and you can
switch smoothly between music
and calls.
The surface of this product is nickel-
free.
Warning: This product may
contain small parts. Keep them out
of the reach of small children.
Parts of the product are magnetic.
Metallic materials may be attracted
to the product. Do not place credit
cards or other magnetic storage
media near the product, because
information stored on them may be
erased.
Read this user guide carefully before
using the product. Also, read the user
guide for the device thatyou connect
to the product.
For support, go to
www.nokia.com/support.
About Bluetooth
connectivity
You can use Bluetooth to make a
wireless connection to other
compatible devices, such as
cellular phones.
Devices do not need to be in direct
line-of-sight, but they must be
within 10 meters (33 feet) of each
other. The connection may be
affected by obstructions such as
walls or other electronic devices.
This device is compliant with
Bluetooth Specification 2.1 + EDR
supporting the following profiles:
ENGLISH
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Headset Profile (HSP) 1.0, Hands-Free
Profile (HFP) 1.5, Advanced Audio
Distribution Profile (A2DP) 1.2, and
Audio Video Remote Control Profile
(AVRCP) 1.0 . Check with the
manufacturers of other devices to
determine their compatibility with
this device.
Get started
Keys and parts
1Charger connector
2Volume knob and indicator light
3Microphone
4Rewind key
5Multifunction key
6Fast-forward key
7Play/Pause key
8Audio connector (3.5 mm)
9Clip
Charge the battery
Before using the headset, you
must charge the battery.
When you unplug a charger, hold
and pull the plug, not the cord.
1. Connect the charger to a wall
outlet.
2. Connect the charger cable to
the charger connector on the
headset. The red indicator light
turns green when the battery is
fully charged.
3. Disconnect the charger from
the headset, then from the wall
outlet.
The fully charged battery has
power for up to 7 hours of talk
time, up to 6 hours of music
playing time, or up to 120 hours of
standby time.
ENGLISH
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
When the battery charge is low,
the headset beeps every 5
minutes and the red indicator
light flashes. When the battery is
charging, the red indicator light is
on.
Check the battery charge —
With your headset connected to
your cell phone, press . A green
light indicates a sufficient charge
level. If the light is yellow, you
may need to recharge the battery
soon. If the light is red, recharge
the battery.
Switch the headset on
Press and hold for 2 seconds.
The headset beeps, and a green
indicator light flashes once. The
headset automatically connects
to the last connected device. If you
have never paired your headset
with a device, or you have cleared
the pairings, pairing mode is
activated.
Switch the headset off — Press
and hold for 4 seconds. The
headset beeps, and a red indicator
light flashes once.
If the headset is not connected to
a device within 30 minutes, it
switches off.
Pair and connect your
headset
Before using the headset, you
must pair and connect it with a
compatible device.
1. Make sure the headset is
switched off.
2. Activate the Bluetooth feature
on your compatible device.
3. Switch the headset on. If you
have never paired your headset
with a device, or you have
cleared the pairings, pairing
ENGLISH
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
mode is activated
automatically. If you have
previously paired your headset
with a device, press and hold
for 5 seconds. The green
indicator light starts to flash
quickly.
4. Within about 3 minutes, set
your device to search for
Bluetooth devices. For details,
see the user guide of the
device.
5. On your device, select the
headset from the list of found
devices.
6. If required, enter the passcode
0000.
In some devices, you may need to
make the connection separately
after pairing.
When the headset is paired and
connected, the green indicator
light flashes slowly.
If your cell phone supports the
A2DP Bluetooth profile and has a
music player feature, you can also
use your device to play music
through the headset. If your cell
phone does not support the A2DP
profile, you can separately pair
the headset with a music player
that supports this profile. If you
have paired and connected the
headset to your cell phone,
disconnect the headset from it
before pairing the headset with
the music player.
You can pair the headset with up
to 8 devices, but connect it to only
one device supporting the HFP
profile and another device
supporting the A2DP profile at a
time.
When you switch on your headset,
it automatically connects to the
last used device. To manually
connect the headset to the last
ENGLISH
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
used device, press and hold for
2 seconds. To manually connect
the headset to a device that
supports the A2DP profile, press
.
Wear the headset
Connect the headphones to the
audio connector.
The headset is provided with
different-sized rubber earpieces.
Select the ones that fit you best.
Make sure you insert the earpiece
marked with Linto your left ear
and the one marked with Rinto
your right ear.
You can attach the headset to your
clothing using the clip.
Make and receive calls
When making and receiving calls,
hold the microphone close to your
mouth.
