Numark MIXSTREAM PRO Manuale utente

Quick-Start Guide

Numark

Mixstream Pro

Setup

Serato software

The Numark Mixstream Pro is a “Serato DJ Lite hardware unlocked” device, meaning it works with Serato

DJ Lite out of the box.

It is also a “paid upgrade to Serato DJ Pro device”, meaning it requires the purchase & activation of a Serato

DJ Pro license, in order to be used with Serato DJ Pro.

You can also try Serato DJ Pro, before making a purchase:

Click here to learn about buying or activating Serato DJ Pro

Click here to learn about trying Serato DJ Pro

Please ensure you have the latest version of Serato DJ Lite installed:

Click here to download Serato DJ Lite

Driver software

The Numark Mixstream Pro is class compliant on macOS but does require manufacturer specic drivers

when used with Windows operating systems. Download and install the Windows driver via Numark’s

website.

Then simply connect your Mixstream Pro with a USB cable to your computer, and launch the latest version

of Serato DJ Lite, and follow the steps below:

1. Connect the device via USB cable to your PC, power it on, and launch Serato DJ Lite

2. Once the device has booted, swipe down from the top of the LCD display on the device, and tap SOURCE

3. Tap the computer/laptop button then tap YES when prompted to restart the player into Computer Mode

Overview

2 3 4 51

# MIXSTREAM PRO CONTROL FUNCTION

1 MAIN (BALANCED) Connect audio output via XLR

2 MAIN Main audio output via RCA

3 USB Connect USB cable to computer

4 DC IN Connect included AC adapter to power source

5 POWER Press to power on / off device

6 HEADPHONES Connect headphones via 3.5mm or 6.5mm jack

7 MIC Connect microphone & adjust microphone gain

# MIXSTREAM PRO

CONTROL FUNCTION SHIFT

FUNCTION

1 MIX Adjust headphone between mix and headphone cue -

2 VOLUME Adjust headphone volume -

3 FILTER Turn left for low pass lter or right for high pass lter, per deck -

4 DISPLAY Shows track, library & waveform information -

5 MAIN Adjust main output volume -

6 SPEAKER Adjust built-in speaker volume -

7 JOG WHEEL Turn jog to bend pitch, or control waveform within Serato DJ

in vinyl mode

Fast track waveform scroll

8 PITCH BEND + / - Press + or - to bend pitch of playing track Toggle tempo range up (+) or

down (-)

9 TEMPO SLIDER Adjust tempo/pitch Ignore tempo/pitch adjustment

10 BUILT-IN SPEAKER Built-in speaker. Use Speaker control to adjust volume -

11 PERFORMANCE PADS

(SECTION)

SEE PERFORMANCE PADS FOR MORE INFORMATION -

12 BROWSE Turn to scroll library. Press in to toggle forward between crate

& track area

Fast Library scroll. Press in

to toggle backward between

crate & track area

13 CHANNEL CUE Toggle channel cue for monitoring -

14 FX (SECTION) Press FX Select button to load labelled FX to Slot 1, and set

depth to 60%. Pull FX lever to ON to turn on FX, or pull it to

HOLD to momentarily turn on FX. Left lever is for FX Unit 1

and right lever is for FX Unit 2.

Overview

1 52 63 4

11121314151617181920

Overview

# MIXSTREAM PRO

CONTROL FUNCTION SHIFT

FUNCTION

15 CROSSFADER Crossfade audio between channel 1-2 -

16 CHANNEL FADER Adjust channel volume (per channel) -

17 BACK Press to cycle back between crate & track area -

18 CHANNEL (SECTION) Adjust level, and adjust EQ (Treble, Mid, Bass) -

19 LOAD 1 Press to load selected track to Deck 1 (press LOAD 2 for

Deck 2)

20 SHIFT Shift modier, which can be held while using another control

for secondary SHIFT function

21 PLAY / PAUSE Toggles Play / Pause on selected deck Stutter play

22 CUE Cues from temp cue point/Set temp cue point Load previous track

23 SYNC Press to turn SYNC on (per deck) Press to turn SYNC off (per

deck)

24 SCRATCH Toggle vinyl or jog platter mode (per deck) -

Performance Pads

The Numark Mixstream Pro comes with 4 performance pads, that can be used across 4 different

performance pad modes.

The 4 modes can be triggered by pressing the performance pad mode button of the same name once, and

consist of:

CUE mode: Press the CUE pad mode button to enter CUE mode. Pads 1-4 trigger Serato DJ Lite Cue

points, and if no Cue point is present on that slot/pad, pressing that pad will set a Cue point. Holding down

the SHIFT button while pressing a populated pad will delete the Cue point from the respective pad/slot.

MANUAL LOOP mode: Press the SAVED LOOP pad mode button to enter MANUAL LOOP mode. Press

pad 1 to set the Loop In point, and press it again to edit the Loop In point. Press pad 2 to set the Loop Out

point, and press it again to edit the Loop Out point. Press pad 3 to turn the Loop on or off, and press pad

4 to trigger a Reloop or Exit an active Loop.

AUTO LOOP mode: Press the AUTO LOOP pad mode button to enter Auto Loop mode. In this mode

pads 1-4 trigger an Autoloop of varying sizes. Press the same pad for a second time to exit an Auto Loop.

LOOP ROLL mode: Press the ROLL pad mode button to enter Loop Roll mode. Holding Pads 1-4

activate a loop roll of varying sizes. Release the pad to exit the Loop Roll.

Show Tooltips

Click on the button in the upper right-hand corner of Serato DJ Lite, then to enable

tooltips. Tool tips provide a handy way to learn the various features of Serato DJ Lite.

Move the mouse over a section of the screen to bring up a context sensitive tool tip.

Watch Tutorials

Click on the button in the upper right-hand corner of Serato DJ Lite, then to launch

your default internet browser and watch tutorials, to help you get familiar with Serato DJ Lite.

Get Support

Click on the button in the upper right-hand corner of Serato DJ Lite, then to launch your

default internet browser and navigate to the Serato DJ Lite knowledge base, where you can nd helpful

articles and guides on Serato DJ Lite. Alternatively, type in the box, with keywords, to

search the Serato DJ Lite knowledge base for specic, related topics.
