NORTHPOLE 88-97-08 Manuale utente

TROUBLESHOOTING GUIDE

PROBLEM

1. CONDENSATION

2. MILDEW

3. REPAIRING A TEAR

4. FAULTY ZIPPER

5. FLOOR CONDENSATION

SOLUTION

THIS IS CAUSED BY LOWER TEMPERATURES ON OUTSIDE OF PRODUCT COMBINED

WITH BODY HEAT ON INSIDE OF PRODUCT. WHEN THIS OCCURS, AVOID TOUCHING

WALLS TO REDUCE CONTACT LEAKAGE. LEAVING DOORS AND WINDOWS OPEN WILL

REDUCE CONDENSATION.

TO AVOID MILDEW, NEVER STORE YOUR PRODUCT WET OR DAMP. HOWEVER, IF

MILDEW OCCURS, USE A SOFT BRISTLE BRUSH OR SPONGE WITH MILD SOAP TO

CLEAN. LET DRY IN THE SUNLIGHT AND APPLY SEAM SEALER COMPOUND ON INSIDE

SEAMS.

PRODUCTS ARE MANUFACTURED WITH ZIPPERS WHICH, IF THE ZIPPER SEPARATES, IT

CAN BE FIXED BY MOVING THE SLIDER TO THE BEGINNING OF THE ZIPPER TAPE AND

REWORKING THE ZIPPER. IF THIS DOESN'T WORK, A REPLACEMENT ZIPPER MAY BE

ORDERED FROM OUR PARTS DEPARTMENT, AND MAY BE INSTALLED BY A REPAIR

SHOP IN YOUR AREA.

FOR SMALL TEARS USE A SELF-ADHESIVE PATCH KIT. WE RECOMMEND A REPAIR

SHOP FOR LARGER TEARS.

TO PREVENT FLOOR CONDENSATION USE A GROUND CLOTH. PLACING A GROUND

CLOTH UNDER YOUR PRODUCT WILL PROLONG ITS LIFE. GROUND CLOTH SIZE

SHOULD BE SLIGHTLY SMALLER THAN PRODUCT FLOOR SIZE.

PERHAPS WE'VE MISSED SOMETHING IN OUR TROUBLESHOOTING GUIDE. FEEL FREE TO GIVE US YOUR IDEAS ON

"TRICKS OF CAMPING", REPAIR PROCEDURES, FEATURES YOU'D LIKE TO SEE, OR OTHER RECOMMENDATIONS.

SEND THEM TO:

NORTHPOLE LIMITED

23 Town and Country Drive

Washington, MO 63090

(ONLY APPLICABLE ON PRODUCTS WITH FLOOR)

NOTICE!

FOR MISSING PARTS:

1-800-775-1965 or 1-800-366-1599

A Message To Our Customers

Thank you for purchasing a quality product manufactured by NorthPole Limited. As the world leader in outdoor recreational

roducts, we pride ourselves in delivering high quality and customer friendly products. As with any new product, it is very

important to read all the information on safety, assembly/disassembly and care of your new purchase prior to usage.

As a valued customer, your satisfaction is very important to us. We at NorthPole Limited welcome your feedback and

look forward to continuing our relationship with the development of new, innovative products to suit your needs.

Please visit your favorite retailer for other quality products from NorthPole Limited.

IMPORTANT: We advise you to assemble this product at least once at home before going on a trip to ensure that you have

attained a satisfactory knowledge of the assembly process. Being familiar with your product will make it easier if you have

to set up in the dark or under adverse conditions.

IMPORTANT SAFETY AND TIP INFORMATION

TO MAXIMIZE THE ENJOYMENT OF YOUR PRODUCT PLEASE ASSEMBLE AND USE YOUR PRODUCT AS SAFELY AS

POSSIBLE. THE PURPOSE OF THE SAFETY ALERT SYMBOL IS TO CALL YOUR ATTENTION TO POSSIBLE

HAZARDS RELATING TO THE USE AND ASSEMBLY OF YOUR PRODUCT. THE PURPOSE OF THE TIP SYMBOL IS

TO CALL YOUR ATTENTION TO SUGGESTIONS THAT WILL ASSIST YOU IN THE ASSEMBLY/DISASSEMBLY PROCESS

AND ENHANCE YOUR CAMPING EXPERIENCE. WHEN YOU SEE THESE SYMBOLS, PLEASE CLOSELY FOLLOW THE

INFORMATION PROVIDED.

WARNING

• KEEP ALL FLAME AND HEAT SOURCES AWAY FROM THIS TENT FABRIC. This fabric is not fireproof! It is made with

flame resistant fabric, which meets CPAI-84 specifications. The fabric may burn if left in continuous contact with any flame

source. The application of any foreign substance to the fabric may render the flame-resistant properties ineffective.