Make a call — When the headset
is connected to your compatible
cellular phone, make a call
normally using your cellular
phone.
Answer or end a call — During a
call, press .
Decline a call — Press twice.
Mute or unmute the
microphone — Press .
You can redial the number you last
called or make a call using voice
ENGLISH
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
dialing, if your cell phone supports
these features with the headset.
Redial the last called
number — When no call is in
progress, press twice.
Activate voice dialing — When
no call is in progress, press and
hold for 2 seconds, and follow
the instructions in the user guide
of your cell phone.
Switch calls between your
headset and your cell phone —
To switch a call from the headset
to a compatible cell phone, or
back to the headset, press and
hold for 2 seconds.
Music
Play music
Listen to your favorite music
wherever you are.
You must pair and connect your
headset to a cell phone that
supports the A2DP Bluetooth
profile and has a music player
feature, or to a compatible music
player that supports this profile.
Warning: Continuous exposure
to high volume may damage your
hearing. Listen to music at a
moderate level.
Play a song — Select the song in
the music player, and press .
Pause or resume playing —
Press .
If you receive or make a call while
listening to music, the music is
paused.
Play the next song — Press .
Play the previous song — Press
twice.
ENGLISH
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Start the current song from the
beginning — Press .
Scroll through the current song
quickly — Press and hold or
.
Stop playing — Press and hold
.
Adjust the volume
Use the volume knob.
If supported, you can also change
the headset volume on the
connected A2DP device.
Settings
Switch the indicator lights
off
You can switch the indicator lights
off if you do not want them to be
shown, for example, during a call.
When the headset is connected to
a device, press and hold and
for 5 seconds. A red indicator
light flashes.
Some indicator lights may still be
shown, for example, when the
battery charge is low.
Switch the lights back on —
When the headset is connected to
a device, press and hold and
for 5 seconds. A green
indicator light flashes.
Clear the pairings
Switch the headset off, and press
and hold for 9 seconds. The
headset beeps twice, and the red
and green indicator lights
alternate. After the settings are
cleared, pairing mode is activated.
ENGLISH
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Troubleshooting
Cannot connect the headset to a
compatible device? Make sure
that the headset is charged,
switched on, and paired with the
device.
Did the headset stop functioning
even though it is charged? Plug
the charger into a wall outlet, and
while you press and hold ,
connect the headset to the
charger.
Product and safety information
Battery and charger
information
This device has an internal,
nonremovable, rechargeable
battery. Do not attempt to remove
the battery from the device as you
may damage the device.
This device is intended for use when
supplied with power from the
following chargers: AC-3, AC-8,
AC-11, AC-15, DC-4 and DC-9 . The
exact charger model number may
vary depending on the type of plug.
The plug variant is identified by one
of the following: E, X, AR, U, A, C, K, or
B.
The battery can be charged and
discharged hundreds of times, but it
will eventually wear out.
Talk and standby times are estimates
only. Actual times are affected by, for
example, device settings, features
being used, battery condition, and
temperature.
If the battery has not been used for
a long time, to begin charging, you
may need to connect the charger,
then disconnect and reconnect it.
ENGLISH
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Altri manuali per BH-111
1
Indice
Lingue:
Altri manuali Nokia Cuffia
Nokia
Nokia 02705Q5 Manuale utente
Nokia
Nokia BH-903 - Headset - Ear-bud Manuale utente
Nokia
Nokia BH-902 Manuale utente
Nokia
Nokia BH-109 Manuale utente
Nokia
Nokia BH 213 - Headset - Over-the-ear Manuale utente
Nokia
Nokia BH-900 Manuale utente
Nokia
Nokia BH 212 - Headset - Over-the-ear Dimensioni
Nokia
Nokia Reaction Manuale utente
Nokia
Nokia BH 301 - Headset - Over-the-ear Manuale utente
Nokia
Nokia BH-303 - Headset - Over-the-ear Manuale utente
Nokia
Nokia BH-800 Manuale utente
Nokia
Nokia BH-500 Manuale utente
Nokia
Nokia BH 102 - Headset - Over-the-ear Manuale utente
Nokia
Nokia HDW 3 - Headset - Over-the-ear Manuale utente
Nokia
Nokia BH-700 Manuale utente
Nokia
Nokia BH 604 - Headset - Binaural Manuale utente
Nokia
Nokia DVB-H Manuale utente
Nokia
Nokia BH-205 Manuale utente
Nokia
Nokia BH-217 Manuale utente
Nokia
Nokia BH-106 Black Manuale utente
