Nuna rava Guida alla configurazione
child restraint
cleaning instructions
1
EN
Cleaning and Maintenance
WARNING: Do not attempt to disassemble
the Child Restraint. Only perform steps shown in
this manual.
Seat Cover Removal
1 To remove seat pad: (1)
a Recline Child Restraint to
rear facing position 1 (BLUE).
b Set Head Support in
highest position.
c Loosen and unbuckle
Harness and Chest Clip.
d Fully extend Calf Support.
e Remove Tether from Storage Anchor.
2 Remove Harness/Buckle Pads as well as Infant
and Head Inserts.
Take care when removing Head Support Cover
so as not to damage the energy absorbing foam.
3 Remove Head Support Cover.
(2)
aGrasp Head Support
Cover at top behind Head
Support Button.
b Peel Cover off Head
Support; work on one side
then the other. Unsnap
Cover and remove.
1
e
a
b
c
d
2
a
b
2
EN
4 Unsnap Seat Cover. (3)
5 Remove Seat Cover from
Calf Support.
6 Remove Seat Cover from
beneath Harness Release
Button frame. (4)
a Grasp the Seat Cover at
the top of the Harness
Release Button.
b Pull away from Button
(toward seat back) and up.
c Work cover out from under
the Button frame.
7 Remove Cover from
Child Restraint. (5)
a Start at bottom, near
Calf Support, work toward
Buckle Holder. Pull Seat
Cover out of seat cover
retaining channel.
b Unhook Cover beneath
Buckle Tongue Holder.
c Continue to the Tether.
d Repeat steps A through C
for the other side.
8 Flip cover over the top of the
Child Restraint. Slide Seat
Cover off of the Tether. (6)
Seat Cover Assembly
1 Reverse Steps of Seat Cover Removal.
5
6
b
a
4
3
3
EN
a Recline Child Restraint to
rear facing Position 1.
b Tuck the seat cover into
the retaining channel
along the edge of the
seat and tuck the corner
ap in near the screw (7).
c From the center of the
seating area, push the
white plastic tab (7) on
the seat cover down over
the screw while pulling
down on the fabric from
the outside (8).
d Ensure both corner
pockets are secured
to the outside of the
Calf Support.
Cleaning the Seat Cover and Harness Pads
1 When required, Seat Cover and harness pads
may be machine washed with cold water and
mild detergent, on the delicate cycle.
2 Allow to air dry.
DO NOT use bleach or other harsh chemicals
to clean your Child Restraint Cover or Harness.
DO NOT attempt to iron your Child Restraint
Cover.
7
8
Plastic tab
Screw
4
EN
Cleaning the Infant Insert
1 When required, the Infant Insert may be machine
washed with a mild soap and cold water.
The support wedge located on the back side of
the Infant Insert should be spot cleaned only.
DO NOT machine wash the support wedge.
2 Allow to air dry.
Cleaning the Harness
The Child Restraint harness system cannot be
removed. DO NOT attempt to remove the harness
system.
1 When required, harness may be hand washed
with a sponge and warm soapy water.
2 Towel dry excess water and allow to air dry.
DO NOT attempt to iron your Harness.
Cleaning the Shell
1 When required, shell may be hand washed
with damp sponge.
2 Towel dry.
DO NOT use abrasive cleansers on the Shell.
Cleaning the Buckle
BUCKLE CAN NOT BE REMOVED.
1 To clean buckle, wipe with damp cloth.
IM-0225A
nuna.eu
1-855-NUNA-USA