• Do not erect this product near an open flame.

• Never use any fuel burning, oxygen consuming devices, or any device that produces fumes (including, but not limited to

cooking stoves, lanterns, candles, hibachis, or heaters) in or around your product. Inhalation of fumes may result in

carbon monoxide poisoning, injury and/or death.

• This product is not waterproof!

• Your product is water repellent, however, during heavy rain some leakage may occur. Keep objects from touching the

inside, as objects may cause leakage at the point of contact.

• To prevent seam leakage (floor seams in particular), a seam sealer compound must be applied to the seams. Use

recommended water repellent compounds on our product. Read the label on any product before using. Questions?

Call our Customer Service number.

• Your recreational product is made from synthetic fabric that has been treated and is highly resistant to the sun’s Ultraviolet

(UV) light. No fabric can withstand prolonged exposure to sunlight. UV damage is not covered by the limited warranty.

• Do not spray or apply insecticide or pesticide on your product. It may damage UV resistant and/or water repellent

properties of your product. Any damage caused by applying insecticide or pesticide on your product is not covered

bythe limited warranty.

• Our recreational products are constructed to rigid specifications. They are not made, however, for extreme weather,

climates, or environments. Modification, abuse and extreme weather are some conditions that may adversely affect

the structural integrity.

• Additional precautions may be necessary during inclement or “surprise” weather conditions. Here are some tips that

may help during these times:

Use guy lines to help secure your structure during periods of heavy winds.

Storms or steady rains may collect in water pockets on the roof. This will add weight, which can weaken the overall

structure causing the uprights to collapse. Maintain a watchful eye and remove any water accumulation that may occur.

• Your product must be stored dry. One of the easiest ways to damage your product is storing it while it is wet. Storing a

wet tent as short as 24 hours in warm weather is likely to cause mildew on the fabric. Once mildew sets in, the stains are

permanent. Stains cannot be removed without potential harm to the fabric coatings and are not covered by the limited

warranty.

• If you must close camp in the rain, open your product and set it up to allow it to dry as soon as possible. Even when your

product appears to be dry after use, it is always best to unfold and assure it is completely dry before storing. Hanging it

outside or even leaving loosely clumped in your house for a few days, turning it inside and out to assure it has dried

everywhere, can help prevent damage.

• This product is not machine washable. To clean product, use mild soap and let it dry thoroughly before storage.

✔QTY. DESCRIPTION PART NUMBER

FABRIC BODY

___ 1 Tent Body N/A

POLES

___ 1 Steel, chain-corded Center Roof Pole w/ R-Springs and Hubs- green CRPL-373GR

___ 2 Steel, chain-corded Side Roof Pole w/ R-springs &Hubs- green SRPL-373GR

___ 6 Steel, chain-corded Roof Gable Pole- green RGPL-171GR

___ 6 Steel, chain-corded Leg Pole w/ R-Springs- green LPOL-171GR

___ 2 Steel, curved Middle Eave Pole w/ R-Spring (spring on outside right)- green EPLM-28GR

___ 4 Steel, curved Corner Eave Pole w/ R-Spring (spring on outside left)- green EPLC-28GR

___ 2 Fiberglass, shock-corded Bay Window Pole w/ corners- black BWPL-25CR79

If you wish to order a complete set of poles, please use:

___ 1 Pole Set of all Twenty-Three Steel & Fiberglass Poles- green/black PSET-GRBK

RAINFLY

___ 1 Rainfly w/ webbing loops; green/ brown trim RFLY-GRBR06

CARRY BAG

___ 1 Carry Bag- w/wheels- navy CBAG-950NV

UNIVERSAL PARTS

___ 25-Way Hub- center side (one in center of each SRPL pole) 5WAY-333-1

___ 2 4-Way Hub- left side (one to left of center on each SRPL pole) 4WAY-334-1

___ 2 4-Way Hub- right side (one to right of center on each SRPL pole) 4WAY-335-1

___ 2 3-Way Hub- gable top (one to front end and one on rear end of CRPL pole) 3WAY-120-4

___ 14-Way Hub- gable middle (one in middle of CRPL pole) 4WAY-120-3

___ 1Remote Control Light Set; 2pc LITERC

___ 2 Shelf; 3 Tier SHF3-12X15

___ 2 Support Strap with clips and slider STRP-307

___ 1Pole Bag PBAG-46IN

___ 1 Stake Bag SBAG-16IN

___ 8 Guy Rope; 3M GROPE-3M

STAKES

___ 1 Stake Set of Sixteen 9 in. plastic stakes SSET-16PL9IN

Review your parts list above to make sure all parts listed above have been included in your package.

