QUICK-START

GUIDE

NUMARK

MIXTRACK QUAD

Installation and Setup

The Numark Mixtrack Quad is a class compliant USB plug and play device

and requires no further driver installation.

1. Connect your Mixtrack Quad to an available USB Port

2. Open Serato DJ Intro

3. The Mixtrack Quad platters require a few touches by the user in order

to calibrate to their environment. After power up and start of Serato DJ

Intro, tap the platters a few times to set their sensitivity.

NOTE: Always make sure your controllers rmware is the latest available.

Go to the controller manufacturers website for the latest rmware update.

MIXTRACK

QUAD

1 2 3 4 5 6 7 8 9 10 11

151617181920212223

Controller

NOTE: SHIFT button is used with other buttons that have shift modier functions.

# Mixtrack Quad Control Serato DJ Function Shift Function

1 FX UNIT See DJ FX section

2 PERFORMANCE PADS See Performance Pads section

3 FILTER Adjust beats multiplier

4 LOAD A Load track to left deck

5 CUE GAIN Adjust headphone volume

6 BROWSE Turn to browse through open panel. Push to cycle forwards through

open panels

Push to cycle backwards through open panels

7 CUE MIX Mixes between the headphone cue and master output

8 MASTER GAIN Adjust master ouput level

9 LOAD B Load track to left deck

10 CHANNEL EQ Bass, Mid, Treble channel equalizers

11 PITCH BEND Use to nudge the pitch up or down. This will slightly speed or slow

down your track temporarily.

SHIFT + KEYLOCK toggle keylock ON/OFF.

SHIFT + RANGE toggles pitch range.

12 PITCH FADER Adjust tempo of playing track When in Sync mode, used to disable the Pitch

Fader temporarily and change the zero position

13 LAYER Use to swap the deck layer so you can control decks 3 & 4 Use in conjunction with performance pads to

change the lighting on your platters

14 PLATTER Touch the top to scratch or jog. Moving the outside of the wheel will jog

15 STUTTER Stutter play

16 PLAY/PAUSE Play/Pause track

17 CUE Jump to start of track (more than 2 Sec elapsed) Previous track (less

than 2 sec elapsed)

18 SYNC Sync on Sync Off (Press twice to return to Absolute

Pitch when in Relative Mode)

19 SCRATCH Toggle between Scratch or Jog

NOTE: SHIFT button is used with other buttons that have shift modier functions.

# Mixtrack Quad Control Serato DJ Function Shift Function

20 CHANNEL FADER Adjusts channel volume

21 CROSS FADER Crossfades between the two channels

22 SHIFT SHIFT button is used with other buttons that have shift modier

functions.

23 CUE Cue selected channel in headphones

Performance Pads

The performance pads have three different modes you can select. The three

modes are; LOOP, SAMPLE (S), CUE (C)

NOTE: To enter a peformance mode, press SHIFT + LOOP, SAMPLE or

CUE pads. The LED will light up below the pad to indicate this mode is

active.

• Loop Mode: The LOOP IN and OUT pads place the IN and OUT points

of a manual loop. RELOOP will activate and jump to current loop. If you

are currently in an active loop, RELOOP will turn the loop off. You can

set Auto Loops by Holding SHIFT + AUTO1, AUTO2, AUTO4, AUTO16.

Press 1/2X to half the length of your loop or press SHIFT + 1/2X to

double the length.

• Sampler Mode: S1, S2, S3 and S4 trigger samples loaded in your

Sample Player.

• Hot Cue Mode: C1, C2, and C3 will add or trigger Cue Points. To

remove Cue Points, hold C4 and press C1, C2, and C3.

Looping

You have the choice of Manual or Auto looping within Serato DJ Intro with

the Mixtrack Quad.

Mixtrack Quad Control Manual Loop Mode

LOOP IN Set loop in point (Loop not active)

LOOP IN Adjust loop in point (Loop active)

OUT Set loop out point (If loop in point is set)

OUT Adjust loop out point (Loop active)

RELOOP Loop off (Loop active)

RELOOP Activate and jump to Loop (Loop not active)

1/2X Half the length of the current loop

SHIFT + 1/2X Double the length of the current loop

NOTE: The best way to edit the in and out points of a manual loop is with

the jog wheel/platter on your Mixtrack Quad.

Mixtrack Quad Control Manual Loop Mode

SHIFT + AUTO1 Auto Loop 1 Bar ON/OFF

SHIFT + AUTO2 Auto Loop 2 Bar ON/OFF

SHIFT + AUTO3 Auto Loop 4 Bar ON/OFF

SHIFT + AUTO4 Auto Loop 16 Bar ON/OFF

1/2X Half the length of the current loop

SHIFT + 1/2X Double the length of the current loop

DJ-FX

You can have up to three different effects active per Virtual deck within

Serato DJ Intro with the Mixtrack Quad

Mixtrack Quad Control Serato DJ Function

AUTO 1 (Button) Effect 1 On/Off. Hold SHIFT + turn

knob to select effect

AUTO 2 (Button) Effect 2 On/Off. Hold SHIFT + turn

knob to select effect

AUTO 3 (Button) Effect 3 On/Off. Hold SHIFT + turn

knob to select effect

RESET (Button) Manually input FX BPM. Hold to reset

SELECT 1 (Knob) Adjust FX 1 depth

SELECT 2 (Knob) Adjust FX 2 depth

SELECT 3 (Knob) Adjust FX 3 depth

FILTER (Knob) Adjust beats multiplier

Using the Tool Tips

Click on the icon to enable Tool Tips. This is located in next to the

setup button in the top right hand corner of the screen. Tool Tips provide a

handy way to learn the various features of Serato DJ Intro.

Move the mouse over a section of the screen to bring up a context

sensitive tool tip. Holding the mouse over the button with Tool Tips

turned on will show you a list of all keyboard shortcuts.

For more information about how to use Serato DJ Intro, please go to our

website www.serato.com or refer to the Serato DJ Intro Software Manual.

For more information on your controller, please refer to the hardware

manual.

For further help, please contact support@serato.com or go to www.serato.

com/dj-intro/support
