DMS-10 and DMS-100 Families
Billing Media Converter II
Bisynchronous
1997 Quick Reference Guide
97Q3 02.01 Standard July 1997
297-6201-501
Your guide to:
• Maintenance commands
• Index Corruption Maintenance
• Replacement procedures
• PCA switch setting and jumper options
This Quick Reference Guide applies to all EMC chassis
(metal front door panels) Bisynchronous (BISYNC) style
Billing Media Converter II (BMC II) systems.
Other style BMC II systems cannot use this Quick
Reference Guide.
BISYNC BMC II systems can be identified by the
information on their rear panel labels.
Catalog Number or Model Number:
NT8M0xxC (EMC Chassis models)
DMS-10 and DMS-100 Families
Billing Media Converter II
Bisynchronous
1997 Quick Reference Guide
Publication Number: 297-6201-501
Applicability: 97Q3
Document Release: Standard 02.01
Date: July 1997
Copyright 1997, 1996 Northern Telecom
All rights reserved
Printed in the United States of America
Northern Telecom Confidential: The information contained in this
document is the property of Northern Telecom. Except as specifically
authorized in writing by Northern Telecom, the holder of this document shall
keep all information contained herein confidential and shall protect same in
whole or in part from disclosure and dissemination to third parties and use
same for evaluation, operation, and maintenance purposes only.
Information is subject to change without notice. Northern Telecom reserves
the right to make changes in design or components as progress in
engineering and manufacturing may warrant. The DMS-100 version of this
equipment has been tested and found to comply with the limits for a Class A
digital device pursuant to Part 15 of the FCC Rules, and the radio interference
regulations of the Canadian Department of Communications. These limits are
designed to provide reasonable protection against harmful interference when
the equipment is operated in a commercial environment. This equipment
generates, uses and can radiate radio frequency energy, and if not installed
and used in accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment in a
residential area is likely to cause harmful interference in which case the user
will be required to correct the interference at his own expense.
DMS is a trademark of Northern Telecom.
iii
BMC II BISYNC Quick Reference Guide
Publication history
May 1996 Standard 01.01
July 1997 Standard 02.01.
• Integrated the new Quick Reference Guide template into this document.
• Added DMS-10 and DMS-100 software and firmware files reference
table to BMC II BISYNC Figures.
• Modified Maintenance Commands with commands left out of first
issue:
—BVAL
— RMID.
• Added a disk drive size and related number of tracks table in Mainte-
nance Commands.
• Added a CMD and STA code descriptions table to the TEC/DSI Com-
mands subsection of Maintenance Commands.
• Removed the Bus Terminator PCA from the list of valid PCAs in the
Miscellaneous PCA Replacement Procedure.
• Added notes regarding the location of the defect map and HEAD and
CYLINDERS out of range to step 9 of the Install replacement disk
drive procedure in the Disk Drive Replacement Procedure.
• Added note concerning the placement of the J5 jumper to step 8 of the
Disk Crossover PCA Replacement Procedure.
• Added the following to the PCA Switch and Strap Settings:
— CPU LED display codes table
— Disk Interface PCA table.
• Modified statements in various sections concerning firmware to verify
file name and release level prior to installation of replacement PCA.
• Modified PCA options statements in various sections to refer to the
PCA Switch and Strap Settings to verify settings prior to installation.
• Corrected various minor format and content errors throughout the docu-
ment.