Please do NOT return product to store.

Call our TOLL FREE Numbers: 800 775-1965 or 800-366-1599 Monday-Friday 7am - 5pm CST

Mention your complete Model Number so that our Representative may assist you!

Model # 88-97-08 Vacation Cottage

14 ft. x 14 ft. x 92 in.

CRPL-373GR

SRPL-373GR

RGPL-171GR

LPOL-171GR

EPLM-28GR

EPLC-28GR

BWPL-25CR79

STRP-307

STEP 1: Verify Package Contents

Verify package contents by emptying contents of

bag(s) and confirming all parts are included and

undamaged. Tip: Do this at home before you leave

on your trip.

STEP 2: Assemble the Roof Poles

A) Select a smooth level site and spread out your

tent.

B) Lay all parts of structure out on a flat open area.

Extend tent poles, and sort into groups by style i.e.

roof gable poles, leg poles, eave poles, etc…. This

will simplify the assembly process.

C) Assemble roof ridge poles and attach hubs. Lock

poles into hubs by popping R-springs on poles into

slots on underside of hubs.TIP: Note that orienta-

tion of hubs must be correct.

D) Attach the gable poles to corre-

sponding openings on hubs.Important:

Make sure R-springs snap into hub

slots and poles are locked into place.

STEP 3: Set Up the Tent

A) Take tent fabric and

locate brass S-hooks

on peaks and roofline

of tent. Attach S-hooks

to small holes on

underside of corresponding hubs.

B) Snap Quick Clips (attached to tent

body) over roof ridge poles to shape

roof.

C) Snap support straps in place over roof ridge

poles.

D) Insert leg poles into lower hub sockets. TIP:

Make sure end of leg pole with R-spring on it is the

one you are inserting into hub.

E) Insert opposite ends of leg poles onto pin-rings at

base of tent.

F) Insert curved eave poles into hubs, making sure

R-springs lock into hub slots.

G) Snap Quick Clips over leg poles.

H) Slide bay window poles through

bay window pole sleeves.

I) Secure poles to tent fabric using

nylon fasteners provided.

STEP 4: Attach the Rainfly

A) Drape rainfly over tent top.

B) Insert ends of eave poles into pole

pockets located on corners of rainfly.

STEP 5: Stake the Tent

A) Secure tent by driving stakes

through webbing loops located at

base of tent. TIP: Make sure tent

floor is stretched tight as you stake it

down.

B) To secure guy lines, find the guy

line plastic slider and look for the por-

tion of line opposite the knot. Pull this

portion, forming a loop (works just like

a slip knot!)

C) Extend guy line to ground and drive a stake

through the loop to secure. Tip: make sure you drive

the stake through this loop to hold the guy line taut.

You can always slide the plastic slider toward the

product’s frame to readjust the tension. Repeat for

remaining guy lines.

STEP 6: Add Accessories

A) Attach shelf unit to tent by taking

S-hooks and attaching them to the

loops in the tent located at the back of

tent.

B) The divider has toggles on the

edges, which attach to fabric loops

inside tent. To install divider, push

each toggle through its corresponding

loop.

ASSEMBL

Y INSTRUCTIONS

THIS RECREATIONAL PRODUCT REQUIRES TWO ADULTS TO ASSEMBLE.

* Unless otherwise specified all instructions will be given assuming the assembler is facing the front opening of the tent.

*Carefully fold out your poles, using caution to prevent snapping the shock-cording. Make sure each pole segment is “seated” into the next section

before flexing the pole during set-up.

If your product does not work properly because of a defect in materials or workmanship, NorthPole Limited will, for 6 months from the date of purchase, at its option

either (a) repair our product with new or refurbished parts, or (b) replace it with a new product. The decision to repair or replace will be made by NorthPole Limited.

NORTHPOLE LIMITED RESERVES THE RIGHT TO MAKE SUBSTITUTIONS TO WARRANTY CLAIMS IF PARTS ARE UNAVAILABLE OR OBSOLETE.

If repair is needed during the limited warranty period, the purchaser will be required to furnish a sales receipt as proof of purchase indicating date of purchase, amount

paid, and place of purchase. Product will not be covered under warranty due to damages resulting from misuse, excessive or abusive usage, and/or inclement weather

conditions (i.e. wind storms, hurricanes, lightning storms, tornadoes). Acts of God resulting in damage to tent and its components are not covered under this limited warran-

ty. In such event, the consumer assumes cost of needed parts. NorthPole Limited is not responsible for normal wear and tear, zipper exhaustion, or the natural breakdown

in materials that occurs with extended use.

