Novus NVC-11BD Manuale utente
USER`S MANUAL VER. 1.0
Mini B/W DOME CAMERA
NVC-11BD
NOVUS SECURITY Sp. z o.o.
359 Pulawska Str., 02-801 Warsaw, Poland
tel: +4822-546-0-500; fax: +4822-546-0-519
[email protected]; www.novuscctv.com
© Copyright 2003, NOVUS SECURITY Sp. z o.o.
NVC-11BD Mini B/W dome camera, User`s Manual
2
© Copyright 2003, Novus Security Sp. z o.o. All rights reserved.
Table of Contents
1. Important information before installation...................................................................................3
2. Safety instructions..........................................................................................................................4
3. Installation ......................................................................................................................................5
4. Specifications..................................................................................................................................6
NVC-11BD Mini B/W dome camera, User`s Manual
3
© Copyright 2003, Novus Security Sp. z o.o. All rights reserved.
1. Important information before installation
Please read and observe all instructions and warnings contained in this manual. Retain the original
manual for future reference. When unpacking your new product, first please compare the received
items with your order list, second check for damaged items. If there is anything missing or damage in
evidence, please do not install or operate the product, then contact the dealer for assistance
immediately. Never try to service this product by yourself. Opening the covers may expose you to
dangerous power voltage or other hazards. For your protection, take a moment to complete the
following product purchase information. The serial number of this product may be found on the cover
of the unit. The serial number may be required by the factory when need service or technical support.
CONGRATULATIONS ON YOUR PURCHASE OF OUR CAMERA
This product has been carefully inspected through rigid quality control before shipment. With
reasonable installation and operation, it will provide year of reliable performance. Considering your
investment, we understand you would like to know the full performance capability about the new
product. Therefore, we need to recommend that you read the installation and operation manual
thoroughly before attempting to install and operate the product.
Preface
Design for this series CCD camera is based on professional video system processing capability.
Interior Key components adopt Japan CCD sensor and IC. So the CCD camera has better performance
such as high sensitivity, sharpness, premium fidelity and low noise, also it has auto electronic shutter,
backlight compensation.
Because power design uses switching power, its operating current is only 200mA for DC12V model.
Installation becomes more simple and easily.
NVC-11BD Mini B/W dome camera, User`s Manual
4
© Copyright 2003, Novus Security Sp. z o.o. All rights reserved.
2. Safety instructions
1. Never expose the unit to rain or moisture to avoid electric shock hazard.
2. All service or maintenance should be made by qualified service personnel.
3. Storage temperature –30°C~80°C
4. All installation and service should conform to local codes.
5. Do not open the cover, it may expose you to power voltage and other hazard.
6. Do not place anything on the unit which maybe spill or fall into the unit.
7. The equipment has been tested and pass the CE standard, which are designed to provide reasonable
protection against harmful interference and be insusceptible to other radiating interference when
operated in commercial environment. Therefore, the equipment can’t also generate and cause any
interference to radio communication.
NVC-11BD Mini B/W dome camera, User`s Manual
5
© Copyright 2003, Novus Security Sp. z o.o. All rights reserved.
.,QVWDOODWLRQ
NVC-11BD Mini B/W dome camera, User`s Manual
6
© Copyright 2003, Novus Security Sp. z o.o. All rights reserved.
SPECIFICATIONS
Pick up Element 1/3" B/W CCD imager
Number of Pixels 537(H) x 597(V)
Synchronizing System Internal
Resolution More than 450 TVL
Video Output 1.0Vp-p composite,75 2KP
Min. Illumination 0.05 Lux / F1.2
Electronic Shutter AUTO 1/50 ~ 1/100,000 s
S/N Ratio 48dB (AGC off)
Gamma 0.45
Angle of View ~68º
Back Light Compensation AUTO
Lens Standard Lens: 3.6 mm
Operating Temperature 0º~ 50ºC
Power Supply DC12/ 200mA
Dimension (mm) 100(Ø) x 57.5(H)
Weight 135g
All rights reserved © NOVUS SECURITY
NOVUS SECURITY Sp. z o.o.