iv
297-6201-501 97Q3 Standard 02.01 July 1997
v
BMC II BISYNC Quick Reference Guide
Contents
BMC II BISYNC Figures 1
Maintenance Commands 5
Alarm Manipulation Commands 5
Boot Commands 5
Disk Operations Commands 5
File Index Maintenance Commands 6
File Manipulations Commands 7
Miscellaneous Commands 8
Polling Link Commands 8
Processor Activity Command 8
Program Version Commands 9
Site Dependent Data Commands 9
Statistics Commands 12
System Clock Commands 12
TEC/DSI Functions Commands 13
Testing Commands 14
Guide to Index Corruption Recovery 15
Version number missing from index, but is on disk 15
Recognition 15
Recovery 17
Sequence numbers not incrementing properly 18
Recognition 18
Recovery 20
TOLIDX OPEN ERROR:03 22
Miscellaneous PCA Replacement Procedure
(NT6M60xx, NT6M62xx, NT6M63xx, NT6M64xx,
NT6M66xx, NT6M70xx, NT6M89xx, or
NT6M90xx) 25
Disk Replacement Procedure 29
Removing the Faulty Disk Drive 29
Installing the Replacement Disk Drive 30
Disk Crossover PCA Replacement Procedure
(NT6M72xx) 33
Error Control II PCA Replacement Procedure
(NT6M65xx) 37
Error Control II Jumper PCA Replacement
Procedure (NTM609xx) 39
vi
297-6201-501 97Q3 Standard 02.01 July 1997
Power and Alarm Communications PCA
Replacement Procedure (NT6M84xx) 41
Power Supply Replacement Procedure
(NT6M71xx) 43
PCA Switch and Strap Settings 47
List of Figures
BMC II BISYNC Front View 1
DMS-10 Side View 2
DMS-100/DCO Side View 2
Version number missing 16
Version number recovered 17
Sequence numbers not incrementing 19
Sequence numbering corrected 20
List of Procedures
Miscellaneous PCA replacement 25
Remove faulty disk drive 29
Install replacement disk drive 30
Disk Crossover PCA replacement (NT6M72xx) 33
Error Control II PCA (NT6M65xx) replacement 37
Error Control II Jumper PCA (NTM609xx) replacement 39
Power and Alarm Communications PCA (NT6M84xx)
replacement 41
Power Supply (NT6M71xx) replacement 43
List of Tables
BMC II BISYNC software and firmware files 3
Disk drive size and related number of tracks 6
Valid status values for CMD and STA bytes 13
NT6M62xx CPU PCA 47
CPU LED display codes 47
NT6M63xx EPROM PCA (MEM1) 48
NT6M60BA Quad SIO (Slot 6), BMC set to INTERNAL timing
and Polling Modem set to EXTERNAL timing 49
NT6M60BAQuadSIO(Slot 6),BMC setto EXTERNALtiming
and Polling modem set to INTERNAL timing 49
Baud Rate Reference 50
NT6M84BA PWR/ALM Communications PCA, BMC set to
INTERNALtimingandPollingmodemsettoEXTERNAL
timing 51
NT6M84BA PWR/ALM Communications PCA, BMC set to
EXTERNALtimingandPollingmodemsettoINTERNAL
timing 51
NT6M66xx Disk Interface PCA 51
NT6M70xx DMS-100 DSI PCA 52
NT6M89xx DMS-10 TEC PCA 53
NT6M90xx 800 bpi DCO TEC PCA 54
NT6M90xx 1600 bpi DCO TEC PCA 55
1
BMC II BISYNC Quick Reference Guide
BMC II BISYNC Figures
Figure 1
BMC II BISYNC Front View
NT6M62xx Central Processor Unit (CPU) with DMAPCA
NT6M63xx EPROM PCA
NT6M64xx DRAM with Extended Memory PCA
NT6M65xx Error Control II PCA
NTM609xx Error Control Jumper PCA
NT6M60xx Quad Serial Input/Output (SIO) PCA
NT6M66xx Disk Interface PCA
NT6M70xx Data Stream Interface (DSI) PCA (DMS-100 systems only)
NT6M89xx Tape Emulation Card (TEC) PCA (DMS-10 systems only)
NT6M90xx TEC PCA (DCO* systems only)
NT6M68xx Bus Terminator PCA
NT6M71xx Power Supply
NT6M72xx Disk Drive: AA - 72MB; BA - 140MB; CA - 30MB;
NT6M72xx Disk Crossover PCA These packs are
NT6M84xx Power/Alarm Communication PCA located in the
NT6M56xx Fan Filter PCA back of the BMC
* DCO is a registered trademark of Siemens Stromberg-Carlson.
LT
AProcessor
J8 J10J9
J8 J10J9 Chassis
GRD
NT6M62xx
NT6M63xx
NT6M64xx
NT6M66xx
NT6M70/89/90xx
NT6M68xx
NT6M60xx
NT6M65xx
NT6M70/89/90xx
NT6M62xx
NT6M63xx
NT6M64xx
NT6M66xx
NT6M70/89/90xx
NT6M68xx
NT6M60xx
NTM609xx
NT6M70/89/90xx
ADisk Drive
NT6M72xx
BDisk Drive
NT6M72xx
Power Supply
NT6M71xx
NT6M71xx
Power Supply B Processor
AB
OP
2BMC II BISYNC Figures
297-6201-501 97Q3 Standard 02.01 July 1997
Figure 2
DMS-10 Side View
Figure 3
DMS-100/DCO Side View
J1 - SDI TTY
J2 - Software Download
J3 - Polling link
J4 - Maintenance TTY
J
1J
2
J
3J
4
J
9J
1
0
J1 - Not Used
J2 - Software Download
J3 - Polling Link
J4 - Maintenance TTY
J
1J
2
J
3J
4
J
9
J
1
0
