Novatel Novatel Wireless 3352 Manuale utente

your mobile

hotspot

Novatel Wireless 3352

User Guide

Novatel Wireless 3352 user guide2 3

contents

nNovatel Wireless 3352 mobile hotspot

nBattery

nCharger

nUser guide

system requirements

Any device with WiFi 802.11 b/g and an internet browser.

You can connect up to 5 devices simultaneously.

hello

welcome to Orange mobile hotspot

With your Novatel Wireless 3352 mobile hotspot you can connect your

WiFi gadgets to the internet when you’re out and about. Access email

away from the ofﬁce, connect with friends when you’re on the move and

keep up with the latest information anywhere.

Take any of your WiFi-enabled devices on the net with your mobile hotspot

– a personal internet bubble, just for you. No wires, no complicated

software – just the internet on all your gadgets, everywhere.

Turn over to get your WiFi gadgets online in no time.

Novatel Wireless 3352 user guide4Novatel Wireless 3352 user guide 5

your mobile hotspot

microSD slot

connection LED

micro USB port

WiFi LED

master reset

battery compartment SIM compartment

Novatel Wireless 3352 user guide6Novatel Wireless 3352 user guide 7

inserting the battery and SIM Card

Before connecting to your mobile hotspot for the ﬁrst time, you must

insert your Orange SIM Card, then insert and fully charge the battery.– so make

a note of both.

1Slide open the battery cover 2Take note of the SSID (network

name) and WEP password (key).

These can be found inside

the battery cover

4Insert the battery,

line up the contact points

5Replace the battery cover 6Charge the battery

for four hours

3Insert the SIM Card

SSID (network name)

WEP password (key)

Novatel Wireless 3352 user guide8Novatel Wireless 3352 user guide 9

connecting to your mobile hotspot

Input the WEP password

(key) and you’ll be connected

to your mobile hotspot

and the internet. You can

connect up to 5 of your

gadgets at the same time.

After your mobile hotspot is

fully charged, press the Power

button to turn it on. The Power/

Connection LED and WiFi LED

will light up.

You can connect to your

mobile hotspot the same way

you would connect to any

WiFi router. Go to the WiFi

connection application on the

device you want to connect.

Find the SSID (network

name) in your list of available

networks and select Connect.

SSID (network name) refers to the unique

name that will come up when you are

searching for WiFi signal on your gadgets.

WEP password (key) is the password that will

connect your gadgets to the mobile hotspot.

red Flashing: Low battery

Solid: Portable WiFi Hotspot has encountered

an error

amber Flashing: Battery charging

Solid: Battery fully charged

green Flashing: 2G (GPRS/EDGE) service is available

Solid: Connected to a network using 2G (GPRS/EDGE)

violet Flashing: 3G (UMTS/HSPA) service is available

Solid: Connected to a network using

3G (UMTS/HSPA) UMTS/HSPA

blue Flashing: Roaming service is available

Solid: Connected to a roaming network

blue WiFi No Light: WiFi is off or the mobile hotspot is connected

by USB port*

Flashing: WiFi is on with devices connected

Solid: WiFi is on with no devices connected

*USB cable can be purchased separately:

visit www.orangeaccessories.co.uk

blue/green Flashing: SMS notiﬁcation

Novatel Wireless 3352 user guide10 Novatel Wireless 3352 user guide 11

your Orange landing page

Whenever you connect to the internet with your Novatel Wireless 3352

mobile hotspot you’ll see the Orange landing page. Your Orange landing

page comes with widgets like a data usage manager, SMS sender, GPS

GeoSearch and weather station.

Customise your landing page with more widgets to quickly access the

information that’s important to you.

caring for your mobile hotspot

nAvoid storing your device in extreme temperatures.

nStore your device in a dry and clean environment.

nAvoid spilling any liquid on your device or immersing it in water.

nDo not place any labels on the device as doing so could alter the

sensitivity of the antenna.

nDo not force the cable into the USB port.

nDo not force the SIM card into the SIM card slot.

nDo not force the microSD card into the microSD slot.

nDo not apply force to the top or bottom of your device.

nDetach the USB cable (sold separately) from your mobile

hotspot before transport.

For regulatory and safety information please visit: www.novatel.com

Note: USB cable not included but

can be purchased separately at

www.orangeaccessories.co.uk

Novatel Wireless 3352 user guide12

we’re always here to help

just give us a call

0844 873 8586

Opening hours are 7am - 11pm, 7 days a week.

Calls cost 5p a minute from a BT landline or Orange home phone.

Costs may vary when calling from a mobile phone.

go online

orange.co.uk/help

Visit any time of the day or night.

This booklet is printed entirely on recycled paper containing

100% post-consumer recovered ﬁbre. You can recycle it again.

Everything Everywhere Limited

Registered Ofﬁce

Hatﬁeld Business Park, Hatﬁeld

Hertfordshire, AL10 9BW

orange.co.uk
