NOUS E6 Manuale utente
2
Button
Enter configuration mode: Press and hold the button for 5 seconds until the screen blinks, the
device will enter configuration mode
Shift C/F: Double-click to cycle switching between °С and °F temperature unit
Trigger to report: Single-click to report its current status to cloud server
Screen
3
On the back
Quick Installation Guide
Note: the smart gateway must be added first before adding the sub-device.
1.Power on the sensor
1).Open the battery cover
4
2).Insert the battery into the battery compartment
(please note battery positive and negative)
3).Close the battery cover
2.You will need Nous ZigBee GateWay/Hub. Open “Nous Smart Home” app, Enter the
gateway homepage and click “Add subdevice”
5
3.Press the reset button for 5 seconds, till the screen blink, then click the confirm button
which shows and "LED already blink" follow the in-app instructions to connect the sensor
to your gateway.
4.Waiting for a few seconds, This device is added successfully and you may rename it.
Click “Done” to finish the setting.
6
5.Put it where you need it.
6.Nous Smart Home app settings:
1).The temperature unit setting
2).The temperature update sensitivity setting
7
3).Limits setting of Low temperature alarm and High temperature alarm.
8
4).Enable/disable alarm setting
9
