Quick Start Guide
HINGE 13 DRAWCONVERTIBLE LAPTOP
Tmax
TM133WH710C
FCC ID:
2
Getting Started
This guide has been designed to help familiarize you with the
features and functions of the HINGE 13 DRAW, and get you
‘up-and-running’ as soon as possible.
Visit www.nuvision.com to register your device, and access the
online user manual, how-to-videos, FAQs and more to optimize
your NuVision experience.
Remember to register your device at
www.nuvision.com/product-registration
3
Package Contents
Digital Pen & (1) AAAA
Battery
Device
AC/DC Adapter
4
Device Overview
1
5
6
7
8
9
11
10
4
2
3
DC 12V
DC 12V
5
Device Overview
1AC/DC Adapter Connection
2
USB Port
3
Micro HDMI Port
4Front Camera Lens
5Keyboard Indicator Lights
63.5mm Headphone Jack
7USB Port
8Micro TF Card Slot
9Power Button
10 Fingerprint ID Scanner
11 M.2 SSD Slot (Supports
Type B Key, Size 2242. For
installation, please refer to
the online manual)
1
5
6
7
8
9
11
10
4
2
3
6
Keyboard Overview
1Function Key
2Open Active Menu
12
k
k
7
Pen Overview
1Tip
2Pen Head
3Eraser Button
4Alt Button (Mouse Right-Click)
5Clip
6Pen Top
7AAAA Battery (Inserts Positive
End Towards the Tip)
8Use Pen Replacement Tool to
Remove/Replace Tip
1
24
5
6
7
38
8
Connect to the Internet
A Home WiFi Router or a publicly-available WiFi signal
(ie., In a library, coffee shop or school.)
OR
9
Connect to the Internet
The Network Name (SSID) and Network Security Key
(ie., Password) for the Internet Connection
NAME (SSID): XXXXXX
WIFI INFO
PASSWORD: XXXXXX
AND
10
Charge the Device
It is recommended to fully charge the battery before first use.
Note: It is normal for the tablet to become warm while charging.
Connect the AC/DC power adapter to a wall outlet, then to the
device’s DC port as shown. A red light next to the Micro HDMI
port will indicate when the device is charging.
