Numatic HZ 390-S2 Manuale utente

HZ 390-S2 / HZ 390-L2

1200W (Kit AA18)

Owner Instructions

www.numatic.co.uk

Warning! Read the Instructions before using the machine.

This machine is suitable for DRY

use only.

Make sure that the ltration system

tted to the machine is suitable for

the material being collected.

PLEASE READ

BEFORE COMMENCING

OPERATION

HZ 390-L2

HZ 390-S2

Kit AA18

601101 2.4 NuFlex Threaded Hose 601144 65mm Soft dusting brush

218016 NVM-2BH HEPAFLO lter bags 629445 Roll of 10x 120 litre waste bags, white

601142 240mm Crevice tool 601141 Double taper hose / tool adaptor

602159 38 / 32mm Adaptor 601917 280mm Stainless steel gulper / scraper tool

604165 TriTex lter for 305mm machines 602161 152mm Rubber brush with soft bristles (38mm)

Handle Assembly

1 3

Air Diffuser

Hose

Machine Function

O

Moving your Machine

Changing the bag, cleaning the lter

1. Remove the cloth lter (A) from the drum.

2. Remove the HEPAFLO dust bag and seal the dust bag hole.

3. Place the dust bag inside an impervious plastic bag and seal the bag.

4. Dispose of the plastic bag, depending on contamination, in an appropriate manner.

3 4

Cleaning your TriTex Filter

901649

H13 Filter Cartridge

Replacing the Cartridge Filter

Lo - Flo Indicator.

This appliance is tted with a low ow indicator to show that air ow has reduced.

In the event of the indicator light ashing, check the following:-

Low Flow Warning Light

Cause Solution

Dust caps still tted Remove the caps.

Blocked hose Unblock the hose.

Bag full Remove and replace

Cloth lter clogged Remove and replace, clean dirty lter by vacuuming.

Hepa cartridge clogged Replace, seek advice from an instructed

person or manufacturer.

Classication TYPE H

Voltage 220 - 240V

Frequency 50 - 60Hz

Power rating 1000W IEC

1200W MAX

Sound Pressure 71.79 B(A) (with gulper tool) to IEC 60704-2-1

+/- 0.2dB(A)

Max. Flow Rate (In Product) 33L/s (118.8 m3/h)

Low ow operation 16L/s (57.6 m3/h)

(NB 16L sec corresponds to an airspeed of 20m/sec in a 32mm pipe)

321

654

987

10 11

Changing / Replacing Cable

WEEE (Waste, Electrical and Electronic Equipment)

Vacuum Cleaner Accessories and packaging should be sorted for environmentally-friendly recycling.

Only for EU countries.

Do not dispose of Vacuum Cleaner into household waste.

According to the European Directive 2012/19/EU on waste electrical electronic equipment

and its incorporation into national law.

Vacuum cleaners that are no longer suitable for use must be separated, collected and sent

for recovery in an environmentally-friendly manner.

Rating Label

1Company Name & Address

2Machine Description

3Voltage / Frequency

4Power rating

5IPX Rating

6Weight (ready to use)

7Type Hazardous

8 CE Mark

9WEEE Logo

10 Machine yr/wk Serial number

About the Machine

Safety Critical Component:

Mains Lead

H05VV-F 10m x 3 x 1.0mm²

NOTE: A risk assessment should be conducted to determine which PPE should be worn.

Ear Protection Safety Footwear Head Protection Safety Gloves

Eye Protection Protective

Clothing

Dust / Allergens

Protection Hi Viz Jacket Caution Floor Sign

PPE (personal protective equipment) That may be required for certain operations.