UNDER NO CIRCUMSTANCES SHALL NORTHPOLE LIMITED BE LIABLE FOR ANY INCIDENTAL OR CONSEQUENTIAL DAMAGES. Some states do not allow the

exclusion or limitation of incidental or consequential damages, so the above limitation may not apply to you.

NORTHPOLE LIMITED EXPRESSLY EXCLUDES ALL WARRANTIES, INCLUDING, BUT NOT LIMITED TO, ANY IMPLIED WARRANTIES OF MERCHANTABILITY AND

FITNESS FOR A PARTICULAR PURPOSE. Some states do not allow the exclusion or limitation of implied warranties, so the above exclusion may not apply to you.

NOTWITHSTANDING ANYTHING TO THE CONTRARY, NORTHPOLE’S AGGREGATE LIABILITY, WHETHER IN CONTRACT OR TORT, SHALL BE LIMITED TO ACTU-

AL DIRECT MONEY DAMAGES IN AN AMOUNT NOT TO EXCEED THE PRICE PAID BY THE END-USER FOR THIS PRODUCT.

HOW TO OBTAIN WARRANTY SERVICE:Call the toll free number during the business hours mentioned below. You must have a copy of your purchase receipt from an

authorized dealer as proof of purchase at time of call.

HOW TO ORDER REPLACEMENT PARTS: When ordering replacement parts, always include Model Number, Part Number, and Part Description.

Call toll free 1 (800) 775-1965 · Mon-Fri, 7:00 a.m. to 5:00 p.m. (Central Standard Time)

Limited 6 Month Warranty

STEP 1: Remove the Stakes

Carefully remove stakes by pulling out the hook ends.

Tip: Do not pull or tug at the stake loops sewn onto the

fabric body. Remove excess soil from the stakes and

store them in their bag.

STEP 2: Remove the Rainfly

A) Remove eave pole ends from pockets on corners of

rainfly.

B) Slide rainfly off tent and fold for storage.

STEP 3: Take Down the Divider Curtain

Unfasten divider toggles from fabric loops to take down

divider. Fold divider for storage.

STEP 4: Take Down the Bay Windows

A) Unfasten nylon fasteners that secure window poles to

tent fabric.

B) Remove window poles from pockets and slide poles

out by carefully pushing them through the sleeves away

from the end at which you are standing. Tip: By following

these instructions, you will minimize risk of damaging

poles and/or snapping shock-cording.

STEP 5: Take Down the Tent

A) Unfasten Quick Clips from tent frame.

B) Remove eave poles from hubs.

C) Remove leg poles from pin-rings and lower hub sock-

ets.

D) Detach S-hooks from hubs.

E) Disconnect all poles from hubs. Carefully fold poles

and store them in their bag.

STEP 6: Fold the Tent

Fold tent into rectangular shape the width of pole bag.

Lay pole bag at one end of tent and roll tightly together,

slowly squeezing air out as you go. You can roll rainfly

together with tent in this step. Store tent in carry bag

provided. (Following these instructions will make it easi-

er to fit tent into bag.)

DISASSEMBLY INSTRUCTIONS

* Make sure all windows and doors are unzipped to disassemble.

* Store all poles and stakes in their corresponding bags to prevent possible tearing or damage to fabric.

Indice

Altri manuali NORTHPOLE Tenda

NORTHPOLE

NORTHPOLE 37-91-51 Manuale utente

Manuali Tenda popolari di altre marche

OZTENT

OZTENT JV SIGNATURE EDITION Manuale utente

GigaTent

GigaTent Summer Chalet Mini Tent Manuale utente

Coleman

Coleman 2000007827 Manuale

ShelterLogic

ShelterLogic 107153 Manuale utente

Outsunny

Outsunny 84C-230 Manuale utente

Napier

Napier SPORTZ COVE 61 Series Manuale utente

EuroTrail

EuroTrail ATLANTIS PRO Manuale utente

Reimo

Reimo Marina Manuale utente

TiiTENT

TiiTENT TB300 Manuale utente

Coleman

Coleman 2000033134 Guida all'installazione

Ozark Trail

Ozark Trail W784.1 Guida rapida

SlingFin

SlingFin CrossBow 2 Manuale utente

Coleman

Coleman 9600-141 Manuale utente

Palram

Palram Arizona 5000 Wave - WINGS Manuale utente

COVERPRO

COVERPRO 56184 Istruzioni per il montaggio

Vango

Vango Zenith 100 Manuale utente

Costway

Costway PATIOJOY OP70818 Manuale utente

Clarke

Clarke PUC 88 Manuale utente
