１.Overview
TS01E 8sw communication system is a remote control system of ON/OFF control of 8
switches by unidirectional communication, which is a combination of a transmitter
(TS01Etx8swBD) equipped with a specific low power radio 426 MHz band module TS 01
E and a receiver (TS 01 E rx 8 sw RXBD).
Register the ID of the transmitter in the receiver, pair it and use it. In addition, since
frequency channels can be selected from 7 channels, multiple systems can be used
within the same area.
The communication distance is about 100 m in the forecast. * There is also a long
distance type (LDM).
When the 8 switch input of the transmitter is grounded(GND), it enters the
transmission and the output of the corresponding receiver module goes to H level.
The receiver has a hold function that outputs H level for 2.5 seconds each time valid
data is received.
Therefore, when you instantly press the button of the transmitter, a pulsed output of 2.5
seconds is obtained from the receiver, and if you hold down the button of the transmitter,
the output of the receiver will remain on.
Since the transmitter has a transmission time limit of 5 seconds transmission and 2
seconds pause due to the Radio Law, transmission stops for 2 seconds, but this 2.5
second supplement enables continuous transmission operation.
The time it takes for the receiver to turn off after releasing the transmitter's button is
about 2.5 seconds.
The TS01E receiver application board is common to TS 02 E.
